REED 700APD Manual

Power drive
Hide thumbs
1
2
3
4
5
6
Table of Contents

Advertisement

Quick Links

Download this manual
700APD Power Drive
The REED 700APD Power Drive is a portable,
pneumatic-motor-driven, heavy-duty power drive
which provides power for threading pipe and conduit
up to 2" (50 mm) in diameter.
700V Safety Arm (#05275) sold separately.
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS.
FAILURE TO FOLLOW ALL INSTRUCTION LISTED
INSIDE MAY RESULT IN ELECTRIC SHOCK, FIRE,
AND/OR SERIOUS PERSONAL INJURY.
700APD
#05260
Also #05262
REED MANUFACTURING COMPANY
1425 West Eighth St.
PHONE: 800-666-3691 or 814-452-3691 Fax: 800-456-1697 or 814-455-1697
www.reedmfgco.com
Optional
Safety Arm
#05275
• Automate the pipe threading process
• Dropheads available separately in sizes
from 1/2" to 2".
SAVE THESE
INSTRUCTIONS!
Erie, PA 16502 USA
1
0519-58885

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 700APD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for REED 700APD

Summary of Contents for REED 700APD

  • Page 1 Optional Safety Arm #05275 700APD #05260 Also #05262 700APD Power Drive The REED 700APD Power Drive is a portable, • Automate the pipe threading process pneumatic-motor-driven, heavy-duty power drive • Dropheads available separately in sizes which provides power for threading pipe and conduit from 1/2” to 2”. up to 2” (50 mm) in diameter. 700V Safety Arm (#05275) sold separately. WARNING! SAVE THESE READ AND UNDERSTAND ALL INSTRUCTIONS. INSTRUCTIONS! FAILURE TO FOLLOW ALL INSTRUCTION LISTED INSIDE MAY RESULT IN ELECTRIC SHOCK, FIRE, AND/OR SERIOUS PERSONAL INJURY.

  • Page 2: Work Area

    700APD Power Drive Reed Manufacturing WORK AREA SERVICE 1. Keep your work area clean and well lit. Cluttered benches 1. Tool service must be performed only by qualified repair and dark areas invite accidents. personnel. Service or maintenance performed by unqualified 2. Keep bystanders, children, and visitors away while personnel could result in a risk of injury. operating a power tool. Distractions can cause you to lose 2.

  • Page 3: Tool Safety

    Reed Manufacturing TOOL SAFETY OPERATION 1. The POWER DRIVE is made to thread pipe. Follow instruc- For threading with drophead die heads only, such as Reed tions in this Operator’s Manual on tool use. Other uses may R12+ Dropheads with R12+ Segmental Dies. increase the risk of injury. 2. Secure POWER DRIVE using the 700V optional safety arm WARNING: OPERATOR SHOULD BE THOROUGHLY (#05275).
  • Page 4 3/4” NPT R12DN1 05610 1” NPT DHR121NPT 05630 1” NPT R12DN1 1/4 05612 1 1/4” NPT DHR121 1/4NPT 05632 1 1/4” NPT R12DN1 1/2 05614 1 1/2” NPT DHR121 1/2NPT 05634 1 1/2” NPT R12DN2 05616 2” NPT DHR122NPT 05636 2” NPT R12+ THREADER SETS Find R12+ Threader Sets in the Reed catalog or www.reedmfgco.com. 700APD Set-up and Operation Fig. 1 700PD Fig. 2 Inserting R12+ Drophead Fig. 5 Rod on black safety arm helps resist Fig. 3 Set Up for Threading Fig. 4 Threading 2” Pipe the threading torque to protect the operator.

  • Page 5: Replacement Parts

    REPLACEMENT PARTS 700APD Safety Arm #05275 700V 700APD Pneumatic Power Drive (Sold separately.) Parts List Ref. No. Description Item Code Qty. Used Ref. No. Description Item Code Qty. Used GEAR CASE 98800 BALL BEARING 98855 COVER PLATE 98804 KEY 95015 FAN HOUSING 98801 SLEEVE...
  • Page 6 Reed Limited Warranty REED will repair or replace tools with any defects due to faulty materials or workmanship for one (1) year or five (5) years from the date of purchase, as applicable. This warranty does not cover part failure due to tool abuse, misuse, or damage caused where repairs or modifications have been made or attempted by non REED authorized repair techni c ians. This warranty applies only to REED tools and does not apply to accessories. This warranty applies exclusively to the original purchaser. One (1) year warranty: Power units for pneumatic, electric, hydraulic and battery-powered tools have a one year warranty. This includes, but is not limited to REED pumps, universal pipe cutter motors, power drives, power bevel tools, threading machines, cordless batteries and chargers.
