General Description
The ULS-100/10 Series Liquid Level Detection System is an ideal, low cost, ultrasonic liquid
level detection system for many applications. It operates in a broad spectrum of viscous to
light liquids.
Principle of Operation
The ULS-100/10 Series operates using ultrasonic sound wave propagation. Ultrasonic sound
waves are greatly attenuated when transmitted through air. Conversely, when liquid is
present, transmission of the sound waves is greatly enhanced. The electronic control unit
generates electrical signals that are converted to bursts of ultrasonic energy at the sensor. The
ultrasonic bursts are transmitted across the liquid sensing gap. Upon receipt of a valid signal,
the solid-state electronics generate a data enable condition, indicating liquid is present. This
signal energizes a relay to provide a contact closure or a 4 mA/20 mA, 2-wire current output.
GEMS
Mounting
Model No.
ULS-100
ULS-10
1. Standard sensor for contact type point level: 316 stainless steel.
2. Different sensor materials include Monel, Hastalloy, Titanium, Teflon,
Kynar, CPVC, PVC or any special metal, alloy. Consult Factory.
3. 3/4" NPT is standard, different NPT and flanges are optional.
4. Standard length of sensor is 1". Extension up to 120" is available.
Model Description
Input Power
Type
115 VAC/230 VAC
Integral
24 VDC/12 VDC
Remote
115 VAC/230 VAC
Integral
24 VDC
Remote
ULS-100/10
Ultrasonic Liquid Level Switches
Instruction Bulletin No. 146077
Output
10 Amp DPDT
"
10 Amp DPDT
2-wire 4/20mA
Notes:
Function
Standard Point
Level
"
Standard Point
Level
Advertisement
Table of Contents
Related Manuals for Gems ULS-100
Summary of Contents for Gems ULS-100
- Page 1 Ultrasonic Liquid Level Switches Instruction Bulletin No. 146077 General Description The ULS-100/10 Series Liquid Level Detection System is an ideal, low cost, ultrasonic liquid level detection system for many applications. It operates in a broad spectrum of viscous to light liquids.
- Page 2 Installation General The unit is easy to install. The sensor, with its integral electronics control unit, can be mounted in any position or orientation desired. Remote-mounted electronics are also possible. Make sure that all wiring, conduit and electrical fittings conform to local Electrical Codes for the location selected.
-
Page 3: Final Installation
Do not overtighten. 3. Run the power and control wiring cables to the electronics control unit. Observe all applicable electrical codes and proper wiring procedures. Wiring Diagram Model ULS-100 POWER Jumper High Level... - Page 4 Wiring Diagram Model ULS-10 Coaxial Cable To Sensor 9V DC to 42V DC Note - Two-Wire Unit - 4-20mA Output - 4 -...
- Page 5 Specifications and Dimensions (ULS-10 and ULS-100 Models) Model ULS-10 Repeatability - 2mm Typical 3-3/4" Delay (On) - 0.5 Seconds (Standard) Input Power - 115 VAC, 230 VAC, 50/60 Hz AC (Standard) 12 VDC & 24 VDC optional Outputs - 10A DPDT Relay (Standard) 3/4"...
- Page 6 Intrinsically Safe Installation (Model ULS-10) Hazardous Location Non-Hazardous Location Class I, II, III, Division 1 Groups A, B, C, D, E, G Associated Equipment Ca, La, Vac, Isc (See Note 2) Vmax Control Equipment Cable Entity Parameters: Vmax = 36 VDC Barriers Imax = 150 mA Safe Ground...
- Page 7 Maintenance Electronics are constructed with solid-state components and epoxy-potted. Periodically, check and clean the sensor when used with liquids which cause a coating build-up on the sensor. No other maintenance is required. Cleaning If the pipe or vessel to which the unit is mounted is to be steam-cleaned or cleaned with abra- sive detergents, remove the entire unit before cleaning by: (1) Disconnecting the power at source;...
- Page 8 GEMS' instruction manual. GEMS will repair or replace, at its option, FOB at its plant or any other location designated, any part which proves to be defective in manufacture or workmanship.
