ACCOLADE
ACCOLADE
DESIGN, INSTALLATION AND

SERVICING INSTRUCTIONS

PLEASE LEAVE THESE INSTRUCTIONS IN THE POCkET PROVIDED ON
THE bACk Of THE fRONT PANEL
benchmark
TM
An unvented hot water storage unit complying with the
The code of practice for the installation,
requirements of Building Regulations Approved Document G3.
commissioning & servicing of central heating systems
Please read these instructions before commencing
installation and on completion leave adjacent in the pocket on
the back of the appliance front panel.
In the interest of continuously improving the Accolade
2000
range,
Gledhill Water Storage Ltd reserve the right to modify the product
without notice, and in these circumstances this booklet, which is
accurate at the time of printing, should be disregarded.
