Gems FS-600 Series Operating And Installation Instructions

Thermal dispersion flow switch no moving part

Advertisement

Prior to installation, confirm system versus sensor specifications and media compatibility of the sensor. Water hammer
effects should be minimized to prevent potential damage to the unit. Sensor can be mounted in any horizontal, vertical
or skewed orientation; however a fully filled flow body is required for accurate sensing. Correctly installed, the sensor
works maintenance free.

Installation

Apply a sparse amount of thread sealant (Permatex "No More Leaks"®) or Teflon® tape to the male threads intended
for installation. Ensure that the sealant does not enter into the sensor flow area. Hand-tighten the unit in place.
Tighten in additional 1/4 turn increments until a seal is achieved. Do not exceed one and one-half additional turns total.

Specifications

Wetted Materials
Probe
Flow Body
Operating Pressure (Max.)
Operating Temperature
Power on Delay Time
Response Time
Inlet/Outlet Ports
Operating Voltage
Current Consumption
Switch Contact Rating
Switch Logic
Ingress Protection
Set Point Accuracy
Set Point Differential
Electrical Termination
Approvals
Thermal Dispersion Flow Switch
FS-600 Series — No Moving Part
Operating and Installation Instructions
316 Stainless Steel
316 Stainless Steel
363 PSIG (25 bar)
-14°F to 140°F (-10°C to 60°C)
15 Seconds Max. (Output On)
10 Seconds Max.
1/2", 3/4", 1", 1-1/2" NPT
24 Vdc or 24 Vac +/-15%
Less than 50mA
30Vac@45mA, 42Vdc @65mA
Normally Open
IP65
15%
20% (Max.) at 5 to 20 CM/SEC,
15% (Max.) at 25 to 60 CM/SEC
M12 x 1 (4-Pin) (1 meter cable included)
CE
Instruction Bulletin No. 232790
Rev. B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS-600 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Gems FS-600 Series

  • Page 1: Specifications

    Instruction Bulletin No. 232790 Rev. B Thermal Dispersion Flow Switch FS-600 Series — No Moving Part Operating and Installation Instructions Prior to installation, confirm system versus sensor specifications and media compatibility of the sensor. Water hammer effects should be minimized to prevent potential damage to the unit. Sensor can be mounted in any horizontal, vertical or skewed orientation;...
  • Page 2 WIRING DIAGRAM Pin 1 (V+) - red Pin 2 (switch) - green Pin 4 (switch) - yellow Pin 3 (V-) - blue Gems Sensors & Controls | One Cowles Road | Plainville, CT 06062-1198 Telephone: 1-800-378-1600 | Email: info@gemssensors.com | www.GemsSensors.com...
