5 Operating the drives
!
5.1 Operating the floppy disk drive
!
Figure 11: Inserting a floppy disk
1 = Insertion direction
2 = Label field
3 = Write-protect slider
4 = ID for a 1.44-Mb floppy disk
Inserting a floppy disk
Ê
Insert the disk into the floppy disk drive in the direction indicated (1) so that the label
field (2) faces upwards and the floppy disk can be felt to have engaged in the drive.
U41119-J-Z126-1-74
Observe the safety instructions given in the
When handling floppy disks, observe the manufacturer's instructions.
Cleaning disks must not be used to clean the floppy disk drives in the server!
Any cleaning disk would destroy the read/write heads in the floppy disk drive within
a mere 20 seconds.
chapter "Important
5 = Eject button for inserted floppy disks
6 = Floppy disk is write-protected
7 = Floppy disk is not write-protected
information".
23
