Example
// Server Side Connections
Connections
Port , Baud
P1 , 9600
6.3

Server Side Node Parameters

Section Title
Nodes
Column Title Function
Node_Name 3 Provide name for node.
Node_ID BACnet station address of physical Server node.
Protocol Specify protocol used.
Node_Option Enable or disable COV for this node.
Example
// Server Side Nodes
Nodes
Node_Name , Node_ID
Virtual_DEV_11 , 11
6.4

Server Side Map Descriptor Parameters

6.4.1

FieldServer Specific Map Descriptor Parameters

Column Title
Map_Descriptor_Name
Data_Array_Name
Data_Array_Offset
Function
3
When using the Trane Tracer Summit Workstation System, this name will appear as the object name.
4
Note that Port is not declared in the Server Side Nodes.
, Parity , Data_Bits , Stop_Bits
, Even , 7 , 1
4
, Protocol
, BACnet_PTP
Function
Name of this Map Descriptor. This is used
for Object_Name Property. Refer
Appendix A.1.
Name of Data Array where data is to be
stored in the FieldServer.
Starting location in Data Array.
Function of Server Map Descriptor.
Page 13 of 34
BACnet PTP Serial Driver Manual
, Protocol
, BACnet_PTP
Legal Values
Up to 32 alphanumeric characters
1 - 16777215
BACnet_PTP
COV_Enable, COV_Disable
Legal Values
Up to 32 alphanumeric
to
characters
One of the Data Array names
4
from Section
0 to ("Data_Array_Length" -1) as
specified in Section
Passive
4
