Setup
Mate Focus / Iris Gears
Mate the focus and iris gears as shown in the image below. Pivot the housing
gears (shown in RED color) to engage the corresponding gears on the Nikonos RS
mount.
Secure the focus / iris gears by tightening the screws with the 3/32 ball driver.
Step 1. Pivot the focus / iris gears
to mate with the Nikonos RS mount
gears.
Step 2. Secure by tightening the
pivot screw with 3/32 ball driver
included with the Pro Action tool kit.
Page 7
