SSL Live Installation Information
Remote Tile
Rear Connections
Mains Power Inlet - *1
USB B Connection - *8c
Connects to console via USB A-B Cable (up to 5m without active repeaters)
Remote Tile Weight, Power & Dimensions
Weight (without flight case)
Weight (with flight case)
Acoustic Noise
Power
Console Dimensions: (upper figures in millimeters, lower figures feet & inches) - A DXF drawing is
available from SSL
www.solidstatelogic.com
9.7 kg (21.4 lbs)
19.7 kg (43.5 lbs)
Fan does not start until external temperatures
reach approximately 40 ºC. Above 40 ºC, NR33.
<100 W
Page 21 of 43
