HIGH FLOW SINGLE INLET OPTION
31
38
37
36
35
40
#
14
15
16
17
18
19
20
21
22
23
24
25
26
27
31
32
33
35
36
37
38
39
40
25
33
32
24
23
39
24
23
DESCRIPTION
1 STORZ 4" FTS PSF4.25 - PARTS SET FULL TIME SWIVEL
2 MATE PSM4.25 X PSF5.25 LOCKOUT PART SET
DESCRIPTION
RELIEF VALVE WITHOUT THREAD, ALUMINUM
7/16-14 X 1 HEX HEAD BOLT 18-8 STAINLESS STEEL
LDH BLANK CAP HARDCOAT USE ON X651
SAFETY VALVE BASE LABEL
O-RING-236 3-1/4 ID 1/8 C/S 3.234 +/-.024 ID.139 +/-.004 C/S
O-RING-244 4-1/4 ID 1/8 C/S 4.234+-.030 ID .139+-.004 C/S
LDH ADAPTOR W/PSM5.25
REAR SPIKE
¼-28 X ¾ BUTTON HEAD
PLASTIC STRIP 5.25 - MOLDED
CUP SEAL 5.25 X 4.75 X ¼ PRECISION ASSOCIATES #666-427
LOCKING LEVER - MOLDED
SPRING TORSION (STORZ LOCK) 9991067 MIDSTATE # 210049
COUPLING HEAD STROZ 5 X 5.25 PSF HARDCOAT
GASKET 5 PRESSURE MOLDED 9991000
BALL 7/16 STAINLESS 302 GRADE 100
MATE PSM4.25 X PSF5.25 - HARDCOAD
PLASTIC STRIP 4.25 - MOLDED
CUP SEAL 4.25 X 3.750 X 1/4
COUPLING RL 3.0NHF X PSF4.25
COUPLING RL 3.5NHF X PSF4.25
GASKET 3.0 HOSE COUPLING
GASKET 3.5 HOSE COUPLING
4.0 NH FEMALE X PSF5.25
4.0 HOSE COUPLING GASKET
16
18
27
17
26
24
23
22
21
4" Storz Coupling is available (not shown)
14
15
18
19
20
QTY
Qty Part #
1 A1810
4 VT43-14HX1.0
1 X631
1 XL080
1 VO-236
1 VO-244
1 X651
1 X482
1 VT25Y28BH750
1 A1291
1 A1296
1 A4171
1 A4230
1 A4135
1 A4220
1 VB.437
1 A4730
1 A1292
1 A1297
1 A4650N
1 A4655N
1 V3194
1 V3196
1 A4660N
1 V3198
14
PART
1 A4114.1
1 A4730.2
