BÜCHI Distillation Unit K-314
Read these instructions thoroughly before you use the BÜCHI
Distillation Unit K-314. Store these instructions in the imme-
diate vicinity of the apparatus so that they may be consulted at
any time. The unit must only be connected to the mains and
switched on after having completed all necessary preparations.
Chapter 2 contains important safety information. Knowledge
of this is imperative for the safe operation of the Distillation
unit.
Subject to technical change without notice. No part of these
instructions may be reproduced in any form whatsoever or
processed, reproduced or disseminated by means of
electronic or optical systems without the express written
permission of Büchi Labortechnik AG. All rights reserved.
Copyright © Büchi Labortechnik AG 1998
Contents
1
2
2.1
2.2
2.3
2.4
2.5
2.6
3
3.1
4
4.1
4.2.
4.3
4.4
4.5
5
5.1
5.2
5.3
5.4
5.5
5.6
5.7
5.8
5.9
6
6.1
6.2
6.3
6.4
6.5
6.6
6.7
6.8
7
7.1
7.2
8
9
en, Version C (22 pages)
K-314 Operating instructions
Contents
2
3
3
3
3
3
4
4
6
6
7
7
7
7
8
8
9
9
9
10
10
10
11
12
12
12
12
13
13
14
15
15
15
15
16
16
16
17
17
18
18
18
19
20
Order No.
96706
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Buchi K-314
Summary of Contents for Buchi K-314
-
Page 1: Table Of Contents
5.12 Cleaning the unit Read these instructions thoroughly before you use the BÜCHI 5.13 Malfunctions Distillation Unit K-314. Store these instructions in the imme- diate vicinity of the apparatus so that they may be consulted at Maintenance any time. The unit must only be connected to the mains and General information and preparations switched on after having completed all necessary preparations. -
Page 2: Scope Of Delivery
1 Scope of delivery BÜCHI Distillation Unit K-314 Scope of Delivery Description Order No. Versions: 220 - 240V 50/60 Hz K-314 complete 37961 Table 1: Versions Enclosed parts: 1 Digestion tube 03904 1 Distillate outlet tube complete 26301 1 Pair of glass tongs... -
Page 3: Safety
BÜCHI Distillation Unit K-314 2 Safety Safety The apparatus has been built in accordance with state-of- the art technology and recognized safety regulations. Nonetheless risks and dangers can arise from the apparatus: • If the apparatus is operated by insufficiently trained personnel. -
Page 4: General Hazards
The wearing of personal safety equipment such as safety glasses, gloves and l l l l l aboratory coats is necessary. As a necessary part of the distillation unit K-314, this instruction manual must at all times be available to the operating personnel at the location where the apparatus is being used. - Page 5 BÜCHI Distillation Unit K-314 2 Safety It is to be assumed that a safe operation is not possible any more • if the unit is visibly damaged, • If the unit is not functioning any more • after long storage under anfavourable conditions, •...
-
Page 6: Function
3 Functi o n BÜCHI Distillation Unit K-314 Function The distillation unit K-314 is suitable for determining nitrogen using the Kjeldahl and Devarda methods..Other steam distillations (e.g., of alcohol) can also be carried out easily. -
Page 7: Putting Into Operation
Always connect the machine to an earthed (grounded) socket. This avoids risks due to an internal defect. Water supply The distillation unit K-314 is delivered with 3 Nyflex high- pressure hoses intended for the following connections: • cooling water inlet • H O supply tank •... -
Page 8: Drain Hose
• Insert the flow-through tube with the tank cap on into the tank until it reaches the stop • Tighten the tank cap • Connect the hose from the water tank to the K-314 O nipple) • Connect the hose from the sodium hydroxide tank to the K-314 (NaOH nipple •... -
Page 9: Operation
BÜCHI Distillation Unit K-314 5 Operation Operation Control elements Main switch Pressure switch for adding the sodium hydroxide solution Steam tap Digestion tube Rubber bung with PTFE hose Sample tube holder Distillate outlet tube with PTFE hose Receiver plate Drip tray Protective door Fig. -
Page 10: Start-Up Checklist
Fill the supply tanks. This can be done, for example, using a bent funnel (Item No. 16662) or a footpump. The reagents are forwarded within the K-314 unit by suction. To ensure optimum long-time operation, the steam generator must only be operated on distillated or deionized water! -
Page 11: Sample Tube Holder
BÜCHI Distillation Unit K-314 5 Operation Sample tube holder The sample tube holder has been correctly adjusted in the factory. Check whether the holder is still correctly positioned; • Push the quick-locking clamp all the way up (1) • Insert the test tube as shown on the figure (2) •... -
Page 12: Distillation Outlet Tube
• Check the filling of the supply tanks, • Open the main water tap, regulate the water flow, • Switch on the distillation unit K-314 and wait until the steam generator is ready, • Insert an empty sample tube and an empty receiving vessel, •... -
Page 13: 5.11 Carrying Out The Kjeldahl Distillation
(behind the distillation glass). The added volume selected must produce a clear shift in color to brown or blue. Fig. 13: K-314 in operation • Distillation Steam tap to ON A distillation time of approximately 3 minutes is required to get a volume of 100 ml. -
Page 14: 5.13 Malfunctions
5 Operation BÜCHI Distillation Unit K-314 5.13 Malfunctions Malfunction Possible cause Remedy No steam production, 1. Water tank is empty 1. Fill water tank other functions OK 2. Water pump does not suck any 2. Fill water tank water, hoses remain empty 3. -
Page 15: Maintenance
6 Mai n tenance Maintenance General information and Preparations The distillation unit K-314 casing has a plastic coating. The wet domain also has a plastic jacketing. In order to avoid damage to these plastic coverings, wipe off any acid or alkaline splashes immediately with a wet cloth. -
Page 16: Cleaning The Feeding Pump
6 Mai n tenance BÜCHI Distillation Unit K-314 Cleaning the feeding pump Proceed as follows when the sodium hydroxide feed pump no longer functions correctly: • Prepare approximately 1 liter water, • Open the small cover of the supply tank, •... -
Page 17: Main Fuses
BÜCHI Distillation Unit K-314 6 Mai n tenance Büchi’s customer service offers the following services: • Replacement part service • Repair service • Maintenance service • Technical consultation. Main fuses Please change the main fuses as follows:: • Pull out mains cables •... -
Page 18: Taking Out Of Operation
7 Taking out of service BÜCHI Distillation Unit K-314 Taking out of service Remove all dangerous substances and clean the unit thoroughly. This avoids any risk that individuals could come into contact with dangerous substances. Storage/Transport The unit has to be cleaned and repacked in its original packaging when it is being stored or transported. -
Page 19: Replacement Parts
BÜCHI Distillation Unit K-314 8 Replacement parts Replacement parts Only original Büchi accessories and replacement parts guarantee safe operation and a proper functioning of the unit. The use of replacement parts and accessories other than those recommended by Büchi is permissible only with prior approval from the manufacturer. -
Page 20: Appendix
9 Appendix BÜCHI Distillation Unit K-314 Appendix Technical data Dimensions (Width x Height x Depth) 245 x 420 x 220 mm Nominal voltage 230 V, 50/60 Hz Mains voltage tolerance +10 % / -15 % Power rating 1800 Watt Power consumption approx. - Page 21 BÜCHI Distillation Unit K-314 9 Appendix 9.3 FCC requirements (for USA and Canada) English: This equipment has been tested and found to comply with the limits for a Class A digital device, pusuant to both Part 15 of the FCC Rules and the radio interference regulations of the Canadian Department of Communications. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 22 9 Appendix BÜCHI Distillation Unit K-314 Declaration of conformity BÜCHI Labortechnik AG Postfach, CH-9230 Flawil Switzerland declare under our sole responsibility that the product: BÜCHI Distillation Unit K-314 to which this declaration relates is in conformity with the following standards:...
