Summary of Contents for Venturo ET8K
- Page 3 DECAL PLACEMENT 21353 SAFETY DECALS 21354 DECALS FOR ET CRANES 21362 MISCELLANEOUS DECALS - ET8/12K(X) 21825 MODEL AND CAPACITY DECALS - ET8K(X) SECTION 200 INSTALLATION 711105 CABLE & BATTERY REQUIREMENTS - ET AND HT CRANES 15660 BATTERY CABLE INSTALLATION DRAWING 20906-8...
- Page 5 SECTION 100 DESCRIPTION & SPECIFICATIONS 7607100A...
- Page 15 SECTION 150 SAFETY 8604150...
- Page 16 CRANE SAFETY AND HAZARDS ET CRANES CAUTIONS 1. INSPECT VEHICLE AND CRANE, INCLUDING OPERATION, PRIOR TO USE DAILY. 2. DO NOT USE THIS EQUIPMENT EXCEPT ON SOLID, LEVEL SURFACE WITH CRANE MOUNTED ON FACTORY-RECOMMENDED TRUCK. 3. BEFORE OPERATING THE CRANE, REFER TO MAXIMUM LOAD (CAPACITY) CHART ON CRANE FOR OPERATING (LOAD) LIMITATIONS.
- Page 23 SECTION 200 INSTALLATION 7607200A...
- Page 24 CCA (A)** RC (MIN)*** CE6K CT2000 CT2003/4/5 DT7K ET5500MPB ET5500R ET6KMPB NOT RECOMMENDED ET6KR ET8K ET10K ET12K ET8KX ET10KX NOT RECOMMENDED ET12KX ET25K SEE DRAWING I24600 FOR CABLE AND BATTERY REQUIREMENTS ET25KX INCLUDES GROUND CABLE ** CCA=COLD CRANKING AMPS AT 0' F.
- Page 28 The boom angle is shown by a gravity arrow. SNATCH BLOCK If the load exceeds 1600 lbs. for the ET8K(X) and ET10K(X) or 1750 lbs. for the ET12K(X) or if reduced winching speed for better control of smaller loads is required, use the snatch block to rig the crane for two part line operation.
- Page 29 CONTROL FUNCTIONS WINCH "UP" and "DOWN" - Raises and lowers the load with the wire rope. POWER ELEVATION - "Up" raises the boom elevation by operating the valves and the electric hydraulic power unit. "Down" operates a solenoid release valve mounted on the cylinder to lower the load and/or boom by gravity at a controlled rate.
- Page 30 OVERLOAD ALARM SYSTEMS (OPTIONAL) This crane may be equipped with an optional overload alarm system. 1. Overload alarm horn sounds if rated load is exceeded at any reach. 2. If alarm sounds, RAISE Boom or LOWER Winch to remove overload. 3.
- Page 31 SOME WINCHES WILL BE SUPPLIED WITH A HEX NUT IN LIEU OF A WEDGE FOR INSTALLING THE WIRE ROPE. FIG 1 DATE SECTION TITLE WIRE ROPE INSTALLATION DRAWING 8-18-09G C200 MANUFACTURING, INC. SUPERCEDES CINCINNATI, OHIO 22245 ET8K AND LARGER CRANES 2-26-08F...
- Page 33 SECTION 300 MAINTENANCE & SERVICE 7607300A...
- Page 37 SECTION 400 PARTS 7607400A...
- Page 40 FASTENER LIST FOR ET8KX PART NUMBER DESCRIPTION LOCATION/FUNCTION !HHCS03118063 HEX HEAD CAP SCREW 5/16-18 X 5/8" LG GROUND STRAP ON CANDLESTICK !LWSH-031 LOCK WASHER - 5/16 GROUND STRAP ON CANDLESTICK !HNUT-03118 HEX NUT - 5/16-18 GROUND STRAP ON CANDLESTICK !HHCS02520063 HEX HEAD CAP SCREW 1/4-20 X 5/8"...
- Page 56 LIMITED WARRANTY POLICY This limited policy warrants new products of Venturo to be free from defects in material and workmanship for a period of one (1) year from date of original installation. This warranty covers: Repair or replacement of product ♦...
