bonitron M3460D Customer Reference Manual

Diode sharing module for ride-thru applications

Advertisement

Quick Links

Model M3460D
Diode Sharing Module
For Ride-Thru Applications
Customer Reference Manual
Web: www.bonitron.com
Tel: 615-244-2825
Email: info@bonitron.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M3460D and is the answer not in the manual?

Questions and answers

Summary of Contents for bonitron M3460D

  • Page 1 Model M3460D Diode Sharing Module For Ride-Thru Applications Customer Reference Manual ● ● Web: www.bonitron.com Tel: 615-244-2825 Email: info@bonitron.com...
  • Page 2 Bonitron has seen thousands of products engineered since 1962 and welcomes custom applications. With engineering, production, and testing all in the same facility, Bonitron is able to ensure its products are of the utmost quality and ready to be applied to your application.
  • Page 3 RIVE PTIONS In 1975, Bonitron began working with AC inverter drive specialists at synthetic fiber plants to develop speed control systems that could be interfaced with their plant process computers. Ever since, Bonitron has developed AC drive options that solve application issues associated with modern AC variable frequency drives and aid in reducing drive faults.
  • Page 4 M3460D This page intentionally left blank...
  • Page 5: Table Of Contents

    EATURES 2.1. Related Products ........................... 9 2.2. Part Number Breakdown ......................9 Figure 2-1: Example of M3460D Part Number Breakdown ................ 9 Table 2-1: Chassis Codes ..........................9 2.3. General Specifications ........................ 10 Table 2-2: General Specifications Chart ....................10 2.4.
  • Page 6 M3460D This page intentionally left blank...
  • Page 7: Introduction

    URPOSE AND COPE This manual is a user’s guide for the Model M3460D Diode Sharing Module. It will provide the user with the necessary information to successfully install, integrate, and use the M3460D module in a variable frequency AC drive system.
  • Page 8: Symbol Conventions Used In This Manual And On Equipment

    M3460D 1.1. YMBOL ONVENTIONS SED IN THIS ANUAL AND ON QUIPMENT Earth Ground or Protective Earth AC Voltage DC Voltage DANGER: Electrical hazard - Identifies a statement that indicates a shock or electrocution hazard that must be avoided. DANGER! DANGER: Identifies information about practices or circumstances that can lead to personal injury or death, property damage, or economic loss.
  • Page 9: Product Description / Features

    ESCRIPTION EATURES Bonitron’s M3460D Diode Sharing Modules are designed to offer system integrators a low cost solution for using a DC Bus Ride-Thru Module (RTM) with multiple fixed bus Variable Frequency Drives. The modules provide isolation for positive current flow to the drive.
  • Page 10: General Specifications

    ENERAL PECIFICATIONS Table 2-2: General Specifications Chart ARAMETER PECIFICATION 230 VAC, 460 VAC Voltage (Please consult with Bonitron regarding special requirements) Current Input Ratings 85, 170, 255, 340, 425 Current (each output) Up to 90 amps Maximum Run Time 4 minutes...
  • Page 11: General Precautions And Safety Warnings

    User’s Manual 2.4. ENERAL RECAUTIONS AND AFETY ARNINGS ▪ H IGH VOLTAGES MAY BE PRESENT ▪ N EVER ATTEMPT SERVICE THIS PRODUCT WITHOUT FIRST DISCONNECTING POWER TO AND FROM THE UNIT DANGER! ▪ A LWAYS ALLOW ADEQUATE TIME FOR RESIDUAL VOLTAGES TO DRAIN BEFORE REMOVING THE ENCLOSURE COVER ▪...
  • Page 12 M3460D This page intentionally left blank...
  • Page 13: Installation Instructions

    User’s Manual NSTALLATION NSTRUCTIONS 3.1. RODUCT NSPECTION Upon receipt of this product, please verify that the product received matches the product that was ordered and that there is no obvious physical damage to the unit. If the wrong product was received or the product is damaged in any way, please contact the supplier from which the product was purchased.
  • Page 14: Typical Configurations

    M3460D 3.4.1.1. ONNECTION The DC bus input should be connected to the output of the Ride-Thru module. Make sure that the DC bus connection polarity is correct. Improper polarity connections carry a high risk of damaging drive equipment if energized.
  • Page 15: Operation

    User’s Manual PERATION 4.1. UNCTIONAL ESCRIPTION The Diode Sharing Module isolates the DC bus connections of multiple drives to keep from generating circulation currents in the AC bridges of the drives. This ensures that the input bridges of each drive do not supply power to other drives in the network, or allow circulating currents between drives.
  • Page 16 M3460D This page intentionally left blank...
  • Page 17: Maintenance And Troubleshooting

    User’s Manual AINTENANCE AND ROUBLESHOOTING Repairs or modifications to this equipment are to be performed by Bonitron approved personnel only. Any repair or modification to this equipment by personnel not approved by Bonitron will void any warranty remaining on this unit.
  • Page 18 M3460D This page intentionally left blank...
  • Page 19: Engineering Data

    User’s Manual NGINEERING 6.1. ATINGS HARTS Table 6-1: M3460D Diode Ratings UMBER OMINAL HP RIVE URRENT EATSINK UMBER USES 230V 460V RIVES ATING ATING M3460D-3H-10 30 A 30 W ATM-10 M3460D-6J-10 30 A 60 W ATM-10 M3460D-3H-30 30 A 90 W...
  • Page 20: Dimensions And Mechanical Drawings

    M3460D 6.3. IMENSIONS AND ECHANICAL RAWINGS Figure 6-1: Typical “H” Chassis Dwg: 980121 Rev: 20001018...
  • Page 21: Figure 6-2: Typical "J" Chassis

    User’s Manual Figure 6-2: Typical “J” Chassis Dwg: 050047 Rev: 20050323...
  • Page 22: Figure 6-3: Typical "L" Chassis

    M3460D Figure 6-3: Typical “L” Chassis Dwg: 980209 Rev: 20001018...
  • Page 23: Figure 6-4: Typical "N" Chassis

    User’s Manual Figure 6-4: Typical “N” Chassis Dwg: 980210 Rev: 20060125...
  • Page 24: Figure 6-5: Typical "P4" Chassis

    M3460D Figure 6-5: Typical “P4” Chassis Dwg: 050046 Rev: 20050323...
  • Page 25: Figure 6-6: Typical "P6" Chassis

    User’s Manual Figure 6-6: Typical “P6” Chassis Dwg: 010293 Rev: 20011010...
  • Page 26: Figure 6-7: Typical "P2" Chassis

    M3460D Figure 6-7: Typical “P2” Chassis Dwg: 080221 Rev: 20080519...
  • Page 27: Figure 6-8: Block Diagram Example Of A Ride-Thru / Diode Application

    User’s Manual Figure 6-8: Block Diagram Example of a Ride-Thru / Diode Application BOOST REGULATOR 3 PHASE AC LINE 2 SECOND, 50% SAG PROTECTION FOR EQUIVALENT DRIVES WITH EQUAL LOADS USING DC BOOSTER AND DIODE ISOLATION Dwgs: 070241 Rev: 20080604...
  • Page 28 M3460D NOTES...
  • Page 29 User’s Manual This page intentionally left blank...
