2. Pitch

Turning the encoder will increase/decrease the pitch of the audio sample, or recorded buffer independently of play-
back speed.
CV input tracks 1V/Octave, accepts 0-5V unipolar, and is added to the knob position.
Pitch ranges from -3 octaves to +2 octaves.
When set to original pitch, both pitch LEDs will be blue.
The LEDs will illuminate twice as bright when set to any octave that is above or below original pitch.
Positions between octaves are indicated by a blend of the colors of the surrounding octaves.

3. Start

Controls the start position of either the loaded file or the recorded buffer.
CV input responds to +/- 5V, and is added to the knob position.

4. Size

Controls the size of the currently selected loop.
CV input responds to +/- 5V, and is added to the knob position.

5. Density

Controls the rate of grain generation.
Ranges from .120Hz(8.3s) to 2.5kHz(400us).
When the secondary Freeze control is enabled, turning the density knob all the way down disables internal grain
generation.
CV input responds to +/- 5V, and is added to the knob position.
Octave Color
-3 White
-2 Orange
-1 Yellow
0 (original pitch) Blue
+1 Green
+2 Purple
10
Side (left/right)
Left
Left
Left
Both
Right
Right
