- Page 1 W251BLQ / W253BLQ / W253BZQ / W258BZQ...
- Page 3 Preface Notebook Computer W251BLQ / W253BLQ / W253BZQ / W258BZQ Service Manual...
- Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
- Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the W251BLQ / W253BLQ / W253BZQ / W258BZQ series notebook PC.
- Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
- Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
- Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
- Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
- Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.
-
Page 11: Table Of Contents
Bottom (W253BZQ) ..............A-8 Overview ..................1-1 Bottom (W258BZQ) ..............A-9 Specifications ..................1-2 DVD (W251BLQ) ............... A-10 External Locator - Top View with LCD Panel Open ......1-4 DVD (W253BLQ / W253BZQ) ..........A-11 External Locator - Front & Right Side Views .........1-5 DVD (W258BZQ) ............... - Page 12 Preface KBC-ITE IT8518 ................. B-21 LED/MDC/BT ................B-22 Fan/TP/Multi CON ............... B-23 5VS/3.3VS/1.8VS/1.5VS/1.1VS ..........B-24 Power VDD3, VDD5 ..............B-25 Power 1.5V/0.75V ................ B-26 Power 1.1V/1VS ................B-27 Power 1.8VS ................. B-28 APU Core/NB Core ..............B-29 Charger, DC In ................B-30 Click Board ..................
-
Page 13: Introduction
Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the W251BLQ / W253BLQ / W253BZQ / W258BZQ series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. -
Page 14: Specifications
Introduction Specifications Processor Options Audio AMD-E Series Accelerated Processing Unit - E2-1800 High Definition Audio Compliant Interface (1.7GHz) 2 * Built-In Speakers 1MB L2 Cache, 40nm, DDR3-1333MHz, TDP 18W Built-In Microphone AMD-E Series Accelerated Processing Unit - E1-1200 Keyboard (1.4GHz) Full-size “WinKey”... - Page 15 Introduction Environmental Spec Temperature ° ° Operating: 5 C - 35 Non-Operating: -20°C - 60°C Relative Humidity Operating: 20% - 80% Non-Operating: 10% - 90% Power (for C-70 APU) 6 Cell Smart Lithium-Ion Battery Pack, 48.84WH (Factory Option) 6 Cell Smart Lithium-Ion Battery Pack, 62.16WH Full Range AC/DC Adapter AC Input: 100 - 240V, 50 - 60Hz...
-
Page 16: External Locator - Top View With Lcd Panel Open
Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera (Optional) 2. LCD 3. Power Button 4. LED Status Indicators 5. Keyboard 6. Built-In Microphone 7. Touchpad & 15.6” (39.62cm) Buttons 1 - 4 External Locator - Top View with LCD Panel Open... -
Page 17: External Locator - Front & Right Side Views
Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Power Indicator FRONT VIEW Figure 3 Right Side View 1. Microphone-In RIGHT SIDE VIEW Jack 2. Headphone-Out Jack 3. USB 2.0 Port 4. Optical Device Drive Bay 5. -
Page 18: External Locator - Left Side & Rear View
Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. External Monitor Port LEFT SIDE VIEW 3. RJ-45 LAN Jack 4. HDMI-Out Port 5. USB 3.0 Port 6. Vent 7. Multi-in-1 Card Reader Figure 5 REAR VIEW... -
Page 19: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Component Bay Cover 3. Vent 4. Hard Disk Bay Cover 5. Speakers 6. USIM Card Cover Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. -
Page 20: Mainboard Overview - Top (Key Parts)
Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT8518 2. Audio Codec VT1802P 1 - 8 Mainboard Overview - Top (Key Parts) -
Page 21: Mainboard Overview - Bottom (Key Parts)
Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Memory Slots DDR3 SO-DIMM 2. CPU Socket (no CPU installed) 3. Platform Controller 4. Mini-Card Connector (WLAN Module) Mainboard Overview - Bottom (Key Parts) 1 - 9... -
Page 22: Mainboard Overview - Top (Connectors)
Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. HDMI-Out Port 2. USB 3.0 Port 3. Speaker Cable Connector 4. Microphone Cable Connector 5. Audio Board Connector 6. TouchPad Cable Connector 1 7. TouchPad Cable Connector 2 8. -
Page 23: Mainboard Overview - Bottom (Connectors)
Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Battery Connector 2. ODD Connector 3. HDD Connector 4. CMOS Battery Connector 5. CPU Fan Cable Connector 6. Multi-in-1 Card Reader 7. RJ-45 LAN Jack 8. External Monitor Port 9. - Page 24 Introduction 1 - 12...
-
Page 25: Disassembly
Disassembly Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the W251BLQ / W253BLQ / W253BZQ / W258BZQ series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicat- ed). We suggest you completely review any procedure before you take the computer apart. -
Page 26: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 27: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 28: Disassembly Steps
Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: 1. Remove the battery page 2 - 5 To remove the HDD: 1. -
Page 29: Removing The Battery
Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide the latch and hold it 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a in place. -
Page 30: Removing The Hard Disk Drive
Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Chapter 4 of the User’s Manual) when setting up a new hard disk. - Page 31 Disassembly 3. Remove the hard disk bay cover (Figure 3b Figure 3 4. Grip the tab and slide the hard disk in the direction of arrow (Figure 3c HDD Assembly 5. Lift the hard disk assembly out of the bay (Figure 3d Removal (cont’d.) 6.
-
Page 32: Removing The Optical (Cd/Dvd) Device
Disassembly Removing the Optical (CD/DVD) Device Figure 4 Optical Device 1. Turn off the computer, remove the battery (page 2 - 5) and hard disk (page 2 - Removal 2. Remove the screw at point (Figure 4a 3. Use a screwdriver to carefully push out the optical device at point (Figure 4b a. -
Page 33: Removing The System Memory (Ram)
Disassembly Removing the System Memory (RAM) Figure 5 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDRIII (DDR3) Up to 1066/1333 MHz. The main memory can be expanded up to 8GB. The SO-DIMM modules sup- ported are 1024MB and 2048MB DDRIII Modules. - Page 34 Disassembly 5. Pull the latches to release the second module if necessary. Figure 6 6. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. RAM Module 7. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot Removal (cont’d.) as it will go.
-
Page 35: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module Figure 7 Wireless LAN 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 7a). -
Page 36: Removing The Keyboard
Disassembly Removing the Keyboard Figure 8 Keyboard Removal 1. Turn off the computer, and remove the battery (page 2 - 2. Remove screws from the bottom of the computer. Press at points to unsnap the LED cover module a. Remove screws from the bottom of the computer. -
Page 37: Part Lists
Appendix A:Part Lists This appendix breaks down the W251BLQ / W253BLQ / W253BZQ / W258BZQ series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation. -
Page 38: Part List Illustration Location
Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part W251BLQ W253BLQ W253BZQ W258BZQ Location page A - 3 page A - 4 page A - 5... -
Page 39: Top (W251Blq
Top (W251BLQ) Figure A - 1 Top (W251BLQ) 非耐落 (灰色) (尚盟) Top (W251BLQ) A - 3... -
Page 40: Top (W253Blq / W253Bzq
Top (W253BLQ / W253BZQ) Figure A - 1 Top (W251BLQ / W253BLQ / W253BZQ / W258BZQ) A - 4 Top (W253BLQ / W253BZQ) -
Page 41: Top (W258Bzq
Top (W258BZQ) Figure A - 1 Top (W258BZQ) 非耐落 灰色 Top (W258BZQ) A - 5... -
Page 42: Bottom (W251Blq
Bottom (W251BLQ) Figure A - 2 Bottom (W251BLQ) A - 6 Bottom (W251BLQ) -
Page 43: Bottom (W253Blq
Bottom (W253BLQ) Figure A - 3 Bottom (W253BLQ) Bottom (W253BLQ) A - 7... -
Page 44: Bottom (W253Bzq
Bottom (W253BZQ) Figure A - 4 Bottom (W253BZQ) A - 8 Bottom (W253BZQ) -
Page 45: Bottom (W258Bzq
Bottom (W258BZQ) Figure A - 5 Bottom (W258BZQ) Bottom (W258BZQ) A - 9... -
Page 46: Dvd (W251Blq
DVD (W251BLQ) Figure 6 DVD ( W251BLQ 非耐落 志精 A - 10 DVD (W251BLQ) -
Page 47: Dvd (W253Blq / W253Bzq
DVD (W253BLQ / W253BZQ) Figure 7 DVD ( W253BLQ / W253BZQ 非耐落 志精 DVD (W253BLQ / W253BZQ) A - 11... -
Page 48: Dvd (W258Bzq
DVD (W258BZQ) Figure A - 8 DVD (W258BZQ) 非耐落 志精 A - 12 DVD (W258BZQ) -
Page 49: Lcd (W251Blq
LCD (W251BLQ) Figure A - 9 LCD (W251BLQ) 頭厚 非耐落 LCD (W251BLQ) A - 13... -
Page 50: Lcd (W253Blq
LCD (W253BLQ) Figure A - 10 LCD (W253BLQ) A - 14 LCD (W253BLQ) -
Page 51: Lcd (W253Bzq
LCD (W253BZQ) Figure A - 11 LCD (W253BZQ) LCD (W253BZQ) A - 15... -
Page 52: Lcd (W258Bzq
LCD (W258BZQ) Figure A - 12 LCD (W258BZQ) 頭厚 非耐落 A - 16 LCD (W258BZQ) - Page 53 Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the W251BLQ / W253BLQ / W253BZQ / W258BZQ notebook’s PCB’s. The fol- lowing table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page...
-
Page 54: Schematic Diagrams
Schematic Diagrams System Block Diagram W24XBL/BZ System Block Diagram CLICK BOARD VDD3,VDD5 6-71-W2402-D02 (Reserve W25XBLQ/W25XBZQ/W27XBZQ) POWER SWITCH BOARD 5V,3V,5VS,3.3VS POWER SWITCH+HOTKEY X 3 1.5VS,1.1VS CRT Connector AMD FUSION APU 6-71-E51QS-D02 Ontario FT1 AUDIO BOARD APU_CORE,NB_CORE HDMI Connector USB+EARPHONE+EXT.MIC 413-BALL 6-71-W25L8-D01 19mmX19mm BGA 1066MHz 1.5V,0.75VS... -
Page 55: Ontario Mem & Pcie I/F, Ap
Schematic Diagrams Ontario MEM & PCIE I/F, AP ONTARIO MEM & PCIE I/F, AP MEM_AD DR[15:0] MEM_DATA[63:0] 5,6 MEM_ADDR0 MEM_DATA0 M_ADD0 M_DATA0 MEM_ADD R1 ONTARIO (2.0) MEM_DATA1 M_ADD1 M_DATA1 MEM_ADD R2 PART 1 OF 5 MEM_DATA2 M_ADD2 M_DATA2 MEM_ADD R3 D 18 MEM_DATA3 M_ADD3... -
Page 56: Ontario Display/Clk/Misc
Schematic Diagrams Ontario Display/CLK/MISC ONTARIO DISPLAY/CLK/MISC 1.8VS CPU_SVC 1K_04 ANALOG/DISPLAY/MISC 1K_04 CPU_SVD ONDP_CALR 150_1%_04 HDMIB_D2BP TDP1_TXP0 DP_ZVSS 300_1%_04 APU_PWRGD HDMIB_D2BN TDP1_TXN0 ON_BLON *10mil_short_04 DP_BLON BLON ON_DIGON R598 *10mil_short_04 TDP1_TXP1 DP_DI GON NB_ENAVDD 13 HDMIB_D1BP ON_VARY TDP1_TXN1 DP_VARY_BL ON_VARY 12 HDMIB_D1BN 3.3V HDMI ON_BLON... -
Page 57: Ontario Power & Decoupling
Schematic Diagrams Ontario Power & Decoupling ONTARIO POWER & DECOUPLING 1.8VS VDDCR_CPU VDDCR_CPU_1 VDD_18_1 *1u_6.3V_X5R_04 VSS_1 ONTARIO (2.0) VSS_50 10u_6.3V_X5R_06 1u_6.3V_X5R_04 VDDCR_CPU_2 VDD_18_2 VSS_2 PART 5 OF 5 VSS_51 1u_6.3V_X5R_04 *1u_6.3V_X5R_04 0.1u_10V_X5R_04 VDDCR_CPU_3 VDD_18_3 VSS_3 VSS_52 VDDCR_CPU_4 VDD_18_4 VSS_4 VSS_53 VDDCR_CPU_5 VDD_18_5 VSS_5... -
Page 58: Nagua Ddr3 So-Dimms A
Schematic Diagrams NAGUA DDR3 SO-DIMMS A SO-DIMM A INAGUA DDR3 SO-DIMMS A MEM_ADDR[15:0] MEM_DATA[63:0] 2,6 JDIMM1A MEM_ADDR0 MEM_DATA0 MEM_ADDR1 MEM_DATA1 MEM_ADDR2 MEM_DATA2 MEM_ADDR3 MEM_DATA3 MEM_ADDR4 MEM_DATA4 MEM_ADDR5 MEM_DATA5 MEM_ADDR6 MEM_DATA6 JDIMM1B MEM_ADDR7 MEM_DATA7 MEM_ADDR8 MEM_DATA8 MEM_ADDR9 MEM_DATA9 1.5V MEM_ADDR10 MEM_DATA10 A10/AP DQ10 MEM_ADDR11... -
Page 59: Nagua Ddr3 So-Dimms B
Schematic Diagrams NAGUA DDR3 SO-DIMMS B SO-DIMM B INAGUA DDR3 SO-DIMMS B MEM_ADDR[15:0] MEM_DATA[63:0] 2,5 JDIMM2A MEM_ADDR0 MEM_DATA0 MEM_ADDR1 MEM_DATA1 MEM_ADDR2 MEM_DATA2 MEM_ADDR3 MEM_DATA3 MEM_ADDR4 MEM_DATA4 MEM_ADDR5 MEM_DATA5 MEM_ADDR6 MEM_DATA6 JDIMM2B MEM_ADDR7 MEM_DATA7 MEM_ADDR8 MEM_DATA8 MEM_ADDR9 MEM_DATA9 1.5V MEM_ADDR10 MEM_DATA10 A10/AP DQ10 MEM_ADDR11... -
Page 60: Hudson Pcie/Pci/Clock/Fch
AD12 R253 2K_1%_04 *20K_04 20K_04 C LK_C ALRN CB E3# 1.1VS AG10 W240BL/W240BZ FR AME# GPIO31 DEVS EL# W251BLQ/W251BZQ AL10 GPIO30 PC IE _R CL KP IRDY# AF10 PC IE _R CL KN TRDY# AE10 W270BZQ R259 R258 1.8VS DISP _C LK P... -
Page 61: Hudson Gpio/Usb/Strap
Schematic Diagrams HUDSON GPIO/USB/STRAP HUDSON GPIO/USB/AUDIO/STRAP U19D R692 *10mil_s hort_04 SWI# R730 *0_04 PC IE_RST2#/GEVENT4# USBC LK/14 M_25M_ 48M_OSC R690 *0_04 3.3V 13,20,22 LID_SW# RI#/GEVENT22 # USB_RCOMP R272 11K_1%_04 SPI_CS3 #/GBE _STAT1/GEVENT21 # USB_ RC OMP SL P_S3# 11,12,20,23 SUSB# R273 RSMRST# *22K_04... -
Page 62: Hudson Sata/Debug Io/Spi
Schematic Diagrams HUDSON SATA/DEBUG IO/SPI HUDSON SATA/DEBUG IO/SPI U19B HUDSON - M3L Part 2 of 5 AK19 AL14 SATA_TX0P SD_CLK/SCLK_0 /GPIO7 3 SATATXP0 AM19 AN14 SATA_TX0N SD_ CMD/SLOAD_0 /GPIO7 4 SATATXN0 AJ12 SD_CD# /GPIO7 5 AL20 AH12 SATARXN0 SATA_RX0N SD_WP/GPIO7 6 AN20 AK13 SATA_RX0P... -
Page 63: Hudson Power Decoupling
Schematic Diagrams HUDSON Power Decoupling HUDSON POWER DECOUPLING 3.3VS 1.1VS U19C Part 3 of 5 HUDSON-M3L 102mA AB17 1007mA U19E VDDIO_ 33_PCIGP_ 1 VD DCR _1 1_1 AB18 VDDIO_ 33_PCIGP_ 2 VD DCR _1 1_2 HUDSON-M3L C494 C495 C496 C493 C499 C500 C501... -
Page 64: Powergood/Tpm
Schematic Diagrams POWERGOOD/TPM 3.3V U22B 74LVC08PW 1.1V_PWRGD SY S_RST# C848 *0.1u_16V_Y 5V_04 3.3V PWRGD_VCORE 3.3V 3.3V R774 3.3V U22A U22C 10K_04 SB_PWROK R775 *10mil_short 74LVC08PW U22D 74LVC08PW R364 *10mil_short 1.8V_PWRGD SB_PWRGD 8 74LVC08PW R365 *10mil_short SYS_PWROK ALL_SYS_PWRGD 13,20 R776 *0_04 25,28 DDR1.5V_PWRGD C841... -
Page 65: Anx3110 Asic
Schematic Diagrams ANX3110 ASIC ANX3110 ASIC 3.3VS C885 C886 C887 C888 C889 C884 2.2u_6.3V_X5R_06 0.1u_10V_X5R_04 0.1u_10V_X5R_04 0.1u_10V_X5R_04 0.01u_16V_X7R_04 0.01u_16V_X7R_04 1.2VS C890 C891 C893 C894 C892 0.1u_10V_X5R_04 0.1u_10V_X5R_04 2.2u_6.3V_X5R_06 0.01u_16V_X7R_04 0.01u_16V_X7R_04 1.2VS 3.3VS C896 C895 0.1u_10V_X5R_04 2.2u_6.3V_X5R_06 3.3VS Sheet 12 of 33 R856 R835 1M_04 3.3VS... -
Page 66: Lvds/Inverter
Schematic Diagrams LVDS/Inverter 3.3VS PANEL CONNECTOR J_LCD1 For single channel R577 4.7K_04 R578 4.7K_04 J_LCD2 For dual channel EDID Mode VIN_LCD J_LCD1 VIN_LCD 80mils LVDS_DATA LVDS_CLK J_LCD2 LVDS_DATA R_BRIGHTNESS R857 0_04 LVDS_CLK BRIGHTNESS 12,20 INV_BLON R_BRIGHTNESS 3/10 R858 *0_04 XLT_BLON_PWM 12 RLVDS-LCLKN RLVDS-L2N INV_BLON... -
Page 67: Hdmi/Crt
Schematic Diagrams HDMI/CRT HDMI PORT 5VS_HDMI * BAV99 RECTIF IER RB551V-30S2 * BAV99 RECTIFIER For ESD *BAV99 RECTIFIER HDMIB_D2BP HDMIB_DATA2P C829 0.1u_10V_X7R_04 R393 HDMIB_D2BN HDMIB_DATA2N C830 0.1u_10V_X7R_04 5VS_HDMI 1_04 5VS_HDMI HDMIB_D1BP C831 0.1u_10V_X7R_04 HDMIB_DATA1P J_HDMI 1 HDMIB_D1BN C832 0.1u_10V_X7R_04 HDMIB_DATA1N R579 2.2K_04 R580... -
Page 68: Ccd/3G
Schematic Diagrams CCD/3G MINI CARD 3G(Port 6) Layout Show "3.5G(HSDPA)" Note 3G_3.3V J_3G1 60mils WAKE# 3.3VAUX_0 COEX1 1.5V_0 UIM_PWR COEX2 UIM_PWR UIM_DATA C592 C593 UIM_DATA UIM_CLK C594 CLKREQ# UIM_CLK UIM_RST *0.1u_16V_Y5V_04 *220u_4V_V_B REFCLK- UIM_RESET UIM_VPP *0.1u_16V_Y5V_04 REFCLK+ UIM_VPP GND0 GND1 GND5 GND2 GND6... -
Page 69: Cardreader/Lan Rtl8402
Schematic Diagrams CardReader/LAN RTL8402 RTL8402 com m and LAN (RTL8402) From PCH LAN_25MHz meet realtek Freq tolerance 50ppm CARD_3V3 R717 0. 2_06 VC C_CARD R114 *0_04 LAN_25MHz 7 SD_D0 R296 *10mil_short_04 SD _D 0_R Crystal 8045 & 3225 Co-lay R185 SD_D1 SD _D 1/MS_CLK_R ·íÃö³¬host¹q·½/ CARD ©Þ´¡®É,VCC_CARD... -
Page 70: Mini Pcie/Sata Hdd/Odd
Schematic Diagrams Mini PCIE/SATA HDD/ODD MINI CARD (WLAN,Port 5) 20 mil 3.3V Layout Show "WLAN(Wim ax, 802.11N)" Note C847 0.1u_16V_Y 5V_04 J_MINI1 PCIE_WAKE# R509 *0_04 8,16 PCIE_WAKE# WAKE# 3.3VAUX_0 COEX1 1.5V_0 20 mil R451 10K_04 3.3V COEX2 UIM_PWR VDD3 R452 *0_04 BT_ON 7,21... -
Page 71: Audio Codec Vt1802P
Schematic Diagrams Audio Codec VT1802P AUDIO CODEC C o m p o n e n t . ALC269 VB2 Layout note: VT1802P EMI Require GND and AUDG spa ce is For 1.5V HDA Link. 60mils ~ 100mils R460 *0_04 1.5VS C680 C681 L109... -
Page 72: Usb 3.0/Usb Charge
Schematic Diagrams USB 3.0/USB Charge USB PORT Charge Power ¥i¤ä´©²Ä¤G-ÓUSB2.0 3.4A Port R3.7 WITH VPRO --> VDD5_USBCHG USBVCC1 VDD5 WITHOUT VPRO --> VDD5 VDD5 100 mil 100 mil *10K_04 C 19 U SB_PN0 USB_PN0_R USB_PN0 DM_O DM_IN * 10u_10V_Y5V_08 TPS254X_ILIM_SEL U SB_PP0 USB_PP0_R USB_PP0... -
Page 73: Kbc-Ite It8518
7,11 LPC_FRAME# LFRAME# KSI5 KB-SI6 KB-SI6 K/B MATRIX 7,11 SERIRQ SERIRQ KSI6 R786 *10mil_short_04 KB-SI7 KB-SI7 1.65V W251BLQ(9W) 10K / 10K 7,12 EC_RST# LPCRST#/WUI4/GPD2( PU ) KSI7 KBC_WRESET# KB-SO0 KB-SO0 2.5V W251BZQ(18W) 2.49K / 7.5K WRST# KSO0/PD0 KB-SO1 KB-SO1 Sheet 20 of 33... -
Page 74: Led/Mdc/Bt
Schematic Diagrams LED/MDC/BT 3V_BT Bluetooth J_BT1 3.3V USB_PN6 USB_PP6 R536 17,20 BT_DET# BT_EN# 47K_04 3.3V *87212-06G0 R537 *0_04 7,17 BT_ON BT_DET# C757 R538 3.3V 3V_BT *180p_50V_NPO_04 *10K_04 R539 50mil 50mil BT_EN# *15mil_short_06 C758 C759 *MTN7002ZHS3 17,20 BT_EN *10u_10V_Y5V_08 Sheet 21 of 33 LED/MDC/BT 3.3VS 3.3VS... -
Page 75: Fan/Tp/Multi Con
Schematic Diagrams Fan/TP/Multi CON FAN CONTROL Audio/B CONN.(Port 2) 5VS_FAN FON# FON# VOUT CPU_FAN VSET R733 *0_06 *AX995B USBVCC1 1.1A 60mils 2nd Source PN:APE8874 R734 0_06 C778 0.01u_16V_X7R_04 AX995B(SOT23-6) & APE8872 Co-Layout J_AUDIO1 MIC1-R M 5VS_FAN MIC1-R M MIC1-L M FON# MIC1-L M HEADPHONE-R... -
Page 76: 5Vs/3.3Vs/1.8Vs/1.5Vs/1.1Vs
Schematic Diagrams 5VS/3.3VS/1.8VS/1.5VS/1.1VS VIN1 3.3V VIN1 C779 VIN1 R563 100K_04 0.1u_50V_Y 5V_06 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 *0.01u_16V_X7R_04 DD_ON 19,20,24 DD_ON_LATCH DD_ON "L" TO PR210 1K_04 PR18 1K_04 M_BTN# M_BTN# PWR_SW# PWR_SW# 20 "H" FROM EC PR211 1K_04 AP_ON INSTANT-ON 10K_04 VDD3 P2808B0 VDD3 VDD3 VDD3... -
Page 77: Power Vdd3, Vdd5
Schematic Diagrams Power VDD3, VDD5 VREF PR21 *0_04 PR22 *10mil_short_04 PC28 1u_10V_Y 5V_06 PR23 PR 24 EN_3V EN_5V PC29 100K_04 120K_04 PC30 1000p_50V_X7R_04 1000p_50V_X7R_04 VREG3 PR25 *10K_04 PC32 PC31 PC33 SY S5V LDO3 PC34 PC37 PC38 4.7u_25V_X5R_08 PQ14 1u_10V_Y 5V_06 PC36 4.7u_25V_X5R_08 P1203BV... -
Page 78: Power 1.5V/0.75V
Schematic Diagrams Power 1.5V/0.75V PD 12 R B0540S2 VDD Q uP6163 PC69 PQ23 10u_10V_Y5V_08 MDS1526 PC 70 0.1u_10V_X7R_04 1.5V VLDOIN VBST VDDQ PR47 *15mil_short_06 2.2UH _10*10*4.0 VTT_MEM DR VH 1.5V *OPEN_2A PR48 *OPEN_8A PC 71 PC72 PC 73 VTTGND PR50 *15mil_short_06 10u_10V_Y 5V_08 *5.1_06... -
Page 79: Power 1.1V/1Vs
Schematic Diagrams Power 1.1V/1VS PR70 EN _1.1V OCP=10uA X RILIM / Rdson PD14 100K_1%_04 PC88 PC87 PC90 PQ30 PC 89 RB0540S2 SU SC PR72 *62K_1%_04 PR71 10K_1%_04 23,28 SU SC MTN7002ZH S3 0.1u_10V_X7R_04 PQ31 PR197 62K_1%_04 PC91 P1203BV 19, 23,25 DD _ON# 0.1u_10V_X5R _04 1.1V... -
Page 80: Power 1.8Vs
Schematic Diagrams Power 1.8VS OCP=10uA X RILIM / Rdson PR40 EN_1.8V PR41 *15K_1%_04 PD10 PC52 PC53 PC54 100K_1%_04 PQ20 PC56 *RB0540S2 SUSB PR42 10K_1%_04 23,25,26 SUSB MTN7002ZHS3 *0.1u_10V_X7R_04 PQ21A *AP6901GSM PC57 0.01u_16V_X7R_04 PC58 *uP6127 1.8VS *0.1u_10V_X7R_04 V1.8S *TMPC0603H-4R7M-Z01 3.3V 1.8VS Sheet 27 of 33 VOUT PR43... -
Page 81: Apu Core/Nb Core
Schematic Diagrams APU Core/NB Core Offset & OFS/VFIXEN VFIX Droop V DDCR_ CP U PR109 +3.3V 10_04 NB_VDDCR C789 0.1u_10V_X5R_04 C790 *0.01u_16V_X7R_04 CPU_VDDNB_RUN_FB_H 3 Metal VID Codes CPU_VDDNB_RUN_FB_L 3 Output Noise issue 3/9 C791 0.1u_10V_X5R_04 PC140 PR110 PR111 10_06 PC137 SGND5 SGND5 10_04... -
Page 82: Charger, Dc In
Schematic Diagrams Charger, DC In # Charge Current 1.5A PR223 *10m il_short_04 PR224 *470K_04 # Charge Voltage 12.6V CHARGER PQ48 P2003EVG PC235 0. 1u_50V_Y 5V_06 6-20-B3Z40-004 for 30W 6-20-B3410-003 for 65W ¾aªñJBATTA1 V_BAT DC 069HS-2-PA9T-1 PQ65A TPCS JACK1 PL10 PQ50 PR153 PD1503Y VS PL15... -
Page 83: Click Board
Schematic Diagrams Click Board CLICK BOARD CLED_ACIN CLED _BAT_CH G CLED_PWR CLED _BAT_FULL C R3 220_04 0.1u_16V_Y 5V_04 *0.1u_16V_Y 5V_04 *0.1u_16V_Y 5V_04 220_04 220_04 220_04 POWER ON C5VS C5VS CVDD 3 BAT LED CD27 CD26 CGND CGND CGN D CJ_TP2 CJ_TP3 CJ_TP1 KPB-3025Y SGC... -
Page 84: Audio Board/Usb
Schematic Diagrams Audio Board/USB USB PORT AR735 *0_06 A_USBVCC A_USBVCC2 HCB1608KF-121T25 60 mil A_USBVCC AC10 50mils A_5V *100u_6.3V_B_A FLG# VOUT1 50mils 22u_6.3V_X5R_08 0.1u_16V_Y5V_04 VIN1 VOUT2 AJ_USB1 *10mil_short_04 AGND VIN2 VOUT3 *0.1u_16V_Y 5V_04 0.1u_16V_Y5V_04 AL122 10u_10V_Y5V_08 AUSB_PN2 AUSB_PN2_R DATA_L AUSB_PP2 AUSB_PP2_R RT9715BGS DATA_H AGND... -
Page 85: Power Switch & Lid Board
Schematic Diagrams Power Switch & LID Board POWER SW & LED & HOT KEY S_3.3VS S_3.3V POWER LID SWITCH IC SWITCH S_3.3VS S_3.3V *BAV99 RECTIFIER S_3.3V S_3.3VS S_3.3V SJ_SW1 220_04 20mil 100K_04 SJ_SW2 20mil 20mil 20mil SM_BTN# Z4301 SWEB_WWW# SLID_SW# SWEB_EMAIL# SM_BTN# SLID_SW#... -
Page 86: External Odd Board
Schematic Diagrams External ODD Board ODD BOARD QJ_ODD2 QJ_ODD1 QJ_SATA_TXP1 QJ_SATA_TXN1 QJ_SATA_RXN1 QJ_SATA_RXP1 Sheet 33 of 33 QGND QGND QJ_ODD_DETECT# External ODD Q_5VS Q_5VS QJ_SATA_ODD_DA# Board 1-162-100562 242001-1 P IN P IN QGND QGND GND1 ~2=WG ND GND1 ~3=Q GND 6-21-14010-013 6-21-13A00-013 6-21-14020-013... -
Page 87: Updating The Flash Rom Bios
Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files... -
Page 88: Use The Flash Tools To Update The Bios
BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS. - Page 89 www.s-manuals.com...
