- Page 1 Datacom Systems Inc Access Your Network DS-1010 Bypass Switch DURA stream 10 Gigabit DS-1010 USERguide 541-0130-U-A.00 May 2010 © 2010 Datacom Systems Inc...
- Page 2 This page intentionally left blank © 2010 Datacom Systems Inc...
-
Page 3: Product Description
Product Description Datacom Systems Inc. DURAstream™ DS-1010 Bypass Switch is a 10Gbps intelligent external active bypass that enables plug and play connectivity which includes an auto heartbeat and requires no additional drivers to be installed on any connected appliance. The DS-1010 consists of one 10Gbps segment which... - Page 4 DURA stream © 2010 Datacom Systems Inc All rights reserved. No parts of this work may be reproduced in any form or by any means graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems without the written permission of the publisher.
-
Page 5: Table Of Contents
2 Basic Command Set ....................22 3 <variable> List for CLI ....................23 4 Command Line Interface Usage ....................26 2 SERIAL Port Configuration (RJ45) ..................27 1 HyperTerminal ....................27 2 IP Address Configuration ....................27 © 2010 Datacom Systems Inc DURAstream™... - Page 6 Section 8 Appendix 1 Heartbeat frame format ....................36 Section 9 Appendix 2 Console-Cable Drawing ....................38 Section 10 Customer Service 1 Internet ..................38 2 Warranty ..................38 3 Limits of Liability ..................38 DURAstream™ © 2010 Datacom Systems Inc...
-
Page 7: Section 1 Terms Of Use
9541. 1.2 License Agreement Notice To All Users: By using Datacom Systems, Inc. products, you agree to the terms set forth. No licenses, express or implied, are granted with respect to the technology described and Datacom Systems, Inc. retains all rights with respect to the technology described herein. If applicable, you may return the product to the place of purchase for a full refund. -
Page 8: Safety Notices And Warnings
E. Reliable Earthing — Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g. use of power strips). DURAstream™ © 2010 Datacom Systems Inc... -
Page 9: Section 2 Overview
Every unit not only comes with dual redundant power supplies to ensure monitoring uptime, the voltage of each power supply is continuously monitored for instances of power decline or outage. In such cases, the unit can initiate a switch to passive bypass mode. DURAstream™ © 2010 Datacom Systems Inc... -
Page 10: Shipped Contents
Manage device remotely or locally with Web based management (HTTPS) or extensive CLI Management port with SSH connectivity SNMP traps and e-mail event notifications on defined events Interfaces with authentication servers such as TACACS+ Syslog support DURAstream™ © 2010 Datacom Systems Inc... -
Page 11: Ds-1010 Series Common Specifications
2.4 DS-1010 Series Specific Specifications DS-1010LR-10G: 1 single mode fiber segment active bypass DS-1010SR-10G-50: 1 multi mode fiber (50µ) segment active bypass DS-1010SR-10G-62: 1 multi mode fiber (62.5µ) segments active bypass DURAstream™ © 2010 Datacom Systems Inc... -
Page 12: Technical Brief
Overview 2.5 Technical Brief DS-1010 is Datacom Systems' 10Gbps intelligent external Active Bypass Switch. The external active bypass enables plug and play connectivity, includes an auto heartbeat and requires no additional drivers to be installed on any connected appliance. DS-1010 consists of 1 segment which can support one network... -
Page 13: Section 3 Hardware Interface
Bypass LED — OFF for Inline state or ON for Bypass state 3.3 LCD Interface ™ The LCD displays the DURAstream 10G firmware version. The < and > keys and up arrow and down are reserved for future use. DURAstream™ © 2010 Datacom Systems Inc... -
Page 14: Section 4 Theory Of Operation
An inline appliance is connected on the single module using the following diagram: Figure 5. DS-1010 Bypass Switching Mode and Active Switching Mode Ports are designated as Appliance or Network Ports as shown below: Figure 6. Network and Appliance Ports DURAstream™ © 2010 Datacom Systems Inc... -
Page 15: Operation Modes
DS-1010 is always in Active Switching Mode. Mode 4: Manual Active Bypass DS-1010 is always in Bypass Switching Mode. Mode 5: Manual Passive Bypass DS-1010 is in passive bypass, where the optical switch is close in bypass mode. DURAstream™ © 2010 Datacom Systems Inc... -
Page 16: Normal Active Bypass
A2 will be bypassed. Heartbeat packets will continue to be sent out the Appliance port. This allows the module to automatically route traffic back through the appliance once it is repaired, or placed back into service. Figure 7. Normal Active Bypass Figure 8. Normal Active Bypass Device Failure DURAstream™ © 2010 Datacom Systems Inc... -
Page 17: Normal Active Inline
A2. Loss of heartbeats will direct traffic from N1 to A1 and N2 to A2. This mode may be used to make sure the heartbeat is flowing through the appliance, while network traffic is not flowing through the appliance. Figure 9. Normal Active Inline Figure 10. Normal Active Inline Heartbeat is Blocked DURAstream™ © 2010 Datacom Systems Inc... -
Page 18: Manual Active Inline
Figure 11. Manual Active Inline 4.1.4 Manual Active Bypass Traffic flows between N1 and N2. No heartbeat packets are sent, and the device will remain in this mode until changed. Figure 12. Manual Active Bypass DURAstream™ © 2010 Datacom Systems Inc... -
Page 19: Manual Passive Bypass
This may cause link downtime. Figure 13. Manual Passive Bypass DURAstream™ © 2010 Datacom Systems Inc... -
Page 20: Heartbeat (Hb)
Bypass Switch. During this no power state, the N1 and N2 ports will physically connect to create a passive bypass path without any traffic interruption between port N1 and port N2. DURAstream™ © 2010 Datacom Systems Inc... -
Page 21: Section 5 Initial Configuration
For example, towards the end of the "cli get" output for the DS-1010 will list the tap settings available. To set segment B N1 to receive on the tap port, type "cli set tap_b_n1 1" where "tap_b_n1" is the <variable> and "1" is the <option> for receive. DURAstream™ © 2010 Datacom Systems Inc... -
Page 22:
1 will enable email security feature. default: 1 email_server smtp server address for email report. email_subject email report subject. email_to email recipient lists. email_username email account user name. DURAstream™ © 2010 Datacom Systems Inc...List For Cli - Page 23 2 – Manual Active Inline. 4 – Manual Active Bypass. 5 – Manual Passive Bypass. The bypass switch will be closed, in bypass mode. password administrator password. default: admin DURAstream™ © 2010 Datacom Systems Inc...
- Page 24 3 letter definition default: PST username administrator account name: datacom login: default: admin web_theme web themes enable. 0 = disable, 1 = enable DURAstream™ © 2010 Datacom Systems Inc...
-
Page 25: Command Line Interface Usage
For example, “cli get timeout” will display timeout value in decimal form. To set a value for individual <variable>, “cli set <variable> <option> For example, “cli set timeout 20” will set timeout value to 20. DURAstream™ © 2010 Datacom Systems Inc... -
Page 26: Serial Port Configuration (Rj45)
Step 1. Using a supplied AC switching adapter and line cord, plug the DS-1010 into an AC power source. Step 2. Connect your PC and DS-1010 using the provided Datacom Systems CONSOLE cable. Create a HyperTerminal (terminal emulator) COM port (115,200, 8, None, 1, None) serial link. -
Page 27: Section 6 Management Port Configuration (Rj45)
(bypass or Inline) with the op_mode, defining the operation mode of the system: o [0]"Normal Active Bypass", o [1]”Normal Active Inline”, o [2]”Always Active Inline”, o [4]"Always Active Bypass", o [5]"Manual Passive Bypass" SNMP TRAP- For Cold or Warm power up (when device is powered up) DURAstream™ © 2010 Datacom Systems Inc... -
Page 28: Cli Setup
0 (NTP service: 0=DISABLED, 1=ENABLED) ntp_server default value is: us.pool.ntp.org 6.7 SYSLOG Definitions syslog default value = 0 (Syslog service: 0=DISABLED, 1=ENABLED syslog_host default value = localhost syslog_ident default value = datacom syslog_port default value = 514 DURAstream™ © 2010 Datacom Systems Inc... -
Page 29: Section 7 Secure Web Management
Figure 15. Certificate Error Page 7.1 Login Figure 16. Login , shows the User Login Page where the default user name is “admin” and “admin” is the password Figure 16. Login DURAstream™ © 2010 Datacom Systems Inc... -
Page 30: Status
Figure 18. Bypass Module Setting 7.4 Management Port , shows the Figure 19. Management Port Management Port options which can configure IP settings of the management port. Figure 19. Management Port DURAstream™ © 2010 Datacom Systems Inc... -
Page 31: Email Notifications
NTP uses UDP on port 123 as its transport layer. It is designed particularly to resist the effects of variable latency by using a jitter buffer. Figure 22. NTP Settings DURAstream™ © 2010 Datacom Systems Inc... -
Page 32: Time Settings
Internet Protocol (IP) computer network. It allows separation of the software that generates log messages from the system that stores the messages. Figure 26. Log Settings DURAstream™ © 2010 Datacom Systems Inc... -
Page 33: Reboot
Plus (TACACS+) which enables or disables the protocol which provides access control for routers, network access servers and other networked computing devices via one or more centralized servers. TACACS+ provides separate authentication, authorization and accounting services. Figure 29. TACACS+ DURAstream™ © 2010 Datacom Systems Inc... -
Page 34: Section 8 Appendix 1 Heartbeat Frame Format
Byte : 64 - 123 byte ( pattern = 0x55 ) ============================================================== Payload or Data : 0x55 0x55 … 0x55 Byte : 123 - 127 byte ( CRC Checksum field) ============================================================= This field is byte machine generated. <= CRC checksum DURAstream™ © 2010 Datacom Systems Inc... -
Page 35: Section 9 Appendix 2 Console-Cable Drawing
Pin 9 - No Connect Other 2 Sets of Wires: Orange/Orange Stripe and Brown/Brown Stripe Solid Orange and Brown Stripe should be connected together Stripe Orange and Solid Brown should be connected together DB9 Connector Pin Description DURAstream™ © 2010 Datacom Systems Inc... - Page 36 CAT5e Cable Wire Colors Top to Bottom Solid Brown wire Brown/White Stripe wire Solid Green wire Blue/White Stripe wire Solid Blue wire Green/White Stripe wire Solid Orange wire Orange/White Stripe wire CAT5e Cable Wire Colors (Bottom View) DURAstream™ © 2010 Datacom Systems Inc...
-
Page 37: Section 10 Customer Service
(315) 463-9541 or support@datacomsystems.com 10.3 Limits of Liability The warranties set forth above are exclusive and in lieu of all other warranties. Datacom Systems, Inc. (DSI) makes no other warranties, expressed or implied, and DSI expressly disclaims all other warranties, including but not limited to implied warranties of merchantability and fitness for a particular purpose. - Page 38 This page intentionally left blank © 2010 Datacom Systems Inc...
- Page 39 Datacom Systems Inc. 9 Adler Drive • East Syracuse, NY 13057 TEL: (315) 463-9541 • FAX: (315) 463-9557 http://www.datacomsystems.com Datacom Systems Inc Access Your Network...
