- Page 1 ENGINEERING DESIGN GUIDE Commercial Horizontal Packaged Water Source Heat Pump: HBH Series 6-10 Tons Heat Controller, Inc. • 1900 Wellworth Ave. • Jackson, MI 49203 • (517)787-2100 • www.heatcontroller.com...
-
Page 2: Table Of Contents
Blower Performance Data - HBH120 Standard Unit ..................16-17 Physical Data ..............................18 HBH072-120 Dimensional Data ......................... 19 Electrical Data - Standard ........................... 20 Typical Wiring Diagram Three Phase HBH/V072-120 with CXM Controller ............21 HBH Series 60 Hz Engineering Specifi cations ....................22-25... -
Page 3: Selection Procedure
HBH SERIES Engineering Design Guide Heat Controller, Inc. Selection Procedure Reference Calculations Heating Cooling LWT = EWT - LC = TC - SC LWT = EWT + GPM x 500 GPM x 500 LAT = EAT + S/T = LAT (DB) = EAT (DB) - CFM x1.08... - Page 4 HBH SERIES Engineering Design Guide Heat Controller, Inc. Selection Procedure Example Equipment Selection For Cool ing Step 1 Determine the actual heating and cooling loads at the desired dry bulb and wet bulb conditions. Step 1 Load Determination: Step 2 Obtain the following de sign parameters: Entering water Assume you have determined that the appropriate cooling load temperature, water fl...
-
Page 5: Hbh Series Nomenclature
Heat Controller, Inc. HBH Series Nomenclature HBH Large Model Structure 4 5 6 0 9 6 Model Type HB = Heat Controller Compact Configuration Supply Air Flow Configuration S = Straight Supply H = Horizontal B = Back Supply Unit Size... -
Page 6: Performance Data - Ari/Ashrae/Iso 13256-1
HBH SERIES Engineering Design Guide Heat Controller, Inc. Performance Data AHRI/ASHRAE/ISO 13256-1 ASHRAE/AHRI/ISO 13256-1 English (I-P) Units Water Loop Heat Pump Ground Water Heat Pump Ground Loop Heat Pump Cooling 86°F Heating 68°F Cooling 59°F Heating 50°F Cooling 77°F Heating 32°F... -
Page 7: Performance Data Selection Notes
HBH SERIES Engineering Design Guide Heat Controller, Inc. Performance Data Selection Notes HBH096 For operation in the shaded area when water is used in lieu of WATER/BRINE Heating - EAT 70°F an antifreeze solution, the LWT (Leaving Water Temperature) FLOW must be calculated. -
Page 8: Performance Data Hbh072
HBH SERIES Engineering Design Guide Heat Controller, Inc. Performance Data HBH072 2,400 CFM Nominal Airfl ow Heating & Cooling Performance capacities shown in thousands of Btuh WATER/BRINE Cooling - EAT 80/67°F Heating - EAT 70°F Flow °F 20.0 15.8 Operation not recommended 49.5... -
Page 9: Performance Data Hbh096
HBH SERIES Engineering Design Guide Heat Controller, Inc. Performance Data HBH096 3,200 CFM Nominal Airfl ow Heating & Cooling Performance capacities shown in thousands of Btuh WATER/BRINE Cooling - EAT 80/67°F Heating - EAT 70°F Flow °F 24.0 10.2 23.5 Operation not recommended 67.1... -
Page 10: Performance Data Hbh120
HBH SERIES Engineering Design Guide Heat Controller, Inc. Performance Data HBH120 4,000 CFM Nominal Airfl ow Heating & Cooling Performance capacities shown in thousands of Btuh WATER/BRINE Cooling - EAT 80/67°F Heating - EAT 70°F Flow °F 30.0 16.0 36.9 Operation not recommended 91.8... -
Page 11: Performance Data Correction Tables
HBH SERIES Engineering Design Guide Heat Controller, Inc. HBH Performance Data – Correction Tables Air Flow Correction Table Percent Total Heat of Heating Heat of of Rated Sensible Power Power Capacity Rejection Capacity Extraction Airfl ow 0.962 0.869 0.947 0.959 0.959... -
Page 12: Antifreeze Correction Table
HBH SERIES Engineering Design Guide Heat Controller, Inc. Antifreeze Correction Table Cooling Heating Antifreeze Type Antifreeze % EWT 90°F EWT 30°F Corr. Fct. EWT 30°F Total Cap Sens Cap Power Htg Cap Power Water 1.000 1.000 1.000 0.995 0.995 1.003 0.989... -
Page 13: Blower Performance Data - Hbh072 Standard Unit
HBH SERIES Engineering Design Guide Heat Controller, Inc. Blower Performance Data - HBH072 Standard Unit All Data is Wet Coil SCFM 0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50 0.28 0.32 0.35 0.39... -
Page 14: Blower Performance Data - Hbh096 Standard Unit
HBH SERIES Engineering Design Guide Heat Controller, Inc. Blower Performance Data - HBH096 Standard Unit All Data is Wet Coil SCFM 0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50 0.45 0.50 0.54 0.59... - Page 15 HBH SERIES Engineering Design Guide Heat Controller, Inc. Blower Performance Data - HBH096 Standard Unit Table Continued from Previous Page All Data is Wet Coil SCFM 0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40...
-
Page 16: Blower Performance Data - Hbh120 Standard Unit
HBH SERIES Engineering Design Guide Heat Controller, Inc. Blower Performance Data - HBH120 Standard Unit All Data is Wet Coil SCFM 0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50 0.75 0.81 0.86 0.91... - Page 17 HBH SERIES Engineering Design Guide Heat Controller, Inc. Blower Performance Data - HBH120 Standard Unit Table Continued from Previous Page All Data is Wet Coil SCFM 0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40...
-
Page 18: Physical Data
HBH SERIES Engineering Design Guide Heat Controller, Inc. HBH Physical Data Model Compressor Quantity Scroll Number of Circuits (Compressors) Factory Charge HFC-410a (oz) [kg] per circuit 60 [1.70] 76 [2.15] 80 [2.27] Blower Motor Blower Motor Quantity Standard Motor (hp) [kW] 1 [0.75]... -
Page 19: Hbh072-120 Dimensional Data
HBH SERIES Engineering Design Guide Heat Controller, Inc. HBH072-120 Dimensional Data ALL CONFIGURATIONS REQUIRE SERVICE ACCESS AREA DESCRIBED IN NOTES 5 AND 6. RIGHT RETURN STRAIGHT DISCHARGE LEFT RETURN STRAIGHT DISCHARGE Note 6 Note 5, 6 LEGEND CAP=Compressor Access Panel... -
Page 20: Electrical Data - Standard
HBH SERIES Engineering Design Guide Heat Controller, Inc. HBH Electrical Data – Standard Compressor Total SCCR ka SCCR Voltage Min/Max Blower FLA/ Model # Voltage Motor Circuit Volts Fuse/ Code Voltage Option Rated symetrical Maximum HACR Current 208-3-60 197/254 A, B, C 10.4... -
Page 21: Typical Wiring Diagram Three Phase Hbh/V072-120 With Cxm Controller
HBH SERIES Engineering Design Guide Heat Controller, Inc. Typical Wiring Diagram Three Phase HBH/V072-120 with CXM Controller... -
Page 22: Hbh Series 60Hz Engineering Specifi Cations
Engineering Specifi cations – Page 1 General: Furnish and install the HBH Series as indicated on the plans. Equipment shall be completely assembled, piped and internally wired. Capacities and characteristics as listed in the schedule and the specifi cations that follow. -
Page 23: Hbh Series 60 Hz Engineering Specifi Cations
HBH SERIES Engineering Design Guide Heat Controller, Inc. HBH Series 60Hz Engineering Specifi cations – Page 2 Fan and Motor Assembly: All units shall have belt-driven single centrifugal fan. Fan motor shall be permanently lubricated with thermal overload protection. Units supplied without permanently lubricated motors must provide external oilers for easy service. - Page 24 HBH SERIES Engineering Design Guide Heat Controller, Inc. HBH Series 60Hz Engineering Specifi cations – Page 3 The unit as standard will be supplied with solid-state electronic condensate overfl ow protection. Mechanical fl oat switches will NOT be accepted. Option: The unit shall be supplied with stainless steel drain pan.
- Page 25 HBH SERIES Engineering Design Guide Heat Controller, Inc. HBH Series 60Hz Engineering Specifi cations – Page 4 FIELD INSTALLED OPTIONS Hose Kits: All units 120000 BTUH (35 kW) and below shall be connected with hoses. The hoses shall be 2 feet (61cm) long, braided stainless steel;...
- Page 26 04/2014...
