  • Page 1 DS-1404, DS-1406, DS-2408 Bypass Switches FASTstart Guide April 2016 © 2016 Datacom Systems Inc.

  • Page 2: Table Of Contents

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Table of Contents Terms of Use ............................... 5 Copyright ................................. 5 License Agreement ............................5 Proprietary Notice ............................5 Trademark Attribution ............................ 5 Certifications and Marks ..........................5 Safety Notices and Warnings .......................... 6 Overview ..............................
  • Page 3 DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 5.8.4 Manual Bypass ............................33 5.8.5 Passive Bypass ............................34 Command List ............................35 Bypass Commands ............................35 6.1.1 Bypass Get Info............................35 6.1.2 Bypass Get Info Reset ..........................35 6.1.3 Bypass Set Direction ..........................35 6.1.4...
  • Page 4 DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.4.1 Port Get Info ............................44 6.4.2 Port Get Counter ........................... 45 6.4.3 Port Get Counter Detail ......................... 45 6.4.4 Port Reset Counter ..........................45 6.4.5 Port Set Media............................46 6.4.6 Port Set Speed ............................46 Switch Commands ............................

  • Page 5: Terms Of Use

    Datacom Systems, Inc. License Agreement Notice to All Users: By using Datacom Systems, Inc. products, you agree to the terms set forth. No licenses, express or implied, are granted with respect to the technology described and Datacom Systems, Inc. retains all rights with respect to the technology described herein.

  • Page 6: Safety Notices And Warnings

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Safety Notices and Warnings These explanatory labels are included in this information for the user in accordance with the requirements of IEC 60825.1. WARNING : Class 1 laser and LED product. A class 1 laser is safe under all conditions of normal use.

  • Page 7: Overview

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 2 Overview This FASTstart Guide for the DS-1404, DS-1406, and DS-2408 Bypass Switches is intended to provide you with information needed to get your Bypass Switch up and running. Additional support, documentation and help can be found on the Datacom Systems website: http://www.datacomsystems.com...

  • Page 8: What Shipped

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide What Shipped? 1- DS-1404, DS-1406, or DS-2408 Bypass Switch 2- Switching AC Adapters 1- DRL512-2M-R cable 1- DB9 M/F straight through 2- AC Line Cords Specifications DS-1404 Ports: Network Ports: Two (2) 10/1G Fiber...

  • Page 9: Supported Sfp Transceivers

    Storage Temperature: -22º to 149ºF (-30º to 65ºC) Humidity: 5 to 90% non-condensing Warranty: Visit http://www.datacomsystems.com/support/warranty-info for more information. Supported SFP Transceivers Datacom Systems supports the following small form-factor pluggable (SFP) transceivers and enhanced small form-factor pluggable (SFP+) transceivers: Model # Specification FCLF-8521-3...

  • Page 10: Front - Port Types

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Front - Port Types Network Pairs: Network Pairs are connected inline in the same way an appliance would normally be installed to the network. Network port 1 connects to one endpoint, and Network port 2 connects to the endpoint on the opposite end of the link. Network Pairs have a multi-tiered fail-open mechanism that allows them to preserve network connectivity in the event of an appliance failure, or even a power failure to the DURAstream™.
  • Page 11 DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Appliance Pairs: Appliance pairs connect the appliance to the DURAstream™ in the same way that it would normally connect to a network. Appliance ports provide connectivity between the network traffic and the appliance. In addition to providing the appliance with inline network traffic, appliance pairs will also send heartbeat packets to monitor the health of the appliance.
  • Page 12 DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Serial Port: The serial port can be used to connect to the DURAstream™ Bypass Switch using a DB9 M/F straight through cable. Using a terminal emulator such as Tera Term or Putty, the serial port may be accessed for login and configuration using the CLI interface.

  • Page 13: Front - Power & Status Indicators

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Front - Power & Status Indicators On the front panel, the power status of the device can be determined through three indicators labeled “POWER 1”, “POWER 2”, and “STATUS”. green The LEDs located next to each power label will illuminate when a power supply is connected and switched ON.

  • Page 14: Rear - Unit Identifiers

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Rear — Unit Identifiers Important information such as the MAC address, serial number, and micron specification of the bypass switch network links can be found on the back of the unit. MAC: The Media Access Control (MAC) address for the management port for on the front of the device is printed here.

  • Page 15: Network Ip Address Configuration

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 3 Network IP Address Configuration All DURAstream™ Bypass Switches can be accessed and configured through the management port on the front of the unit. Once set up, this port can be used to access the device through Telnet.

  • Page 16: Setting Up The Durastream™ For Management Port Access

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Setting up the DURAstream™ for Management Port Access Step 1: First, connect your PC and your DURAstream™ using the provided Datacom Systems DB9 M/F straight through cable. Connect the DB9 Female pin end to the serial port on your PC and connect the DB9 Male pin to the serial port on your DURAstream™.
  • Page 17 DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Step 5: Set up the IP address, subnet, and gateway on the device to match the network that the management port is connected to. This can be done by using the commands: o MANAGEMENT SET IP (<IP address> | “DHCP”) o MANAGEMENT SET SUBNET <Subnet mask>...

  • Page 18: Management Connection

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 4 Management Connection Setup Once the management port configuration on the DURAstream™ has been set up to match your chosen network location, you must next connect the straight through CAT5 cable to your network.

  • Page 19: Connecting Via Telnet

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Connecting via Telnet Once the Management port is configured and connected to the network, the DURAstream™ may be configured using a CLI over Telnet. After confirming network connectivity in step 4.1, a terminal emulator may be used to configure the device.
  • Page 20 DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Step 2: Enter the IP address of the VERSAstream in the Host field. Click “OK” Step 4: To confirm that connection to the correct device was made, enter the “system get info” command to view unique identifiers for the unit such as the Serial Number and MAC Address.

  • Page 21: Bypass Terminology Explanation

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 5 Bypass Terminology Explanation Overview DURAstream™ Bypass Switches allow you to customize various attributes of the heartbeat packets that are used to determine appliance health. They are shipped programmed with recommended settings, but can be changed dynamically. The default settings are suited for most use cases, but can be easily modified to change the parameters of how the DURAstream™...

  • Page 22: Heartbeat Expiration

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Heartbeat Expiration The Heartbeat Expiration configuration controls the length of time that the DURAstream™ will wait before considering a heartbeat lost. Setting the Heartbeat Expiration to 200ms will cause all heartbeats that have not arrived back at the DURAstream™ within 200ms to be considered lost.

  • Page 23: Heartbeat Fail Count

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Heartbeat Fail Count The Heartbeat Fail Count controls how many consecutive heartbeats must be missed in order for the DURAstream™ to determine that action should be taken to bypass the appliance. The lower the fail count is set to, the faster the DURAstream™ will take action to bypass the appliance.

  • Page 24: Heartbeat Reactivation Count

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Heartbeat Reactivation Count The Heartbeat Reactivation Count controls how many consecutive heartbeats must be passed in order for the DURAstream™ to determine that the appliance should be put back inline on the link. The lower the Reactivation count is set to, the faster the DURAstream™ will put the appliance back inline.

  • Page 25: Heartbeat Direction

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Heartbeat Direction The Heartbeat Direction setting controls direction that heartbeats are inserted in. By default (UNI), the heartbeats will always transmit out the odd port, and be received on the even port. Setting this field to BIDI will cause each appliance port to both transmit and receive heartbeats simultaneously.

  • Page 26: Heartbeat Packet Type

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Heartbeat Packet Type The Heartbeat Packet setting determines the format of the heartbeat packet that is sent out. It’s recommended to choose the heartbeat type that matches the network traffic, and also the type of traffic that the appliance is designed to pay attention to.

  • Page 27: System Bypass Modes

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide System Bypass Modes 5.8.1 Normal When set to Normal mode, the DURAstream™ will transmit heartbeats to the appliance to monitor its health. If the DURAstream™ determines that the appliance is healthy based on user specified criteria, it will direct traffic through the appliance ports.

  • Page 28: Normal High Availability

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 5.8.2 Normal High Availability The high availability feature is available in DS-1406 and DS-2408 models. The feature makes use of all 4 appliance ports on the bypass switch. When activated, the bypass switch can only be used to route traffic from a single network link.
  • Page 29 DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Datacom Systems Inc. 2016...
  • Page 30 DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Datacom Systems Inc. 2016...
  • Page 31 DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Datacom Systems Inc. 2016...

  • Page 32: Manual Inline

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 5.8.3 Manual Inline When set to Manual Inline mode, the DURAstream™ will forcefully put a connected appliance inline. No heartbeats are transmitted in this mode, meaning that the DURAstream™ is not able to monitor the health of the appliance.

  • Page 33: Manual Bypass

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 5.8.4 Manual Bypass When set to Manual Bypass mode, the DURAstream™ will isolate the appliance from the network link. No traffic is sent to the appliance, however heartbeats are still sent in order to maintain a record of the appliance’s health.

  • Page 34: Passive Bypass

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 5.8.5 Passive Bypass When set to Passive Bypass mode, the DURAstream™ will isolate itself and the appliance from the network link. A passive connection to the network will be created, where the Network Endpoints directly negotiate speed with each other, rather than the Network Pair.

  • Page 35: Command List

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6 Command List Bypass Commands 6.1.1 Bypass Get Info Use this command to retrieve information from all bypass fields. This will also Usage Guidelines print the configurable heartbeat information and bypass current state. BYPASS GET INFO...

  • Page 36: Bypass Set Expire

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.1.4 Bypass Set Expire Use this command to set the period of time that the bypass switch will wait, starting at the point of transmission, before considering a heartbeat packet to be lost. If it takes more than the defined period of time for a heartbeat to arrive...

  • Page 37: Bypass Set Mode

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.1.7 Bypass Set Mode This command is used to set the current operating mode of the Bypass Usage Guidelines Segment. (NORMAL, NORMAL HIGH AVAILABILITY, MANUAL BYPASS SET MODE Syntax INLINE, MANUAL BYPASS, PASSIVE BYPASS)

  • Page 38: Email Notification Commands

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Email Notification Commands 6.2.1 Email Get Settings Usage Use this command to display all configurable email settings. Guidelines EMAIL GET SETTINGS Syntax Example EMAIL GET SETTINGS Command Displays the following configurable values:  Email Source/Destination Notes ...

  • Page 39: Email Set Destination

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.2.4 Email Set Destination Use this command to set the Destination for the email notifications. This email Usage Guidelines address will receive notifications for all triggers that are turned on. Syntax EMAIL SET DESTINATION (email@address.com) Example EMAIL SET DESTINATION monitoring@acmetest.com...

  • Page 40: Email Set Trigger

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.2.7 Email Set Trigger Use this command to decide when to send out an email notification. Email Notifications can be sent out based on link state changes, heartbeats Usage Guidelines lost/arrived, Failover Status Change, Power Supply Status Change, and During a Warm/Cold Boot.

  • Page 41: Management Reset

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.3.2 Management Reset Usage This command is used to resend the DHCP Discovery manually. Guidelines Syntax MANAGEMENT RESET Example MANAGEMENT RESET 6.3.1 Management Set CLI Timeout This command is used to set the telnet command line timeout. If there is no...

  • Page 42: Management Set Daemon Ntpd

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.3.4 Management Set Daemon NTPD Usage This command is used to set the NTP Feature on or off. Guidelines Syntax MANAGEMENT SET DAEMON NTPD <ON/OFF> Example MANAGEMENT SET DAEMON NTPD ON  When turned on, the unit will use the configured NTP server to...

  • Page 43: Management Set Ip

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.3.3 Management Set IP This command is used to configure the IP address for the management port on Usage Guidelines the switch. Syntax MANAGEMENT SET IP <IPv4 address or “DHCP”> Example MANAGEMENT SET IP 192.168.1.25 ...

  • Page 44: Management Set Tftpserver

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.3.7 Management Set TFTPServer This command is used to configure the IP address for the TFTP Server that the Usage Guidelines DURAstream will communicate with. Syntax MANAGEMENT SET TFTPSERVER <IPv4 address> Example MANAGEMENT SET TFTPSERVER 192.168.1.25 ...

  • Page 45: Port Get Counter

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.4.2 Port Get Counter This command is used to display port counter information for a port, or set of Usage Guidelines ports. Simple counter output that shows Tx and Rx packets. Syntax PORT (1,2,3,4,5,6,7,8,*) GET COUNTER...

  • Page 46: Port Set Media

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.4.5 Port Set Media This command is used to change the media type of an appliance port from fiber Usage Guidelines to copper or vice versa. Syntax PORT (3,4,5,6,*) SET MEDIA <Copper,Fiber> Example PORT ALL SET MEDIA FIBER ...

  • Page 47: Switch Commands

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Switch Commands 6.5.1 Switch Restart This command is used to reboot the bypass switch. During the reboot, the link Usage will be passively closed in order to allow link state for part of the duration of the Guidelines reboot.

  • Page 48: System Commands

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide System Commands 6.6.1 System Get Info Usage This command is used to display all system information. Guidelines Syntax SWITCH GET INFO Example SWITCH GET INFO Command Fields Displayed:  Product Model Notes  Current Operating Mode ...

  • Page 49: System Send Logfile

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.6.2 System Send Logfile This command is used to send the current log file to the configured TFTP server. Usage The IP address of the TFTP server that is used is taken from the “...

  • Page 50: System Set Ntpdserver

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 6.6.4 System Set NTPDserver This command is used set the NTP server that will be used to regulate the Usage Guidelines DURAstreams Date/Time. Syntax SYSTEM SET NTPDSERVER (pool.ntp.org) Example SYSTEM SET NTPDSERVER (pool.ntp.org) Command Either set an IP address or the address of an NTP server.

  • Page 51: Configuration Examples

    Single Copper Appliance for a 1G Fiber Link. Use Case: A single appliance scenario can be used on the DS-1404, DS-1406, and DS- 2408 models. It is used when a single appliance needs to be installed on a single network link through the bypass switch.
  • Page 52 DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Example Configuration Commands Management Port Setup Command Explanation Management Set IP 192.168.1.2 If you plan to access the Durastream™ over a network, you should first set up the IP information to connect to it Management Set Subnet 255.255.255.0...
  • Page 53 DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide *Optional* Email Notification Setup Command Explanation Emails notifications will appear from the entered Email Set Source john_doe@acme.com email address. Emails notifications will arrive at the entered Email Set Destination john_smith@acme.com email address. Email notifications will go through the entered Email Set Server 192.168.1.3...

  • Page 54: Customer Service

    DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide 8 Customer Service Datacom Customer Service is available via telephone and Internet. You may also find the assistance you need at our website: http://www.datacomsystems.com. Telephone: +1 315 463-9541 Internet website: http://www.datacomsystems.com/support/contact-support Datacom Systems Inc. 2016...
  • Page 55 DURAstream™ DS-1404, DS-1406, DS-2408 FASTstart Guide Datacom Systems Inc. 9 Adler Drive • East Syracuse, NY 13057 TEL: +1 315 463-9541 • FAX: +1 315 463-9557 http://www.datacomsystems.com Datacom Systems Inc. 2016...
