- Page 1 ® WELDPLAST Leister Process Technologies Galileo-Strasse 10 CH-6056 Kaegiswil/Switzerland Tel. +41 41 662 74 74 +41 41 662 74 16 www.leister.com sales@leister.com...
-
Page 2: Weldplast S6
(Translation of the original operating instructions) Please read operating instructions carefully before use and keep for further reference. Leister WELDPLAST S6 Hand extruder Application Hand extruder for welding thermoplastics from PE and PP filler rod with a diameter of 4 and 5 mm (other materials on enquiry) in the construction of containers, apparatus, pipelines and storage sites. -
Page 3: Leister Process Technologies Galileo-Strasse
Conformity Leister Process Technologies, Galileo-Strasse 10, CH-6056 Kaegiswi/Switzerland confirms that this product, in the version as brought into circulation through us, fulfils the requirements of the following EC directives. Directives: 2004/108, 2006/95 Harmonized Standards: EN 55014-1, EN 55014-2, EN 61000-6-2, EN 61000-3-11, EN 61000-3-12, EN 50366, EN 62233, EN 60335-2-45 Kaegiswil, 15.05.2009... - Page 4 Operating Leister WELDPLAST S6 hand extruder Description of tool 1 Main switch 9 Pre-heating nozzle 2 On/off switch drive 10 Tube clamp 3 Potentiometer 11 Protective tube 4 Drive locking device 12 Welding rod opening 5 Display 13 Tool handle...
- Page 5 Operating Leister WELDPLAST S6 hand extruder Working environment / safety The hand extruder must not be used in inflammable environments or where explosion hazards exist. Ensure stable positioning during operation. The connection cable and the welding rod must remain unimpeded and must not hinder the user or others during operation.
- Page 6 Operating Leister WELDPLAST S6 hand extruder Power supply If an extension cable is used, it should have a cross section of at least 3 × 4mm must be permitted for the place where it is being used (e.g. outside) and labelled accordingly.
- Page 7 Operating Leister WELDPLAST S6 hand extruder Software and menu guide The Weldplast manual welding extruder is fitted with convenient software, which makes wor- king with the extruder easy for the user. Key functions Tap lightly on the keys to operate them.
- Page 8 Operating Leister WELDPLAST S6 hand extruder Setting parameters in the operating window The cursor (31) shows which parameters can be set. After switching on, the cursor is on the «SPEED» position. In the operating window, the following parameters can be selected with the Select key (28) and changed in their values with the Up key (29) and Down key (27).
- Page 9 Operating Leister WELDPLAST S6 hand extruder Setting the PLAST and AIR temperatures • Set the cursor to the «PLAST» or «AIR» position by pressing the Select key (28). • Set the temperature value with the Up (29) or Down (27) keys.
- Page 10 Operating Leister WELDPLAST S6 hand extruder Starting the welding process • Fit the appropriate welding shoe (8) as required. • Set the potentiometer (3) to max. • Once the operating temperature is reached («READY*» status), welding can begin. • Actuate the drive on/off switch (2).
- Page 11 Operating Leister WELDPLAST S6 hand extruder Further settings Contrast setting Given unfavourable lighting conditions and fluctuations in the ambient temperature, the contrast on the display can be set in the operating window with the back key (25). Heating on/off In the case of long interruptions (standby), the heating for PLAST and AIR can be deactivated with the Enter key (26) in the operating window.
- Page 12 Operating Leister WELDPLAST S6 hand extruder Menüführung Menu Menu Scroll Select Functions Scroll Select and return Return to operating window Scroll...
- Page 13 Operating Leister WELDPLAST S6 hand extruder Welding parameters – Programming Free Menu setting Select program Scroll Enter The hand extruder is suitable for the following types of thermoplastic: • PP / PE-HD / PE-LD Programs 1-3 are provided with preset values which can be adjusted during the welding process.
- Page 14 Operating Leister WELDPLAST S6 hand extruder Replacing the welding shoe • The welding shoe must only be replaced when the tool has attained its operating temperature. Work with temperature resistant gloves only. Danger of getting burned! • Dismounting Turn off the device while warm and disconnect from the power supply.
- Page 15 Troubleshooting Leister WELDPLAST S6 hand extruder Error messages Err04 An error occurring is shown in the status display (30) (e.g Motor is overheated). ErrXX Display When an error occurs, the heating units for AIR and PLAST, as well as the drive motor, are...
- Page 16 • To ensure optimal rod dispensing, the welding rod should be passed through the eyelets (41) provided. Welding-shoe assortment WELDPLAST S6 standard Leister Process Technologies offers welding shoes for all the common seam geometries in various sizes: Blank V weld...
- Page 17 Service and repair • Repairs should only be carried out by authorized Leister Service Centres. They gua- rantee a specialised and reliable Repair Service within 24 hours using original spare parts in accordance with the circuit diagram and spare parts list.
-
Page 20: Sales@Leister.com
® © Copyright by Leister Your authorised Service Centre is: Leister Process Technologies Galileo-Strasse 10 CH-6056 Kaegiswil/Switzerland Tel. +41 41 662 74 74 +41 41 662 74 16 www.leister.com sales@leister.com...
