NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Magnetic-Resistance
Safety Notice
Deluxe Rowing Machine
Hardware Pack
AMZ-986RW
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
AMZ-986RW
Retain This
Manual for
Reference
®
IMPEX
INC.
190613
2801 S. Towne Ave, Pomona, CA 91766
Tel: (800) 999-8899 Fax: (626) 961-9966
ASSEMBLY &
www.marcypro.com
OWNER'S
support@impex-fitness.com
MANUAL
Advertisement
Table of Contents
Related Manuals for Impex Circuit Fitness AMZ-986RW
Summary of Contents for Impex Circuit Fitness AMZ-986RW
- Page 1 Hardware Pack AMZ-986RW Assembly Instruction Parts List Warranty Ordering Parts Model AMZ-986RW Retain This Manual for Reference ® IMPEX INC. 190613 2801 S. Towne Ave, Pomona, CA 91766 Tel: (800) 999-8899 Fax: (626) 961-9966 ASSEMBLY & www.marcypro.com OWNER'S support@impex-fitness.com MANUAL...
-
Page 2: Table Of Contents
BEFORE YOU BEGIN Thank you for selecting the CIRCUIT FITNESS Magnetic-Resistance Deluxe Rowing ® Machine AMZ-986RW by IMPEX INC. For your safety and benefit, read this manual carefully before using the bike. As a manufacturer, we are committed to provide you complete customer satisfaction. -
Page 3: Important Safety Notices
BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES RESPONSIBILITY PERSONAL INJURY PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. -
Page 4: Warning Label Placement
WARNING LABEL PLACEMENT The Warning Labels shown here has been placed on the Front Stabilizer. If the labels are missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the labels in location shown. © IMPEX INC. www.marcypro.com... -
Page 5: Hardware Pack
Collar ¾” Allen Bolt M8x ⅝” Allen Bolt M8x1 Stopper ½” Allen Bolt M6x Flat washer Axle for pedal Acorn nut M8 ¾ Carriage bolt M8*1 Curve washer Lock Washer Flat washer Axle for slide rail © IMPEX INC. www.marcypro.com... -
Page 6: Component For Assembly
Knob Allen Wrench Allen Key 4MM Allen Key 6MM COMPONENTS FOR ASSEMBLY NO:31L/R NO:26 NO:23 NO:5 NO:15 NO:28 NO:2 NO:9 NO:37 © IMPEX INC. www.marcypro.com... -
Page 7: Important Assembly Instruction
Attach front post (51) to Main frame (5) and secure with one set of allen bolts (11) & curved washers (10) and from the sides with two sets of allen bolts (11) and flat washers (3). © IMPEX INC. www.marcypro.com... - Page 8 Attach the left pedal (31L) to the left bracket of the pedal support tube (37), secure using one axle for pedal (34), two allen bolts (32) and two flat washers (33). Repeat the same procedure for right pedal (31R). © IMPEX INC. www.marcypro.com...
- Page 9 Attach the pedal support tube (37) to bottom of the main frame (5). Secure using two carriage bolts (36), two flat washers (3) and two acorn nuts (35). STEP 6 Attach middle stabilizer (28) to main frame (5), secure with 4 sets of allen bolts (11) and flat washers (3). © IMPEX INC. www.marcypro.com...
- Page 10 Attach the rear stabilizer (26) to the back of the slide rail (15). Secure one allen bolt (11) and one flat washer (3) on the front of the rear stabilizer, then secure two allen bolts (24) and two flat washers (3) on the rear of the stabilizer. Thread two stoppers (27) into rear stabilizer (26). © IMPEX INC. www.marcypro.com...
- Page 11 (17). Attach the end caps (14L & 14R) to the end of the slide rail (15). STEP 10 Pull out the locking pin (8) from the main frame and unfold the slide rail (15) slowly. © IMPEX INC. www.marcypro.com...
- Page 12 Set rear stabilizer to the floor and insert locking pin (8) to lock the frame into place. Note: if there is resistance when inserting the locking pin, slightly lift the middle stabilizer, and it will make inserting the pin easier. © IMPEX INC. www.marcypro.com...
-
Page 13: Exploded Diagram
EXPLODED DIAGRAM © IMPEX INC. www.marcypro.com... - Page 14 EXPLODED DIAGRAM © IMPEX INC. www.marcypro.com...
-
Page 15: Parts List
Seat support plate Seat Allen bolt M8x1 9/16 End cap for slide rail Rear stabilizer Stopper Middle stabilizer Self-tapping screw ST5*15 End cap for middle stabilizer Pedal L/R Allen bolt M6x½” Flat Washer Ф6*Ф17 Axle for Pedal © IMPEX INC. www.marcypro.com... - Page 16 Self-tapping screw 5*9/16 Powder bushing Bearing Wheel Axle for wheel Allen bolt M8x2 3/16” Magnetic assembly 66L/R Decorative cover L/R Lock washer Ф8 Flat Washer Ф8*Ф1 Axle for slide rail 8-level tension gear Hex nut M6 Tension wire © IMPEX INC. www.marcypro.com...
-
Page 17: Care And Maintenance, Weight Capacity & Dims
9. Folded Dimension (L x W x H): 49”x20.5”x51” OPERATING NOTES TRANSPORT The Rower has a pair of roller wheels on Front Stabilizer End Cap. To move, fold up the Rower; carefully hold and tilt the Rower, and then roll. © IMPEX INC. www.marcypro.com... -
Page 18: Computer
(not included). CALENDAR: The computer will display year, month, and day when computer is in sleep mode. TEMPERATURE: The computer will display the current room temperature when the computer is in sleep mode. © IMPEX INC. www.marcypro.com... - Page 19 (2) RACE (Fig.5) ： A. Select RACE mode and L9 will flash. The TIME/500M will display 4:00. Then, press UP or DOWN to select L1 ~ L15. Press ENTER to confirm. Then, you can set the distance © IMPEX INC. www.marcypro.com...
- Page 20 Alarm only works while the computer is in sleep mode. Alarm will not sound during exercise. Press and hold RESET to go to clock screen to set up ALARM. SLEEP MODE The computer will go into sleep mode after about 4 minutes of inactivity. BATTERY © IMPEX INC. www.marcypro.com...
-
Page 21: Exercise Guidelines
Work to your targeted heart rate but it is very important to maintain a steady tempo throughout. The rate of work should be sufficient to raise your heartbeat into the target zone shown on the graph below. © IMPEX INC. www.marcypro.com... -
Page 22: Weight Loss
The important factor here is the amount of effort you put in. The harder and longer you work the more calories you will burn. Effectively this is the same as if you were training to improve your fitness, the difference is the goal. © IMPEX INC. www.marcypro.com... -
Page 23: Warranty
IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
