8.0 DRAWINGS & PARTS LIST
# DESCRIPTION
1 SHAFT NUT
2 SNAP RING
3 BEARING
4 WORM WITH KEYWAY
5 KEY 1/8 X 1.00
6 BUSHING
7 BOOT
8 DANGER LABEL
9 11/4-28 GREASE FITTING
10 PULL PIN
11 PULL PIN SPRING
12 PULL PIN HOUSING
13 KEY RING
14 5/16-18 X 1-1/4 SHCS
15 3/8-16X7/8SHCS
17 PEG - CARRYING HANDLE
18 BIG BEND/BELL ASSEMBLY
20 200 PSI/BAR GAGE/BUMPER
21 HANDWHEEL ASSEMBLY
23 ROTATION LOCK PIVOT
24 ROTATION LOCK INSERT
25 ROTATION LOCK SPRING
26 ROTATION LOCK LEVER
** NOTE: Specify desired color and hose thread at time of order.
CROSSFIRE
MANUAL: MANUAL:
WITH STOW-A-WAY 800 BASE WITH STOW-A-WAY 800 BASE
INSTRUCTIONS FOR SAFE OPERATION AND MAINTENANCE INSTRUCTIONS FOR SAFE OPERATION AND MAINTENANCE
Read instruction manual before use. Operation of this device Read instruction manual before use. Operation of this device
DANGER
without understanding the manual and receiving proper training is a without understanding the manual and receiving proper training is a
misuse of this equipment. A person who has not read and misuse of this equipment. A person who has not read and
understood all operating and safety instructions, is not qualified to understood all operating and safety instructions, is not qualified to
operate the CROSSFIRE portable/deck gun. operate the CROSSFIRE portable/deck gun.
Maximum recommended Maximum recommended
flow is 1250 GPM on flow is 1250 GPM on
truck mount adaptor, 800 truck mount adaptor, 800
GPM on portable base. GPM on portable base.
Maximum recommended Maximum recommended
inlet pressure is 175 psi. inlet pressure is 175 psi.
This instruction manual is intended to familiarize firefighters and maintenance This instruction manual is intended to familiarize firefighters and maintenance
personnel with the operation, servicing, and safety procedures associated with the personnel with the operation, servicing, and safety procedures associated with the
C R O S S F I R E C R O S S F I R E p o r t a b l e / d e c k p o r t a b l e / d e c k g u n . g u n .
This manual should be kept available to all operating and maintenance personnel. This manual should be kept available to all operating and maintenance personnel.
QTY PART #
1 X210
1 VR4220
1 VM4250
1 X220
1 X225
1 X230
1 X240
1 XL090
1 VT25-28ZERK
1 X340
1 X345
1 X350
1 VR4300
2 VT31-18SH1.2
1 VT37-16SH875
1 X362
1 X800**
1 X823
1 X810
1 X180
1 X170
1 X152
1 X821
# DESCRIPTION
27 PAWL
28 DETENT SPRING
29 WEAR STRIP
30 CUP SEAL .366 NITRILE 70A
31 SLIDE BAR
32 #6-32 X 1/4 BUTTON HEAD
33 COVER
34 CLEVIS PIN RETAINER
35 O-RING-018
36 PLUNGER WAVE SPRING
37 SAFETY PLUNGER
38 2.5 NH ELBOW/VANE ASSEMBLY
39 O-RING-241
40 DRAIN HOUSING
41 DRAIN PLUG
42 FLAT WASHER
43 1/4-28 X 1/2 BHCS
44 O-RING 130
45 5/16 SS BALLS
45A 5/16 TORLON BALLS
46 3/8-24 x 3/8 SOCKET SET
47 MANUAL - CROSSFIRE WITH
STOW-A-WAY BASE
48 DVD - CROSSFIRE
12
®
CROSSFIRE
Model No. XFT-NJ
CROSSFIRE
The safest, most versatile
master stream device...Ever!
OPERATIONS MANUAL:
DVD SUPPLEMENT
This DVD is not intended to replace the reading and
understanding of the CROSSFIRE operations manual.
QTY PART #
2 X135
2 H770
1 X120
1 X125
1 X140
2 VT06E32BH250
1 X142
1 X137
1 VO-018
1 X165
1 X150
1 X339NJ**
1 VO-241
1 X375
1 X382
1 VW687X281-50
1 VT25-28BH500
1 VO-130
38 VB.312
38 VB.312TO
2 VT37F24SS312
1 LIX-040
1 LIX-200
