Summary of Contents for Clevo W25CSV series

  • Page 1 W25CSV...
  • Page 3 Preface Notebook Computer W25CSV Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 Preface About this Manual This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the W25CSV series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: System Startup

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Part Lists ..........A-1 Overview ..................1-1 Part List Illustration Location ............A-2 Specifications ..................1-2 Top ....................A-3 External Locator - Top View with LCD Panel Open ......1-4 Bottom ................... A-4 External Locator - Front & Right Side Views .........1-5 HDD ....................
  • Page 12 Preface Lynx 8/9 ..................B-23 Lynx 9/9 ..................B-24 Intel LAN i217LM ............... B-25 LAN Transformer ................. B-26 Card Reader RTS5229 ..............B-27 USB Port, E-SATA ..............B-28 3G, HDD, ODD ................B-29 WLAN, CCD, TPM ..............B-30 KBC-ITE IT8587 ................. B-31 AUDIO CODEC ALC269 ............

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the W25CSV series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri- vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Audio Intel® Core™ i7 Processor High Definition Audio Compliant Interface i7-4600M (2.90GHz) 2 * Built-In Speakers 4MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 37W Built-In Microphone  Intel® Core™ i5 Processor Security i5-4330M (2.80GHz), i5-4300M (2.60GHz) Latest Specification Information BIOS Password 3MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 37W The specifications listed here are correct at the...
  • Page 15 Introduction Interface Dimensions & Weight Three USB 3.0 Ports (Including one AC/DC Powered USB 374mm (w) * 250mm (d) * 35.5mm (h) port) 2.33kg with ODD & 62.16WH Battery One USB 2.0 Port One eSATA Port One HDMI-Out Port One Headphone and S/PDIF Out Combo Jack One Microphone-In Jack One RJ-45 LAN Jack One External Monitor Port...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera (Optional) 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated in red. 3. LCD 4. Power Button 5.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicator 2. Touchpad Switch FRONT VIEW Figure 3 Right Side View 1. Microphone-In RIGHT SIDE VIEW Jack 2. Headphone and S/PDIF Out Combo Jack 3. USB 2.0 Port 4.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. External Monitor Port LEFT SIDE VIEW 3. RJ-45 LAN Jack 4. e-SATA Port 5. Vent 6. Powered USB 3.0 Port 7. 2 * USB 3.0 Ports 8.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Docking Port 3. Vent 4. Component Bay Cover 5. Hard Disk Bay Cover 6. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use.

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. PI3L720ZHE 2. TUSB7320 3. ITE IT8518E 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Platform Controller 3. CMOS Battery 4. Audio Codec VT1802P 5. Memory Slots DDR3 SO-DIMM 6. Mini-Card Connector (WLAN Module) 7. Mini-Card Connector (3G Module) 8.

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. e-SATA Port 2. Powered USB 3.0 Port 3. USB Port 3.0 4. Keyboard Cable Connector 5. Audio Board Connector 6. Touchpad Cable Connector 1 - 10 Mainboard Overview - Top (Connectors)

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. HDD Connector 2. Fan Cable Connector 3. Multi-in-1 Card Reader 4. HDMI-Out Port 5. RJ-45 LAN Jack 6. External Monitor Port 7. DC-In Jack 8. Microphone Cable Connector 9.
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the W25CSV series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Keyboard: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide the latch and hold it 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a in place.

  • Page 30: Removing And Installing The Hard Disk Drive

    Disassembly Removing and Installing the Hard Disk Drive Figure 2 HDD Assembly Hdd Removal Procedure Removal The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm a. Remove the screws. (h).
  • Page 31 Disassembly 5. Raise the plastic tab Figure 3 6. Slide the hard disk assembly in the direction of arrow (Figure 3d HDD Assembly 7. Remove the HDD assembly from the bay. Removal (cont’d.) 8. Remove the screws & and the adhesive cover from the hard disk (Figure 3f 9.

  • Page 32: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 4 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L Up to 1600 MHz. The main memory can be expanded up to 16GB. The SO-DIMM modules supported are 1024MB and 2048MB DDR3L Modules.
  • Page 33 Disassembly 4. The RAM modules will be visible at point on the mainboard. Figure 5 5. Gently pull the two release latches ( & ) on the sides of the memory socket in the direction indicated by the RAM Module arrows (Figure 5b).

  • Page 34: Removing And Installing A Processor

    Disassembly Removing and Installing a Processor Figure 6 Processor Removal Procedure Processor Removal 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - 2. The CPU heat sink will be visible at point (Figure 6a).
  • Page 35 Disassembly 7. Turn the release latch towards the unlock symbol to release the CPU (Figure 7d). Figure 7 8. Carefully (it may be hot) lift the CPU up and out of the socket (Figure 7e). Processor Removal 9. Reverse the process to install a new CPU. (cont’d) 10.
  • Page 36 Disassembly Processor Installation Procedure Figure 8 Processor 1. Insert the CPU (Figure 8a), pay careful attention to the pin alignment, it will fit only one way (DO NOT FORCE Installation IT!), and turn the release latch towards the lock symbol (Figure 8b).

  • Page 37: Removing The 3G Module

    Disassembly Removing the 3G Module Figure 9 3G Module Removal 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - 2. Carefully disconnect the cables & , and then remove the screw (Figure a.

  • Page 38: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 10 Wireless LAN 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. Carefully disconnect the cables , and then remove the screw (Figure 10a)

  • Page 39: Wireless Lan, Combo, 3G & Lte Module Cables

    Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 40: Removing The Optical Device

    Disassembly Removing the Optical Device Figure 11 ODD Removal 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - 2. Remove the screw at point , and use a screwdriver to carefully push out the optical device at point a.

  • Page 41: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 12 Keyboard Removal 1. Turn off the computer, remove the battery (page 2 - 5), and the component bay cover (page 2 - 2. Remove screws from the bottom of the computer and carefully push out at point a.

  • Page 42: Removing And Installing The Mainboard

    Disassembly Removing and Installing the Mainboard Figure 13 Mainboard Module Mainboard Removal Procedure Removal 1. Turn off the computer, remove the battery (page 2 - 5), HDD (page 2 - 6), RAM (page 2 - 8), CPU (page 2 - 10), (page 2 - 16), and keyboard...
  • Page 43 Disassembly Mainboard Installation Procedure Figure 14 1. Insert the mainboard by holding it at an angle and making sure that the ports are aligned with the bottom case Mainboard Module (Figure 14a). Installation 2. Tighten the screws (Figure 14b) on the mainboard. 3.

  • Page 44: Removing The Lcd

    Disassembly Removing the LCD Figure 15 LCD Removal 1. Turn off the computer, remove the battery (page 2 - 5), HDD (page 2 - 6), RAM (page 2 - 8), CPU (page 2 - 10), and keyboard (page 2 - 17).

  • Page 45: Removing The Speaker

    Disassembly Removing the Speaker Figure 16 Speaker Module 1. Turn off the computer, remove the battery (page 2 - 5), component bay cover (page 2 - 8), keyboard (page 2 - Removal and mainboard (page 2 - 18). 2. The speaker module will be visible at point on the mainboard (Figure 16a).
  • Page 46 Disassembly 2 - 22...

  • Page 47: Part Lists

    Appendix A:Part Lists This appendix breaks down the W25CSV series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 48: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 page A - 6 page A - 7 A - 2...

  • Page 49: Top

    Figure A - 1 Top A - 3...

  • Page 50: Bottom

    Bottom (長騰) Figure A - 2 Bottom 非耐落 使用 A - 4 Bottom...

  • Page 51: Hdd

    Figure A - 3 HDD A - 5...

  • Page 52: Dvd

    Figure A - 4 A - 6 DVD...

  • Page 53: Lcd

    Figure A - 5 頭厚 LCD A - 7...
  • Page 54 A - 8...

  • Page 55: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the W25CSV notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1 System Block Diagram - Page B - 2 Lynx 4/9 - Page B - 19 5VS, 3VS, 3.3VM, 5VM - Page B - 36...

  • Page 56: System Block Diagram

    Schematic Diagrams System Block Diagram MAIN BOARD W25CSV System Block Diagram 6-71-W2W50-D01 SHEET 2~40 5VS,3VS,3.3VM,5VM SHEET 35 AUDIO BOARD USB2.0+HP+MIC+SPK+RJ11 1.05V series 6-71-W2W58-D01 SHEET 41 DVI to Docking <7" Haswell SHEET 36 Memory Termination SHEET 34 POWER SWITCH BOARD PROCESSOR POWER SWITCH DDR3 /1.35 SHEET 9,10...

  • Page 57: Processor 1/7

    Schematic Diagrams Processor 1/7 Haswell rPGA Processor 1/7 ( DMI,PEG,FDI ) +VCCIOA_OUT U25A Haswell rPGA EDS 20 mil DMI Signal Group PEG_IRCOMP 24.9_1%_04 PEG_RCOMP Zdiff = 85 Ohm ±10% (5 / 5.5 ml) PEG_RXN_0 DMI_TXN0 DMI_RXN_0 PEG_RXN_1 DMI_TXN1 DMI_RXN_1 PEG_RXN_2 DMI_TXN2 DMI_RXN_2 PEG_RXN_3...

  • Page 58: Processor 2/7

    Schematic Diagrams Processor 2/7 Processor Pullups/Pull downs Haswell Processor 2/7 ( CLK,MISC,JTAG ) +VCCIO_OUT H_PROCHOT# R168 62_04 1.05VS +VCCST H_CPUPW RGD_R R436 10K_04 C384 *0.1u_10V_X5R_04 R417 *0_04 C380 C381 *22u_6.3V_X5R_08 *22u_6.3V_X5R_08 TRACE WIDTH 10MIL, LENGTH <500MILS U25B Haswell rPGA EDS DDR3 Compensation Signals SKTOCC# AP32...

  • Page 59: Processor 3/7

    Schematic Diagrams Processor 3/7 Haswell Processor 3/7 ( DDR3 ) 6-86-27988-003 PZ98927-3641-01F 6-86-27988-003 PZ98927-3641-01F 6-86-27988-001 47989-0732 6-86-27988-001 47989-0732 6-86-27988-004 PZ98821-362B-01H 6-86-27988-004 PZ98821-362B-01H Data Signal Group Zdiff = 50 Ohm ±10% (MS 5/SL 5.5 ml) Haswell rPGA EDS U25C Haswell rPGA EDS U25D M_A_DQ[63:0] M_B_DQ[63:0]...

  • Page 60: Processor 4/7

    Schematic Diagrams Processor 4/7 Haswell Processor 4/7 ( POWER ) V_VDDQ_DIMM PROCESSOR CORE POWER +V_VCCDDQ V_VDDQ_DIMM *OPEN-5MM C174 C343 C342 ICCMAX Maximum Processor SV 48 +VCCIN Haswell rPGA EDS U25E 0.1u_10V_X7R_04 0.1u_10V_X7R_04 *100p_50V_NPO_04 Short C102 AA26 AA28 0.1u_10V_X5R_04 0.1u_10V_X5R_04 AA34 EMI Require RSVD AA30...

  • Page 61: Processor 5/7

    Schematic Diagrams Processor 5/7 Haswell EDP/HDMI 5/7 ( GRAPHICS ) 3.3VS R413 R409 *100K_1%_04 *100K_1%_04 DP_AUXN DP_AUXN DP_AUXP DP_AUXP R411 R410 *100K_1%_04 Sheet 6 of 44 *100K_1%_04 Processor 5/7 U25H Haswell rPGA EDS DP_AUXN DK_DVI_TXN2 DDIB_TXBN_0 EDP_AUXN +VCCIOA_OUT 3.3VS DP_AUXP DK_DVI_TXP2 DDIB_TXBP_0 EDP_AUXP...

  • Page 62: Processor 6/7

    Schematic Diagrams Processor 6/7 Haswell Processor 6/7 ( GND ) Haswell rPGA EDS U25F Haswell rPGA EDS U25G AK34 AL10 AL11 AL12 AL14 AL15 AL17 AL18 AL20 AL21 AL23 AA11 AA25 AA27 AA31 AA29 AB10 AA33 AA35 AM10 AM13 AC25 AM16 AC27 AM19...

  • Page 63: Processor 7/7

    Schematic Diagrams Processor 7/7 Haswell Processor 7/7 ( RESERVED ) CFG Straps for Processor PCI EXPRESS STATIC LANE REVERSAL FOR ALL PEG PORTS (Default) CFG2 1: (DEFAULT)NORMAL OPERATION; LANE# DEFINITION MATCHES 0: LANE REVERSAL U25I Haswell rPGA EDS CFG2 R146 *1K_04 RSVD_TP RSVD_TP...

  • Page 64: Ddr3 So-Dimm_0

    Schematic Diagrams DDR3 SO-DIMM_0 SO-DIMM A H=5.2mm JDIMM1A M_A_A[15:0] M_A_DQ[63:0] M_A_A0 M_A_DQ0 JDIMM1B M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ2 V_VDDQ_DIMM M_A_A3 M_A_DQ3 M_A_A4 M_A_DQ4 M_A_A5 M_A_DQ5 VDD1 VSS16 C123 *10p_50V_NPO_04 M_A_A6 M_A_DQ6 VDD2 VSS17 M_A_CLK_DDR0 M_A_CLK_DDR#0 M_A_A7 M_A_DQ7 VDD3 VSS18 M_A_A8 M_A_DQ8 VDD4 VSS19 C126 *10p_50V_NPO_04...

  • Page 65: Ddr3 So-Dimm_1

    Schematic Diagrams DDR3 SO-DIMM_1 SO-DIMM B CHANGE TO STANDARD H=9.2mm JDIMM2A M_B_B[15:0] M_B_DQ[63:0] M_B_B0 M_B_DQ0 JDIMM2B M_B_B1 M_B_DQ1 C120 *10p_50V_NPO_04 M_B_B2 M_B_DQ2 V_VDDQ_DIMM M_B_CLK_DDR0 M_B_CLK_DDR#0 M_B_B3 M_B_DQ3 M_B_B4 M_B_DQ4 C124 *10p_50V_NPO_04 M_B_B5 M_B_DQ5 VDD1 VSS16 M_B_CLK_DDR1 M_B_CLK_DDR#1 M_B_B6 M_B_DQ6 VDD2 VSS17 M_B_B7 M_B_DQ7...

  • Page 66: Ps8625

    Schematic Diagrams PS8625 RTD_PLVDD_EN RTD_PLVDD_EN ENBLT ENBLT 3.3VS 3.3VS PANEL_PW M HCB1005KF-121T20 HCB1005KF-121T20 BCIHP0420TB-2R2M HCB1005KF-121T20 PANEL_PW M 3.3VS VDDIO 3.3VS VDDIOX SW _OUT VDD12 VDDRX R359 R360 C321 C292 C319 C287 C285 C289 10K_04 10K_04 (B) LVDS 0.47u_10V_Y5V_04 1u_6.3V_X5R_04 0.47u_10V_Y5V_04 4.7u_6.3V_X5R_06 4.7u_6.3V_X5R_06 1u_6.3V_X5R_04...

  • Page 67: Lvds, Inverter

    Schematic Diagrams LVDS, Inverter 3.3V R365 100K_04 PANEL CONNECTOR 3.3V (SB LVDS) EDP;LVDS 3.3VS R361 0_04 BLON U18A (SB GPIO) 74LVC08PW U18B J_LCD2 R362 *0_04 74LVC08PW SB_BLON BLON1 3.3V LVDS-UCLKN LVDS-UCLKP R366 0_04 BLON2 LVDS-U1N LVDS-U2N BKL_EN EDP;LVDS LVDS-U1P LVDS-U2P PLVDD 2.2K_04 2.2K_04...

  • Page 68: Hdmi

    Schematic Diagrams HDMI HDMI PORT HDMI_5VS For ESD M021015 FOR EMI R461 R484 C418 0.1u_10V_X7R_04 HDMI_DATA0P_C TMDS_DATA2-R R511 0_04 TMDS_DATA2 2.2K_04 2.2K_04 HDMI_DATA0P IN_D1+ OUT_D1+ C417 0.1u_10V_X7R_04 HDMI_DATA0N_C TMDS_DATA2#-R R508 0_04 TMDS_DATA2# HDMI_DATA0N IN_D1- OUT_D1- C428 0.1u_10V_X7R_04 HDMI_DATA1P_C TMDS_DATA1-R R505 0_04 TMDS_DATA1 *BAV99 RECTIFIER...

  • Page 69: Crt

    Schematic Diagrams TPD7S019 CRT Conn. CRT PORT Docking M021015 3.3VS CRT_5VS 2.2K_04 Z1301 3.3VS RB551V-30S2 2.2K_04 MTDK5S6R NB_DAC_DDCADATA DDC_DATA INT. CRT PORT 2.2K_8P4R_04 MTDK5S6R NB_DAC_DDCACLK DDC_CLK NB_DAC_DDCADATA DDCDATA DDC_IN1 DDC_OUT1 MTDK5S6R DK_DAC_DDCADATA NB_DAC_DDCACLK DDCLK DK_DAC_DDCADATA DDC_IN2 DDC_OUT2 DK_EN FUNCTION OUTPUT NB_DAC_HSYNC CRT_HSYNC 33_04...

  • Page 70: Lynx 1/9

    Schematic Diagrams Lynx 1/9 RTCVCC Lynx Point - M (HDA,JTAG,SATA) QM87/HM87 20mil 20mil BAT54CS3 6-07-15034-1A0 SATA PORT 6Gb/s(0,1,4,5) VDD3 C430 1u_6.3V_X5R_04 C253 SATA PORT 3Gb/s(2,3) RTC_VBAT_1 15p_50V_NPO_04 W25CSW : non-VPRO:HM87 (6-03-00087-0S2) C442 *10u_10V_Y5V_08 R503 W25CSV : VPRO:QM87 (6-S03-00087-0S3) C434 *10u_6.3V_X5R_06 20K_1%_04 RTC CLEAR SATA Signal Group...

  • Page 71: Lynx 2/9

    Schematic Diagrams Lynx 2/9 NO REBOOT STRAP NO REBOOT STRAP: HDA_SPKR High Enable 3.3VS VDD3 LPC_SIRQ R246 10K_04 Lynx Point - M (LPC,SMBUS,SPI,C-LINK) PCH_BT_EN# R317 10K_04 SMB_CLK R275 2.2K_04 iTPM ENABLE/DISABLE SMB_DATA R305 2.2K_04 TPM FUNCTION:SPI_SI High Enable DRAMRST_CNTRL R306 1K_04 PCH LYNX POINT SUPER SKU ES1 SPI_SI...

  • Page 72: Lynx 3/9

    Schematic Diagrams Lynx 3/9 For vPRO test POWER STATES SUSB# SUSC# SLP_M# PM_SLP_LAN# Lynx Point -M (DMI,FDI,PWRGD) VDD3 JVPRO1 SUSB# SUSC# PCH LYNX POINT SUPER SKU ES1 SLP_A# U27B Moff AW22 w/ WOL_EN DMI_RXN0 DMI_RXN_0 *85205-05R-w25 AR20 DMI_RXN1 DMI_RXN_1 AJ35 FDI_TXN0 FDI_RXN_0 AP17...

  • Page 73: Lynx 4/9

    Schematic Diagrams Lynx 4/9 Lynx Point -M (CRT,LVDS,PCI,DISPLAY) R446 150_1%_04 DAC_B R447 150_1%_04 DAC_G NEAR PCH R448 150_1%_04 DAC_R Zo= 37.5 ±15% U27E PCH LYNX POINT SUPER SKU ES1 DAC_B DK_DVI_DDCB_CLK DAC_B DK_DVI_DDCB_CLK VGA_BLUE DDPB_CTRLCLK C388 *33p_50V_NPO_04 DAC_G DK_DVI_DDCB_DAT DAC_G VGA_GREEN DDPB_CTRLDATA DK_DVI_DDCB_DAT...

  • Page 74: Lynx 5/9

    Schematic Diagrams Lynx 5/9 Lynx Point - M (GPIO,CPU/MISC,NCTF) VDD3 R307 10K_04 HOST_ALERT#1 U27F PCH LYNX POINT SUPER SKU ES1 R266 10K_04 PCH_GPIO8 S_GPIO R227 100_04 S_GPIO_R BMBUSY#/GPIO0 R293 *10K_04 PLL_ODVR_EN R304 *1K_04 SMI# SMI# TACH1/GPIO1 PLL_ODVR_EN:HIGH- ENABLED[DEFAULT] DGPU_HPD_INTR# TACH2/GPIO6 LOW - DISABLED SCI# CPU/Misc...

  • Page 75: Lynx 6/9

    Schematic Diagrams Lynx 6/9 Lynx Point -M (PCIe,USB) USB 3.0 PCI-E x1 Usage USB3.0 Signal Group Zdiff = 85 Ohm ±10% (5 / 5.5 ml) U27I PCH LYNX POINT SUPER SKU ES1 Lane 1 USB2.0 Signal Group Lane 2 Zdiff = 85 Ohm ±10% (5 / 5.5 ml) AW31 Lane 3 WLAN...

  • Page 76: Lynx 7/9

    Schematic Diagrams Lynx 7/9 0.1A Lynx Point -M (POWER) VCCA_DAC_1_2 1.5VS HCB1608KF-121T25 C202 C203 C198 U27G PCH LYNX POINT SUPER SKU ES1 0.1u_10V_X5R_04 1u_6.3V_X5R_04 10u_6.3V_X5R_06 1.05VS 1.5A VCCADAC1_5 AA24 CRT DAC AA26 0.02A C385 C236 C212 C234 C223 AD20 V3.3S_ADACBG R197 *15mil_short_06 3.3VS...

  • Page 77: Lynx 8/9

    Schematic Diagrams Lynx 8/9 Lynx Point - M (POWER) VDD3 CougarPoint power supply range 0.3A PCH LYNX POINT SUPER SKU ES1 HCB1608KF-121T25 U27H C246 C232 Voltage VDD3 VDD3 1.5A *HCB1608KF-121T25 *0.1u_10V_X5R_04 *0.1u_10V_X5R_04 1.00V 1.05V 1.10V 3.3V 3.3V R469 *15mil_short_06 1.43V 1.5V 1.58V 1.5A...
  • Page 78 Schematic Diagrams Lynx 9/9 Lynx Point -M (GND) Lynx Point -M (CLK) U27K PCH LYNX POINT SUPER SKU ES1 AA16 U27C PCH LYNX POINT SUPER SKU ES1 AA20 AA22 AA28 AB35 CK_PCH_SRC0_N VGA_PEXCLK# CLKOUT_PCIE_N_0 CLKOUT_PEG_A AB12 CK_PCH_SRC0_P AB36 VGA_PEXCLK 100MHz CLKOUT_PCIE_P_0 CLKOUT_PEG_A_P AB34...

  • Page 79: Intel Lan I217Lm

    Schematic Diagrams Intel LAN i217LM GIGA LAN (INTEL LAN I217) LAN i217 VDD3 The 10Kohm pull-up resistor of CLK_REQ_N is required to either 3.3V Suspend (5, 6, 7) or Core (2) rail, depending on the power well of PCH's input PCIECLKRQx# buffer.

  • Page 80: Lan Transformer

    Schematic Diagrams LAN Transformer Transformer RJ45 Conn. GIGA LAN TRANSFORMER Docking 3.3V_LAN LAN_MDIP0 NB_LAN_MDIP0 LAN_MDIP0 LAN_MDIN0 NB_LAN_MDIN0 LAN_MDIN0 LAN_MDIP1 NB_LAN_MDIP1 LAN_MDIP1 LAN_MDIN1 NB_LAN_MDIN1 NB RJ45 LAN_MDIN1 LAN_MDIP2 NB_LAN_MDIP2 LAN_MDIP2 LAN_MDIN2 NB_LAN_MDIN2 LAN_MDIN2 LAN_MDIP3 NB_LAN_MDIP3 LAN_MDIP3 LAN_MDIN3 NB_LAN_MDIN3 LAN_MDIN3 R381 *10mil_04 Z2401 DK_LAN_MDIO0+ Sheet 25 of 44...

  • Page 81: Card Reader Rts5229

    Schematic Diagrams Card Reader RTS5229 3.3V_IN 3.3VS SD_W P/MS_BS SD_CD# 40 mil MS_INS# R561 *28mil_06 3.3VS 3,18 PLTRST# CR1_LEDN R568 10K_04 CR_CLKREQ# 3.3V_IN R552 *10K_04 R553 *10K_04 C512 *SCS751V-40 SD_CD# PCH_GP34 *0.1u_16V_Y5V_04 100ohm +/- 15% R578 *10mil_short SD_D2/MS_CLK PCIE_TXP4_CARD HSIP R577 *10mil_short SD_D3/MS_D3...

  • Page 82: Usb Port, E-Sata

    Schematic Diagrams USB Port, E-SATA USB CHARGER PORT USB3.0 Smart CDP Function pin8 pin4 W/ USB CHARGER USBVCC1 DCP autodetect with mouse/keyboard wake up 100mils USB_OC#01 R179 *0_04 Z2605 USB_OC#01 FLG# VOUT1 *0_04 R402 USB_OC#23 20,23 S0 Charging with SDP For W/ or W/O Intel Vpro C187 VIN1...

  • Page 83: 3G, Hdd, Odd

    Schematic Diagrams 3G, HDD, ODD R612 *0_06 3G POWER 3.3VS MINI CARD 3G(Port 6) MINI Card - 3G Card R613 *0_06 3G_3.3V M021015 Combo 3.3V 3G_3.3V >120 mil AO3415 >120 mil 3G CARD / mSATA , PCB Footprint C350 220u_6.3V_6.3*6.3*4.2 88911-52xxA C354 0.1u_16V_Y5V_04...

  • Page 84: Wlan, Ccd, Tpm

    Schematic Diagrams WLAN, CCD, TPM MINI CARD WLAN (Port 8) WLAN POWER (For INTEL SMART CONNECTOR) J_MINI1 20 mil OPEN_2A PIN 2,24,39,41,52 3.3V R164 *0_04 Z2801 17,28,32 PCIE_W AKE# W LAN_3.3V WAKE# 3.3VAUX_0 VDD3 W LAN_3.3V 6-34-M56AS-011-1 20 mil COEX1 1.5V_0 R163 10K_04...

  • Page 85: Kbc-Ite It8587

    Schematic Diagrams KBC-ITE IT8587 KBC_AVDD KBC_VSTBY HCB1005KF-121T20 MODEL_ID Voltage VDD3 VDD3 VDD3 C267 C264 C260 C263 C249 C248 MODEL_ID R470 *10K_04 W25CSW 3.3V 10u_10V_Y5V_08 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 R490 10K_04 W25CSV EC_VCC KBC_AGND 1.65V 3.3VS J_KB1 C259 J_KB1 85208-24051 0.1u_16V_Y5V_04 6-20-94AF0-124 U13B...

  • Page 86: Audio Codec Alc269

    Schematic Diagrams AUDIO CODEC ALC269 AUDIO CODEC (2W) DVDD_IO PVDD1_2 For 3.3V HDA Link. ALC269 VB7 R582 *20mil_04 R594 *28mil_06 Layout note: 3.3VS VT1802S GND and AUDG space is R583 0_04 C473 C475 C497 C499 3.3V 60mils ~ 100mils 10u_10V_Y5V_08 0.1u_16V_Y5V_04 10u_10V_Y5V_08 0.1u_16V_Y5V_04...

  • Page 87: New Card, Gsensor

    Schematic Diagrams New Card, GSensor 3.3V NEW CARD(Port 4) C455 *0.1u_16V_Y5V_04 1(: &$5' 0\ODU FRVW 1HZ FDUG BUF_PLT_RST# FDUG 3.3V J_NEW 1 C449 0.1u_16V_Y5V_04 NC_RST# MC74VHC1G08DFT2G NC_PERST# AUXIN PERST# PERST# 36 mil NC_3VAUX 3.3VS AUXOUT +3.3VAUX C439 0.1u_16V_Y5V_04 6-01-74108-Q61 C463 0.1u_16V_Y5V_04 48 mil 3.3VIN...

  • Page 88: Fan, Tp, Connector

    Schematic Diagrams Fan, TP, Connector CLICK +FP B'd CONN FAN CONTROL M021015 TP_VCC R160 *28mil_06 R502 *0_04 C176 R128 R129 FON# J_LED1 1u_6.3V_X5R_04 C415 10K_04 10K_04 M021015 FAN_5VS VOUT 1u_6.3V_X5R_04 CPU_FAN VSET TP_DATA NCT3940S-A GND Plane TP_CLK C190 C191 LED_PW R LED_ACIN 47p_50V_NPO_04 180p_50V_NPO_04...

  • Page 89: Docking Connector, Com Port

    Schematic Diagrams Docking Connector, COM Port Docking COM PORT HCB1608KF-121T25 3.3V J_DOCK1 M021011 OSC1 R383 22_04 OSC_OUT pin2,8,143,144 DOCKING 3.3V 1000p_50V_X7R_04 AVCC D03A FCO-536B48000 R384 10K_04 C330 C345 SCO-536B 6-22-48R00-1B4 VDD3 DK_SENSE *0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 DK_LAN_MDIO0+ DK_LAN_MDIO0+ DK_USB_PN13 DK_LAN_MDIO0- USB 2.0 HUB DK_LAN_MDIO0- DK_USB_PP13 AVCC...

  • Page 90: 5Vs, 3Vs, 3.3Vm, 5Vm

    Schematic Diagrams 5VS, 3VS, 3.3VM, 5VM 3.3VS 3.3V DD_ON# SUSB NMOS NMOS PQ24A VDD3 VDD3 PQ42A SYS15V VDD3 MTS2072G6 3.3VS SYS15V VDD3 3.3V MTS2072G6 PR194 PR193 PR127 PC94 PR125 PC93 PR126 10K_04 100K_04 1M_04 22_04 1M_04 DD_ON# 27,33 SUSB 3,13,36,38 3.3VS_EN1 M021017 3.3V_EN1...

  • Page 91: 1.05V Series

    Schematic Diagrams 1.05V Series VPRO USED VDD5 M020823 PR178 280K_04 PR167 PR173 1.05V_LAN_M IMAX:5A PC138 PC134 PC135 OCP:10A 4.7u_25V_X5R_08 4.7u_25V_X5R_08 1u_6.3V_X5R_04 PR118 1.05V_LAN_M VPRO USED For CV test PR176 VDD3 10_04 PC89 0_06 PL11 PJ28 VTT_SELECT VTT VR Output Voltages PJ12 *CV-40mil PC88...

  • Page 92: Vdd3/Vdd5

    Schematic Diagrams VDD3, VDD5 VDD3/VDD5 VREF PR114 *0_04 PR109 *20mil_04 PC80 1u_6.3V_X5R_04 PR116 PR161 EN_3V EN_5V PC81 130K_04 130K_04 PC128 1000p_50V_X7R_04 1000p_50V_X7R_04 VREG3 4.7u_25V_X5R_08 PC86 PC87 PC133 PC77 PR162 *10K_04 4.7u_25V_X5R_08 4.7u_25V_X5R_08 1u_6.3V_X5R_04 SYS5V VDD3 LDO3 PC82 PC157 PC129 0.1u_10V_X5R_04 VDD5 PC132 0.1u_50V_Y5V_06...

  • Page 93: Power 1.5V, 1.35V, 0.75Vs, 1.5Vs

    Schematic Diagrams Power 1.5V, 1.35V, 0.75VS, 1.5VS 1.5V or 1.35V/0.75VS PD10 1.5V or 1.35V PC117 PC125 PC124 PC118 PQ34 IMAX:8A MDU1516 RB0540S2 G5616 ULTRASO-8 VDDQ_VTT PC62 OCP:15A VDDQ 10u_10V_Y5V_08 PC60 0.1u_10V_X5R_04 Short VLDOIN VBST PJ23 PR87 7/30 Short VDDQ_VTT DRVH VDDQ V_VDDQ_DIMM 2.2_04...

  • Page 94: Power V_Core 1

    Schematic Diagrams POWER V_CORE 1 3.3VS PR140 100K_1%_NTC_04 PR20 300K_1%_06 SWN3 100K_04 PUT COLSE Del PJ1 PC32 PC26 PC27 PC29 PC30 PC36 TO VCORE SWN1 PR17 300K_1%_06 Phase 1 PJ18 PR151 PR16 Inductor APGND VIN_CPU *CV-40mil 75K_1%_04 165K_1%_04 PC37 PC38 PC39 PC40 PC104...

  • Page 95: Ac In, Charger

    Schematic Diagrams AC IN, Charger PR38 *20mil_04 SMART CHARGER EMB20P03V V_BAT VJACK PR40 *10K_06 JACK1 6-15-32023-7B0 HCB2012KF-800T80 50932-00301-001 PQ28 PQ6A JBATTA2 EMB20P03V EMB17A03V M021015 PR133 PR45 0.01_1%_32 8.2UH_6.8*7.3*3 0.01_1%_32 GND1 PC95 PR132 GND2 470K_04 PQ6B EMB17A03V PR134 100K_04 PR44 PC31 0_06 PC33 4700p_50V_X7R_04...

  • Page 96: Audio Board

    Schematic Diagrams Audio Board USB PORT A_USBVCC 60 mil AC11 AC13 AC10 AC12 22u_6.3V_X5R_08 22u_6.3V_X5R_08 *22u_6.3V_X5R_08 *22u_6.3V_X5R_08 *100u_6.3V_B_B 0.1u_16V_Y5V_04 *0_04 *0_04 *0_04 *0_04 *0_04 *0_04 AJ_USB1 AGND AUSB_PN9 AUSB_PN2_R DATA_L 6-71-W25CSV-D01 AUSB_PP9 AUSB_PP2_R DATA_H *W CM2012F2S-161T03-short M021011 UAR48-041FN2V KS-001HL-ANBA 6-21-B49E0-104 AGND AUDIO JACK Sheet 41 of 44...

  • Page 97: Power Switch & Lid Board

    Schematic Diagrams Power Switch & LID Board POWER SW & LED & HOT KEY LID SWITCH IC S_3.3VS S_VDD3 20mil SJ_SW 2 S_VDD3 6-53-3050B-042 POWER BUTTON 100K_04 S_VDD3 SM_BTN# SSATA_LED# SPW R_SW 1 MH248-ALFA-ESO *BAV99 RECTIFIER SLED_NUM# TJG-532-V-T/R SLED_CAP# TC017-BB1J-X160T SLID_SW # SLED_SCROLL# M021011...

  • Page 98: Click Board

    Schematic Diagrams CLICK BOARD CLICK BOARD T3.3V CLED_ACIN CLED_BAT_CHG CLED_PW R CLED_BAT_FULL C95D95 O126X94D126X94 *0.1u_16V_Y5V_04 220_04 C5VS 220_04 Z4406 220_04 220_04 220_04 CGND Airplane LED POWER ON CJ_TP1 Z4401 Z4402 Z4403 Z4404 BAT LED CTP_CLK CTP_DATA To T/P CTPBUTTON_L RY-SP190YG34-5M RY-SP155HYYG4-1 RY-SP155HYYG4-1 CTPBUTTON_R...

  • Page 99: Fingerprint Board

    Schematic Diagrams FINGERPRINT BOARD NOTE: MODE MODE=HIGH (NC) , USB MODE MODE=LOW , SPI MODE GGND, G_EGND GGND EGND MODE GUSB_PP1 G3.3V AVDD GUSB_PN1 G2.5V DVDD G3.3V VDDIO UVDD G3.3V GLED1 GMCS LED1 SPI_CS GMOSI GMISO SPI_MOSI SPI_MISO GMCLK GLED2 SPI_CLK LED2 GDISCON...
  • Page 100 Schematic Diagrams B - 46...

  • Page 101: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 102: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.
  • Page 103 www.s-manuals.com...
