Summary of Contents for Fortinet FortiWiFi 60CM
- Page 1 FortiWiFi 60CM QuickStart Guide...
- Page 2 Copyright© 2013 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, and FortiGuard®, are registered trademarks of Fortinet, Inc., and other Fortinet names herein may also be trademarks of Fortinet. All other product or company names may be trademarks of their respective owners. Performance metrics contained herein were attained in internal lab tests under ideal conditions, and performance may vary.
-
Page 3: Table Of Contents
Table of Contents Package Contents Connecting Your Device FortiExplorer Connecting to the FortiWiFi Unit Technical Specifications LED Specifications Cautions and Warnings Documentation and Links Register Your Product Product License Agreement... -
Page 4: Package Contents
Package Contents Thank you for purchasing the FortiWiFi 60CM. The FortiWiFi 60CM multi-threat security appliance offers you unmatched performance, flexibility, and security for your remote, branch, or small office network. Your box contains the following: FortiWifi 60CM QuickStart Guide USB Cable... -
Page 5: Connecting Your Device
Connecting Your Device CONSOLE DC+12V USB MGMT WAN2 WAN1 MODEM To attach your unit to a wall, refer to the wall mount template. Ensure the FortiWiFi unit is placed on a stable surface. Connect the following to the FortiWiFi unit: 1. -
Page 6: Fortiexplorer
MODEM USB A cable end into USB B cable end into Management Computer your Fortinet device Note: When using FortiExplorer for the first time, ensure the FortiWiFi unit is using its factory default settings. Installing FortiExplorer FortiExplorer is available for Microsoft Windows XP, Vista, 7, and 8. It is also available for Mac OS X Snow Leopard and higher. - Page 7 Mac OS Install 1. Double-click the .dmg file and drag the FortiExplorer program file into the Applications folder. 2. Connect the USB cable to the FortiWiFi unit and then to the management computer. 3. Double-click the FortiExplorer icon to launch the application. Configuration Options With FortiExplorer, you are provided a number of options on how to configure the FortiWiFi unit, depending on your level of comfort with...
-
Page 8: Connecting To The Fortiwifi Unit
Connecting to the FortiWiFi Unit The FortiWiFi unit requires some basic configuration to add it to your network. These basic steps include assigning IP addresses, DNS settings, and the default gateway. Until these steps are completed traffic will not flow through the device. In addition to FortiExplorer, the FortiWiFi unit can be configured using the Web-based Manager or the Command Line Interface (CLI). - Page 9 To Connect to the CLI: You can configure all FortiWiFi configuration options from the CLI using config commands. The CLI also includes get, show, diagnose, and execute commands for performing various configuration and monitoring tasks. 1. Connect the FortiWiFi unit’s console port to the management computer using the provided console cable.
-
Page 10: Technical Specifications
Technical Specifications CONSOLE USB MGMT WAN2 WAN1 MODEM DC+12V # Interface Type Description 1 USB MGMT USB-B USB client port for management. 2 USB USB-A USB server port for USB key, modem, or management functions. 3 Console RJ-45 Optional serial connection to the Management Computer. -
Page 11: Led Specifications
LED Specifications FortiWiFi 60CM MODEM WIFI INTERNAL WAN1 WAN2 DMZ LINK/ACT SPEED STATUS EXPRESS CARD State Description Green The unit is on. The unit is off. MODEM Green Internal modem is in use. Flashing Green The unit is booting. STATUS Green The unit is running normally. -
Page 12: Cautions And Warnings
Cautions and Warnings Please review the following cautions and warnings. Environmental and mounting specifications Operating temperature: 0 - 40°C (32 - 104°F) Storage temperature: -25 - 70°C (-13 - 158°F) Humidity: 20 to 90% non-condensing Operating Altitude: <2250m (7400ft) Elevated Operating Ambient: If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. - Page 13 If you experience trouble with this equipment, or repair or warranty information, please contact the following address and phone number for information. Fortinet Inc. 1090 Kifer Road, Sunnyvale, CA 94086 USA 1-866-393-9960 (US and Canada)
- Page 14 Industry Canada Equipment Standard for Digital Equipment (ICES) – Canada CAN ICES-3 (B) / NMB-3 (B) This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 15 Grounding Ensure your Fortinet product is connected and properly grounded to a lightning and surge protector. WAN or LAN connections that enter the premises from outside the building should be connected to an Ethernet CAT5 (10/100 Mb/s) surge protector.
-
Page 16: Documentation And Links
The following Fortinet web pages provide information and resources for your Fortinet product: 1. Customer Service & Support: https://support.fortinet.com On this page you can create a support account with Fortinet, register and manage your products, download updates, firmware images and release notes, and create technical support tickets. 2. Technical Documentation: http://docs.fortinet.com... -
Page 17: Register Your Product
Register Your Product If you did not register your Fortinet product using the FortiExplorer wizard, please register your product now. Register Register your Fortinet product in order to receive: • Technical Support • New product features • Protection from new threats Enregistrer Vous devez enregistrer le produit pour recevoir: • Support technique • Nouvelles fonctionnalitées du produit • Protection contre de nouvelles menaces... -
Page 18: Product License Agreement
Product License Agreement The parties to this agreement are you, the end customer, and either (i) where you have purchased your Product within the Americas, Fortinet, Inc., or (ii) where you have purchased your Product outside of the Americas, Fortinet Singapore Private Limited (each referred to herein as “Fortinet”) .CAREFULLY READ THE FOLLOWING LEGAL AGREEMENT (THE OR THIS “AGREEMENT”... - Page 19 (d) is licensed for beta, evaluation, donation, testing or demonstration purposes or for which Fortinet does not charge a purchase price or license fee. In the case of beta, testing, evaluation, donation or free Software or Product, the end user acknowledges and agrees that such Software or Product may contain bugs or errors and could cause system failures, data loss and other issues, and the end user agrees that such Software or Product is provided “as-is”...
- Page 20 To obtain a complete machine-readable copy, please send your written request, along with a check in the amount of US $25.00, to General Public License Source Code Request, Fortinet, Inc., 1090 Kifer Rd, Sunnyvale, CA 94086 USA. In order to receive the modified software modules, you must also include the following information: (a) Name, (b) Address, (c) Telephone number, (d) E-mail Address, (e) Product purchased (if applicable), (f) Product Serial Number (if applicable).
- Page 21 or modify the Program subject to these terms and conditions. You may not impose any further restrictions on the recipients’ exercise of the rights granted herein. You are not responsible for enforcing compliance by third parties to this License. 7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License.
- Page 22 If distribution of object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place satisfies the requirement to distribute the source code, even though third parties are not compelled to copy the source along with the object code. 5.
