PARTS LIST
OPERATING AND
SERVICE MANUAL
LEGEND
"P" SERIES
BLOWERS
6" – 8" GEAR
DIAMETER
Models
GAF_ _ P _
GAG_ _ P _
GAH_ _ P _
SB-7-622
Version 04
July 9, 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEGEND P Series and is the answer not in the manual?

Questions and answers

Related Manuals for Gardner Denver LEGEND P Series

Summary of Contents for Gardner Denver LEGEND P Series

  • Page 1 PARTS LIST OPERATING AND SERVICE MANUAL LEGEND “P” SERIES BLOWERS 6” – 8” GEAR DIAMETER Models GAF_ _ P _ GAG_ _ P _ GAH_ _ P _ SB-7-622 Version 04 July 9, 2015...

  • Page 2: Maintain Blower Reliability And Performance

    Rely upon the knowledge and experience of your AUTHORIZED DISTRIBUTOR and let them assist you in making the proper parts selection for your blower. For the location of your local authorized Gardner Denver blower distributor refer to the yellow pages of your phone directory, check the Web site at www.gardnerdenver.com...
  • Page 3 5 Gallon Pail 28H99 55 Gallon Drum 28H100 Drive End AEON PD Grease Description Part Number Case/10 Tubes 28H283 Call your local Sutorbilt Distributor to place your order for Gardner Denver lubricants. Your Authorized Gardner Denver Distributor is: SB-7-622 Page 2...

  • Page 4: Foreword

    FOREWORD â Sutorbilt blowers are the result of advanced engineering and skilled manufacturing. To be assured of receiving maximum service from this machine, the owner must exercise care in its operation and maintenance. This book is written to give the operator and maintenance department essential information for day-to-day operation, maintenance and adjustment.

  • Page 5: Safety Precautions

    SAFETY PRECAUTIONS Safety is everybody’s business and is based on your use of good common sense. All situations or circumstances cannot always be predicted and covered by established rules. Therefore, use your past experience, watch out for safety hazards and be cautious. Some general safety precautions are given below: Failure to observe these notices could result in injury to or death of personnel.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS Maintain Blower Reliability And Performance ....................... 1 Foreword ................................3 Safety Precautions ............................... 4 Sutorbilt Legend Series Blowers Matrix/Menu ...................... 8 Introduction ................................9 Section 1, Equipment Check ..........................10 Section 2, Installation ............................11 Section 3, Lubrication ............................14 Section 4, Operation ............................
  • Page 7 INDEX Air Filters And Filter Silencers .......14 Lubrication, Section 3 Assembly Instructions, Section 7 ......26 Lubrication ............14 Blower Startup Checklist ........17 Mechanical Seals Only ........26, 27 Disassembly Instructions, Section 6 ......23 Mounting Configurations ........11 Disassembly Instructions ........23 Operation, Section 4 Drive Installation ...........12 Operation .............

  • Page 8: Sutorbilt Legend Series Blowers Matrix/Menu

    SUTORBILT LEGEND SERIES BLOWERS MATRIX/MENU NOTICE TO CUSTOMER – To find the construction options for Your blower unit, FILL IN THE BALANCE OF LETTERS OR __ __ __ __ __ __ __ NUMBERS FROM YOUR UNIT NAMEPLATE COLUMN NUMBER FOLLOW THE LINE DOWN AND OVER FROM EACH SPACE THUS FILLED IN TO FIND THE APPROPRICATE CONSTRUCTION OPTION WITH WHICH YOUR MACHINE IS EQUIPPED.

  • Page 9: Introduction

    Your Sutorbilt blower is a precision engineered blower that has been carefully manufactured and thoroughly tested at the state-of the art Gardner Denver Blower Factory in Sedalia, Missouri. As with other precision machinery, there are several relatively simple installation, operation and maintenance procedures that you must observe to assure optimum blower performance.

  • Page 10: Section 1, Equipment Check

    STORAGE shipment. These covers must be removed before Your Gardner Denver Blower was packaged at the start-up. factory with adequate protection to permit normal The internal surfaces of all Sutorbilt units are mist storage for up to six (6) months.

  • Page 11: Section 2, Installation

    SECTION 2 INSTALLATION LOCATION anchored to adequate structural members, restricting movement and vibration. MOUNTING CONFIGURATIONS Install the blower in a well lit, clean dry place with plenty of room for inspection and maintenance. The blower flex-mount design enables horizontal FOUNDATIONS and vertical mounting configurations with top or bottom hand, right or left hand shaft positioning.

  • Page 12: Drive Installation

    4. Secure the mounting feet capscrews to the torque sheave positioning is as close as possible to the blower drive cover, not to exceed dimension “C” in Drive Shaft value in Figure 7-8, page 34. Illustration, FIGURE 2- , page 13 NOTICE The calculated shaft moment must not exceed the Over tightening belts leads to heavy bearing...

  • Page 13: Figure 2- 2 - Belt Drive Overhung Load Calculations

    Maximum Gear Dimensions Allowable Diameter (Inches) Moment (Inches) (LB-IN) (Max) 4.08 1.14 1788 4.50 1.31 3000 5.57 1.77 4144 MAXIMUM ALLOWABLE MOMENT DRIVE SHAFT ILLUSTRATION 0.000 1.000 0.250 0.966 0.500 0.926 0.750 0.879 1.000 0.823 1.250 0.751 0.025 0.997 0.275 0.962 0.525 0.922...

  • Page 14: Section 3, Lubrication

    SECTION 3 LUBRICATION FIGURE3- - LUBRICATION At the gear end the timing gear teeth are lubricated by being partially submerged in oil. The gear teeth serve as oil slingers for gear end bearings. At the drive end the bearings are grease lubricated. FILLING PROCEDURE Refer to Figure 3-1.

  • Page 15: Gear End Lubrication

    GEAR END LUBRICATION AEON PD Synthetic Blower Lubricant is recommended. Refer to FIGURE 3-3, for AEON PD, AEON PD-FG (Food Grade) and AEON PD-XD (Extreme Duty) part numbers. Order AEON PD from your Gardner Denver Distributor or call Gardner Denver directly.

  • Page 16: Section 4, Operation

    SECTION 4 OPERATION Future operating problems can be avoided if proper precautions are observed when the equipment is first put into service. Before starting under power, the blower should be turned over by hand to make certain there is not binding or internal contact.

  • Page 17: Blower Startup Checklist

    BLOWER STARTUP CHECKLIST This startup procedure should be followed during the initial installation and after any shutdown periods or after the blower has been worked on or moved to new location. It is suggested that the steps be followed in sequence and checked off (√) in the boxes provided.

  • Page 18: Safety Precautions

    SAFETY PRECAUTIONS 1. Do not operate blower with open inlet or outlet port. 2. Do not exceed specified vacuum or pressure limitations. 3. Do not operate above or below recommended blower speed range. 4. Blower is not to be used where non-sparking equipment is specified. 5.

  • Page 19: Special Tools Required Section 5

    SECTION 5 MAINTENANCE FIGURE 5- 1 – PULLER PLATE – SK2154 SB-7-622 Page 18...

  • Page 20: Figure 5- 2 - Gear Driven - Sk2150

    FIGURE 5- 2 – GEAR DRIVEN – SK2150 SB-7-622 Page 19...

  • Page 21: Figure 5- 3 - Mechanical Seal Installation Tool - Sk2152

    FIGURE 5- 3 – MECHANICAL SEAL INSTALLATION TOOL – SK2152 SB-7-622 Page 20...
  • Page 22 FIGURE 5-1 – BEARING PRESS TOOL – MECHANCIAL SEAL UNITS – SK2156 FIGURE 5- 4 SB-7-622 Page 21...

  • Page 23: Section 6, Disassembly Instructions

    SECTION 6 DISASSEMBLY INSTRUCTIONS NOTICE Numbers in parentheses ( ) refer to key numbers in assembly drawings on pages 35, 37and 39. 1. Drain oil from gear case by removing drain plug (4). 2. Remove the socket head bolts (5) from the gear cover (3). 3.

  • Page 24: Figure 6-

    FIGURE 6- 4 FIGURE 6- 3 NOTICE If backlash is above the specified limit, the gears are not necessarily unusable. Excessive play could be caused by worn bearings. 5. If timing gears appear to be reusable, match mark timing gear tooth mesh by making small punch marks on the ends of meshing gear teeth with a pin punch and hammer (see FIGURE 6-2, page 25).

  • Page 25: Figure 6-

    12. Remove the two drive end bearings (14) from the drive headplate (24) using a ball peen hammer and punch (see Figure 6-5, page 26). Exercise care not to damage the headplate bearing bores when removing bearings. 13. Remove the drive end spacers (33), (34) and (41). The grease seals (15) can now be driven out of the drive headplate with hammer and punch (see Figure 6-5, page 27).

  • Page 26: Section 7, Assembly Instructions

    SECTION 7 ASSEMBLY INSTRUCTIONS NOTICE Numbers in parentheses ( ) refer to key numbers in assembly drawings on pages 35, 37, 39 and 41. 1. Make sure all metallic parts are clean and free of any nicks or burrs. 2. Lubricate the outside diameter of the lip seal (15) with a light oil or grease. Install seals in both the drive headplate (24) and gear headplate (18).

  • Page 27: Figure 7-

    FIGURE 7- 3 FIGURE 7- 2 3. Assemble gear headplate (18) and mounting foot (17) to the impeller case with cap screws (21) and where the mounting foot is secured to the headplate use capscrews (16). The two positioning dowel pins (19) will ensure proper alignment of the headplate and impeller case.

  • Page 28: Figure 7-

    Do not drive the mating ring down to the mechanical seal, as this can damage the seal. C. Install mating ring (B) on the drive end short shaft and the gear end shaft as done in the previous step, but use spacer (33) (refer to gear end Figure 7-1, page 29).

  • Page 29: Figure 7-

    11. Impeller should now be checked for free axial movement by hitting the ends of the impeller shafts with the palm of your hand. 12. Push the impellers against the gear headplate and recheck the total end clearance between the drive headplate and the impellers (see FIGURE 7-4, page 31).

  • Page 30: Figure 7-

    16 SETTING IMPELLER END CLEARANCE Refer to Figure 7-1, page 29. The gear end bearings are held in position by the force created by the wavy spring (28) on the drive end and the bearing retainer (12) on the gear end. The interference fit between the shaft (H) and the bearing inner race (E) keeps the shaft from moving axially.
  • Page 31 NOTICE Replacement gears have minimum backlash marks on the outside diameter of the gear face. These marks should be located 180 degrees from each other (see Figure 7-6).. F. Position impellers so they are 90 degrees to each other. Using the driving tool shown on page 22, install the gears and hubs on the shafts using the taper pin holes and match marks for correct positioning.

  • Page 32: Figure 7- 7 - Torque (Ft-Lbs.)

    Ref. GEAR DIAMETER FASTENERS Screw – Gear Case Headplate Screw – Bearing Retainer to Headplate Screw – Mounting Foot to Headplate Screw – Headplate to Impeller Case Screw - Drive Cover to Headplate Screw – Timing Hub to Gear NOTE: REF. NO. DENOTES ITEMS IN EXPLODED VIEW DRAWINGS ON PAGES 36, 38, AND 40. FIGURE 7- 7 –...

  • Page 33: Section 8, Parts List

    SECTION 8 PARTS LIST 300GAF810-B (Ref. Drawing) SB-7-622 Page 32...
  • Page 34 Order by Part Number and Description. Reference Numbers are for your convenience only. Ref. Size -- 6H Size -- 6M Size -- 6L Description Req’d GAFH_P_ GAFM_P_ GAFL_P_ NAMEPLATE ................. 301GAE496 301GAE496 301GAE496 PLUG FOR ALTERNATE OIL LEVEL CONN......64AC4 64AC4 64AC4...
  • Page 35 300GAG810-A (Ref. Drawing) SB-7-622 Page 34...
  • Page 36 Order by Part Number and Description. Reference Numbers are for your convenience only. Size -- 7M Size -- 7L Ref. Size -- 7H GAGM_P_ GAGL_P_ Description Req’d GAGH_P_ 301GAE496 301GAE496 NAMEPLATE ................301GAE496 64B4 64B4 PLUG FOR ALTERNATE OIL LEVEL CONN......64B4 GEAR CASE ................
  • Page 37 300GAH810-A (Ref. Drawing) SB-7-622 Page 36...
  • Page 38 Order by Part Number and Description. Reference Numbers are for your convenience only. Ref. Size -- 8H Size -- 8M Size -- 8L Description Req’d GAHH_P_ GAHM_P_ GAHL_P_ NAMEPLATE ................ 301GAE496 301GAE496 301GAE496 PLUG FOR ALTERNATE OIL LEVEL CONN..... 64AC5 64AC5 64AC5...
  • Page 39 SB-7-622 Page 38...
  • Page 40 Gardner Denver, Inc. 1800 Gardner Expressway, Quincy, IL 62305 Customer Service Department Telephone: (800) 682-9868 FAX: (217) 221-8780 © 2015 Gardner Denver, Inc. Litho in U.S.A.
