Welcome
Lightcloud is a commercial
wireless lighting control system
& service. It's powerful and
flexible, yet easy to use
and install. Learn more at
lightcloud.com
1 (844) LIGHTCLOUD
Sensor
1 (844) 544-4825
support@lightcloud.com
LCSENSE15/D10 (Ceiling Sensor)
LCHBSENSE15/D10 (High Bay Sensor)
WE ' RE HERE TO HELP:
1 (844) LIGHTCLOUD
Custom manufactured in China
1 (844) 544-4825
© RAB Lighting, Inc
support@lightcloud.com
170 Ludlow Avenue Northvale, NJ 07647
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for RAB Lighting Lightcloud LCSENSE15/D10
Summary of Contents for RAB Lighting Lightcloud LCSENSE15/D10
- Page 1 1 (844) LIGHTCLOUD Sensor 1 (844) 544-4825 support@lightcloud.com LCSENSE15/D10 (Ceiling Sensor) LCHBSENSE15/D10 (High Bay Sensor) WE ’ RE HERE TO HELP: 1 (844) LIGHTCLOUD Custom manufactured in China 1 (844) 544-4825 © RAB Lighting, Inc support@lightcloud.com 170 Ludlow Avenue Northvale, NJ 07647...
- Page 2 Hello Lightcloud is a wireless lighting control service. The Lightcloud Sensor is a remotely configurable passive infrared motion Product Features sensor that can switch and Advanced PIR Sensing Secure Cloud Control & Configuration dim both hardwired circuits Retrofit-Friendly Local Control and remote circuits using Scheduling &...
-
Page 3: Specifications
Contents Specifications Indoor Damp Location Lightcloud Ceiling Sensor Wire Nuts Instruction Manual or High Bay Sensor PART NUMBER OPERATING HUMIDITY 10% RH to 95% RH LCSENSE15/D10 (Ceiling) LCHBSENSE15/D10 (High Bay) Non-Condensing INPUT OPERATING TEMPERATURE 120-277VAC, 50/60Hz, -20ºC to 40ºC <1W (Standby) - 2W (Active) OVERALL DIMENSIONS MAXIMUM SWITCHED LOAD RATINGS 4.91”... -
Page 4: Setup And Installation
Setup & Installation Find a suitable location Install your Lightcloud Sensor Use these guidelines when installing devices: INSTALL AT A JUNCTION BOX INDOOR/OUTDOOR The Sensor can control other Lightcloud devices, wirelessly. • If there is a clear line of sight between two Lightcloud devices, If you don’t need to hard-wire a switched circuit to the Sensor, they can be placed up to 1000 feet apart. - Page 5 Setup & Installation (cont’d) SWITCHED NEUTR AL The “Switched Neutral” white with red stripe wire is the neutral line for the load being switched. This enables power Installing Accessories (High Bay only) Wiring Panel measurement. See the Power Measurement section under “Functionality”...
- Page 6 Setup & Installation (cont’d) Labeling your device Power up To add new devices to your Lightcloud network, contact RAB: D E VICE ID s WE ’ RE HERE TO HELP: 1 (844) LIGHTCLOUD or 1 (844) 544-4825 support@lightcloud.com PA NE L / ZO NE N A ME CIRCUIT # Confirm device connectivity...
- Page 7 Setup & Installation (cont’d) Place cover Commission & Con gure Your Devices Secure cover onto sensor by pushing up and twisting to the right (clockwise). All Lightcloud products can be commissioned and configured by: • Logging on to lightcloud.com STATUS •...
- Page 8 Functionality STATUS INDICATOR: • Solid GREEN when connected to your Lightcloud network • Blinking RED when not connected to a Lightcloud network. The device will automatically continue trying to connect to a network that is in Setup Mode. Overview POWER INDICATOR: STATUS INDICATOR Illuminated when powered.
- Page 9 Functionality (cont’d) Features Features: Passive Infrared Motion Detection OCCUPANCY & VACANCY SENSING: CEILING SENSOR HIGH BAY SENSOR The Lightcloud Sensor can operate in either Occupancy or Vacancy Sensor modes, selectable via the Lightcloud application. In Occupancy mode, the attached 9’ circuit will be switched on when motion is detected, and o (or dimmed) when the 30’...
- Page 10 (i.e. all neutral wires joined). CAUTION: Changes or modi cations to this equipment not expressly approved by RAB Lighting may void the user’s authority to operate this equipment.
