VEIN REPLACEMENT:

1. If the water or blood oozes out of the arm where the IV catheters have been installed and
withdrawn, replace the veins with a segment from the enclosed IV Vein set.
2. Pull down the IV arm skin to access the affected area.
3. Clip with scissors the damaged section of vein tubing.
4. Install a plastic tubing connector in each of the remaining vein ends.
5. Use the new tubing in the kit and cut a piece the correct length for replacement.
6. Install it between the tubing connectors. Make sure the tubing is seated all the way onto the
connectors.
7. Pull the IV arm skin back over the veins.
The deltoid muscle of the right arm is for IM injections (
out of the arm after use and squeeze the foam insert dry. Let it air dry before storing.
Replacement units are included.
CHEST TUBE PLACEMENT:
This bilateral feature will allow the use of normal sized trocars during the insertion process. This
trainer is not designed to be a technique trainer; rather, it offers the opportunity to install a
chest tube to indicate that the procedure is necessary under current patient conditions as
evidenced by the practitioner's assessment.
1. Close the tubing clamp before filling the reservoir bag.
2. Fill the bag and attach the tubing end to port C.
3. Once the tubing is securely connected elevate the reservoir bag about 30" above chest level
4. Release the tubing clamp so the water can flow into the system.

TENSION PNEUMOTHORAX:

Install the pneumothorax patches when needed. The smaller circle fits the cut out area of the
overlay. The larger circle is the shoulder that holds the patch in place.
When a needle is inserted in either of the bi-lateral chest sites, the bladder will release the
compressed air with an audible hiss.
ECG MONITORING AND DEFIBRILLATION
Four ECG limb lead connectors on the chest are attached to the rib cage for removing the
overlay skin. The ECG snaps cannot be used for defibrillation and each one is labeled, "NOT A
DEFIBRILLATION SITE". Doing so will void the warranty.
To view limb lead ECG waveforms, attach the 3, 4, or 5-lead ECG cable to the ECG snaps at the
following locations:
RA (right arm): right shoulder snap
Use only water
8
). Pull the injection site
