- Page 1 Model No MX1616-310 Operating Instructions Thanks for purchasing our product. Please be sure to read this instruction manual carefully before using our product.
- Page 2 Introduction MX1616-310 is an 16-by-16 DVI/HDMI true matrix. It allows any of the sixteen source (Blue-Ray player, HD DVD player, satellite receiver, game system, etc.) to be routed to any of the sixteen displays simultaneously, no matter the source is HDCP or not. Users can choose several different ways to control the matrix: by using infrared extension receiver, RS232, RS485, LAN, touch panel, panel buttons and supplied remote control.
-
Page 3: Table Of Contents
Contents HDMI Matrix..................... 1 Product Overview .................... 1 Features......................1 Package Contents.................... 4 Panel Descriptions ................... 4 Front Panel ...................... 4 Back Panel....................... 5 Connections..................... 6 Operations ....................... 7 Operations ....................... 8 Specifications....................19 Typical Application ..................20 Maintenance ....................20 Product Service ..................... -
Page 5: Hdmi Matrix
HDMI Matrix Product Overview ( Model Number: MX1616-310 ) ■ Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. - Page 6 simultaneously. The UTP output supports both dual and single cat5e/cat6. Reading and saving EDID function from displays. Support high definition resolutions, including 1080p, 1080i, 720p and other standard video formats. Each port supports both HDMI and DVI inputs. With extra infrared extension receiver. Seven switching modes: panel buttons, touch panel, local IR, IR call back from remote locations, RS232, RS485 and Ethernet.
- Page 7 Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth. splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
-
Page 8: Package Contents
Package Contents ■ Main unit. P/N_MX1616-310. ① Operating Instructions. P/N_INSMX1616-310. ② Handles. ③ Mounting ears. ④ Stylus. ⑤ 1 x 100~240V AC Power cable. ⑥ 1 x USB to UART cable. ⑦ 1 x RS232 to RS485 convertor. ⑧ 1 x IR RX (IR receiver cable). ⑨... -
Page 9: Back Panel
Touch panel. ① Function panel button. ② Keypad. ③ Indicator of operating. ④ IR receive window. ⑤ Power switch. ⑥ Back Panel ISP port ① IR TX ② HDMI input port ③ LAN port ④ HDMI output port ⑤ IR extension ⑥... -
Page 10: Connections
IR TX cable into MX1616-310 IR emitter. ⑥ Power on the input source you want to show. ⑦ Connect the power supply into MX1616-310 and turn on the display you want to watch. ⑧ Use the remote supplied or pushes the button on the front panel to choose input source, or using touch panel, infrared extension receiver, RS232, RS485 or LAN port to do the control. - Page 11 HD STB BD DVD Signal IR Tx IR Tx HDMI Signal Signal MX1616-310 HDMI TV 1 Signal from TV 31 HDMI port HDMI Signal from RJ45 port receiver receiver IRSignal IR Signal HDMI Signal IR Rx IR Rx TV32 remote...
-
Page 12: Operations
Operations ■ Operation on Touch panel. Main Menu Switch Menu TYPE A: Step A.1: Select an output port or ‘A’, and press “OK”, Step A.2: Select an input source, and press “OK”. TYPE B: Step B.1: Select a model, and press “OK”. NOTE: ‘C’... - Page 13 ④ Preview Menu Step: Select an Input port, and press “OK”. ⑤ Observe Menu Step: Select an output port, and press “OK”. ⑥ Save Menu Step: Select a save model, and press “OK”. Page 9...
- Page 14 ⑦ Setting Menu There are 5 sub-menu here: EDID/LC/IR/EQ/RST. i. EDID menu There are 6 mode provided. When select a different mode, and press “OK”, the following warning box will pop up: The mode selected will be effective after next power-on. Page 10...
- Page 15 EDID mode details: Index EDID Mode Details Remark copy HDMI output's edid to the specified input Full Copy Note1 port Limited copy HDMI output's edid to the Limited Copy Note2 specified input port Fixed 1080P-2CH Fix EDID—1080p stereo Note3 Fixed 1080P-6CH Fix EDID—1080p 5.1Audio Note4 Fixed 1080P-8CH...
- Page 16 Note: 6.The matrix will use the embedded 1080i-stereo EDID when this mode is effective. Page 12...
- Page 17 LC menu There are 4 mode in LC menu. Index Long cable mode Details H-OFF, UTP-ON Hdmi LC mode off; UTP LC mode on.(Default) H-OFF, UTP-OFF Hdmi LC mode off; UTP LC mode off H-ON, UTP-ON Hdmi LC mode on; UTP LC mode on H-ON, UTP-OFF Hdmi LC mode on;...
- Page 18 IR call back from remote locations to control the HDMI Matrix MX1616-310. You can use the MX1616-310’s remote through the IR RX of the UTP receiver to change the input channel for the UTP out of the MX1616-310, just changing this UTP output.
- Page 19 Setting Setting Setting Setting Index Index Index Index details details details details 0db/0db(def 16db/0db 23db/0db 26db/0db ault) 0db/-3db 16db/-3db 23db/-3db 26db/-3db 0db/-6db 16db/-6db 23db/-6db 26db/-6db 0db/-9db 16db/-9db 23db/-9db 26db/-9db 10db/0db 19db/0db 25db/0db 27db/0db 10db/-3db 19db/-3db 25db/-3db 27db/-3db 10db/-6db 19db/-6db 25db/-6db 27db/-6db 10db/-9db 19db/-9db...
- Page 20 NOTE: If the touch screen becomes insensitive, calibration is necessary Touch screen calibration method: Press the panel button “Setting” in the home menu status, holding until the following prompt appears(about 4s). Press the symbol's center, until the one disappears and another symbol appears, and press its center again until the end of the calibration—OK or Failure.
- Page 21 TYPE A: Step A.1: Press “Switch”, Step A.2: Select an output port or ‘A’, and press “OK”, Step A.3: Select an input source, and press “OK”. TYPE B: StepB.1: Press “Switch”, Step B.2: Select a model, and press “OK”. NOTE: ‘C’ means Clear, if type the wrong number, press ‘C’. ‘A’ means All, only valid at step A.2.
- Page 22 2) Operation via IR remote. IR Local or IR extender: Step1: select an output port; Step2: select an input port or ‘<<’/’>>’(down/up) NOTE: The time between the two steps must be less than 4 seconds. IR callback: Step: select an input port or ‘<<’/’>>’(down/up) NOTE: Can only control the corresponding UTP port.
-
Page 23: Specifications
Specifications ■ Operating Temperature Range -5 to +35oC(-41 to +95oF) Operating Humidity Range 5 to 90 % RH (no condensation) Video Amplifier Bandwidth 2.25Gbps Input Video Signal 0.5-1.0 volts p-p Input DDC Signal 5 volts p-p (TTL) Maximum Single Link Range 1080p Deep Color VESA: 640x480, 800x600, 1024x768, 1280x1024, 1600x1200, 1920x1200... -
Page 24: Typical Application
Typical Application ■ Maintenance ■ Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Product Service ■ ● Provided Service Damage Requiring service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adaptor has been damaged;... -
Page 25: Mail-In Service
The unit has been dropped or the cabinet damaged. Servicing Personnel: Do not attempt to service the unit beyond that described in these operating instructions. Refer all other servicing to authorized servicing personnel. Replacement parts: When parts need replacing ensure the servicer uses parts specified by the manufacturer or parts that have the same characteristics as the original parts. -
Page 26: Warranty Limits And Exclusions
mail-in your product during the warranty period. This Limited Warranty is extended only to the original purchaser and only covers product purchased as new. A purchase receipt or other proof of original purchase date is required for Limited Warranty service. ●...
