6.4.3

Map Descriptor Example

// Server Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , Node_Name
SMD_AI_01 , DA_AI_01
SMD_AI_02 , DA_AI_01
SMD_AI_03 , DA_AI_01
SMD_AO_01 , DA_AO_01
SMD_AO_02 , DA_AO_01
SMD_AO_03 , DA_AO_01
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , Node_Name
SMD_DI_01 , DA_DI_01
SMD_DI_02 , DA_DI_01
SMD_DI_03 , DA_DI_01
SMD_DO_01 , DA_DO_01
SMD_DO_02 , DA_DO_01
SMD_DO_03 , DA_DO_01
, 0 , Passive , Virtual_DEV_11 , AI
, 1 , Passive , Virtual_DEV_11 , AI
, 2 , Passive , Virtual_DEV_11 , AI
, 0 , Passive , Virtual_DEV_11 , AO
, 1 , Passive , Virtual_DEV_11 , AO
, 2 , Passive , Virtual_DEV_11 , AO
, 0 , Passive , Virtual_DEV_11 , BI
, 1 , Passive , Virtual_DEV_11 , BI
, 2 , Passive , Virtual_DEV_11 , BI
, 0 , Passive , Virtual_DEV_11 , BO
, 1 , Passive , Virtual_DEV_11 , BO
, 2 , Passive , Virtual_DEV_11 , BO
Page 15 of 34
BACnet PTP Serial Driver Manual
, Object_Type , Object_Instance , Units
, 1 , Degrees-Fahrenheit
, 2 , Degrees-Fahrenheit
, 3 , Degrees-Fahrenheit
, 1 , percent-relative-humidity
, 2 , percent-relative-humidity
, 3 , percent-relative-humidity
, Object_Type , Object_Instance
, 1
, 2
, 3
, 1
, 2
, 3
