SFP Transceivers

2
Transmit Optical Bore SFP Cage Sockets
Receive Optical Bore
Extraction Lever Socket Latch
Caution:
SFP transceivers are static sensitive devices. Use an ESD wrist strap or similar grounding device when handling
transceivers.
Do not install or remove SFP transceivers while fiber-optic cables are still attached. This can cause damage to the
cables, cable connectors, and the optical interfaces. It may also prevent the transceiver from latching correctly into
the socket connector.
Do not force the SFP transceivers into the cage slots. If the transceiver does not easily slide in and click into place, it
may not be aligned correctly or may be upside down. If this happens, remove the SFP transceiver, realign it or rotate it
and slide it in again.
