3.3.1 INLET FLANGE SIZE SPECIFICATIONS

MODEL FITS FLANGE
XFIH-E1*A 3" ANSI 125/150
(metric DN8 PN20)
XFIH-E2*A 4" ANSI 150
(metric DN100 PN20)
XFIH-E4*A metric DN80, PN16
XFIH-E5*A metric DN100, PN16
* The second to last digit in the model number refers to exit thread size and type.

3.4 OVERALL DIMENSIONS

15.43
[392MM]
SHOWN
WITHOUT
7.90
INLET FITTING
[201MM]
(SEE TABLE
IN SECT. 3.4.1
FOR
ADDITIONAL
HEIGHTS)

3.4.1 OVERALL HEIGHT INCREASE FOR INLET FITTINGS

MODEL
XFIH-E1*A
XFIH-E2*A
XFIH-E4*A
XFIH-E5*A
XFIH-E6*A
XFIH-E7*A
XFIH-E8*A
XFIH-E9*A
OUTSIDE THICKNESS
DIAMETER
7.5" .75"
190mm 20mm
9.0" .94"
230mm 23mm
200 mm 22 mm
220mm 22 mm
3.64
[93MM]
10.74
[273MM]
[150MM]
18.64
[473MM]
Overall Dimensions
INLET FITTING TYPE
3" ANSI 125/150
(metric DN8 PN20)
4" ANSI 150
(metric DN100 PN20)
metric DN80, PN16
metric DN100, PN16
3" NPT Female
4" NPT Female
3" BSP Male
4" BSP Male
* The second to last digit in the model number refers to exit thread size and type.
BOLT HOLE NO. BOLT
CIRCLE HOLES
6.0"
152.5mm
7.5"
190.2mm
160 mm
180 mm
5.89
FIG 3.4
ADDITIONAL HEIGHT
.75"
20 mm
.94"
23 mm
2.80"
22 mm
2.80"
22 mm
2.00"
51 mm
1.75"
45 mm
2.30"
58 mm
2.30"
58 mm
6
SIZE OF TORQUE ON BOLTS
BOLTS
4 5/8" 76-80 FT-LBF
4 M16 100-110 Newton Meters
8 5/8" 76-80 FT-LBF
8 M16 100-110 Newton Meters
8 16 mm 100-110 Newton Meters
8 16 mm 100-110 Newton Meters
OVERALL HEIGHT
16.18"
412 mm
16.37"
415 mm
18.23"
414 mm
18.23"
414 mm
14.43"
443 mm
17.18"
436 mm
17.73"
450 mm
17.73"
450 mm
