- Page 1 INTORQ BFK470 Spring-applied brake with electromagnetic release Translation of the Original Operating Instructions www.intorq.com www.intorq.com...
- Page 2 Product key INTORQ Legend for the product key INTORQ BFK470 Product group Brake Product type Spring-applied brake Type Size 06, 08, 10, 12, 14, 16, 18 Not coded: Supply voltage, hub bore hole, options INTORQ | BA 14.0199 | 08/2016...
- Page 3 03/2014 SC Restructured FM; note concerning brake seal 33001439 01/2015 SC Harmonized connection diagrams 33001439 08/2016 SC Additional sizes: 06, 08, 10, 12 Refer to www.intorq.de for the latest version of these operating instructions. INTORQ | BA 14.0199 | 08/2016...
-
Page 4: Table Of Contents
Brake with proximity sensor ........................36 Commissioning ............................37 During operation ............................37 Maintenance and repair ............................38 Wear of spring-applied brakes ........................38 Inspections ..............................39 Maintenance ..............................40 Spare-parts list ............................43 Electrical accessories ..........................43 Troubleshooting and fault elimination .......................44 INTORQ | BA 14.0199 | 08/2016... -
Page 5: Preface And General Information
Reference to another page with additional Symbols information For example: 16 = refer to page 16 Wildcard Wildcard for options, selections For example: BFK458- = BFK458-10 Note Important notice about ensuring smooth operations or other key information. INTORQ | BA 14.0199 | 08/2016... -
Page 6: Abbreviations Used
Engagement time, sum of the delay time and braking torque - rise time Disengagement time, time from switching the stator until reaching 0.1 M Slipping time, operation time of the brake (according to t ) until standstill INTORQ | BA 14.0199 | 08/2016... -
Page 7: Safety Instructions And Notices
Characterises the type and severity of danger Note Describes the danger Possible consequences ❚ List of possible consequences if the safety instructions are disregarded. Protective measure ❚ List of protective measures to avoid the danger. INTORQ | BA 14.0199 | 08/2016... -
Page 8: Scope Of Delivery
INTORQ does not accept any liability for deficiencies claimed subsequently. ❚ Claim visible transport damage immediately to the deliverer. ❚ Claim visible deficiencies or incomplete deliveries immediately to INTORQ GmbH & Co. KG. Disposal The spring-applied brake consists of different types of material. ❚... -
Page 9: Drive Systems
Warranty ❚ Terms of warranty: Refer to the terms of sale and delivery for INTORQ GmbH & Co. KG. ❚ Warranty claims must be made to INTORQ immediately after the defects or faults are detected. ❚... -
Page 10: Safety Instructions
❚ Only qualified, skilled personnel are permitted to work on and with INTORQ components. According to IEC 60364 or CENELEC HD 384, qualified, skilled personnel are persons ..who are familiar with the installation, mounting, commissioning, and operation of the product. -
Page 11: Application As Directed
... must only be operated under the ambient conditions prescribed in these Operating Instructions..must not be operated beyond their corresponding power limits. Any other use or excessive usage shall be deemed improper! Possible applications of the INTORQ spring-applied brake ❚ No explosive or aggressive atmosphere. -
Page 12: Technical Specifications
The spring-applied brake is designed for converting mechanical work and kinetic energy into heat energy. Due to the static braking torque, loads can be held at standstill. Emergency braking is possible at high speed of rotation. The wear increases as the switching energy increases. INTORQ | BA 14.0199 | 08/2016... - Page 13 Increased breakaway torque is common in particular after long downtimes in humid environments where temperatures vary. ❚ If the brake is used as a pure holding brake without dynamic load, the friction lining must be reactivated regularly. INTORQ | BA 14.0199 | 08/2016...
-
Page 14: Rated Data
-0.10 10.0 BFK470-14 0.75 0.45 9.55 9.85 ± 0.1 -0.1 +0.15 11.5 BFK470-16 0.80 0.50 11.05 11.35 -0.1 -0.05 +0.20 13.0 BFK470-18 0.65 12.50 12.85 -0.1 -0.10 Tab. 2: Air gap / rotor thickness INTORQ | BA 14.0199 | 08/2016... - Page 15 – the brake is no longer securely fastened! ❚ The material of the end shield must have a tensile strength of R >= 250 N/mm INTORQ | BA 14.0199 | 08/2016...
-
Page 16: Rated Data (Dimensioning Data) Electrical Data
75 / 80 / 100 / 110 3600 BFK470-16 55 / 80 / 90 / 100 / 105 / 125 / 150 BFK470-18 100 / 150 / 165 / 185 / 200 / 235 / 250 Tab. 5: Rated torques INTORQ | BA 14.0199 | 08/2016... - Page 17 7500 BFK470-10 12000 BFK470-12 24000 BFK470-14 30000 BFK470-16 36000 BFK470-18 60000 Tab. 6: Switching energy - operating frequency - operating times 1) Typical values 2) Measured with induced voltage limitation of -800 V DC INTORQ | BA 14.0199 | 08/2016...
-
Page 18: Switching Energy / Operating Frequency
The disengagement time is the same for DC and AC switching. The disengagement time can be shortened by special equipment for fast-response excitation or over-excitation. Switching energy / operating frequency Abb. 3 Switching energy as a function of the operating frequency Switching energy Operating frequency INTORQ | BA 14.0199 | 08/2016... -
Page 19: Emissions
The user must ensure compliance with EMC Directive 2004/108/EC using appropriate controls and switching devices. If an INTORQ rectifier is used for the DC switching of the spring-applied brake and if the switching frequency exceeds five switching operations per minute, the use of a mains filter is required. -
Page 20: Mechanical Installation
The diameter of the shaft shoulder must not be greater than the tooth root diameter of the hub. ❚ The form and position tolerances apply only to the materials mentioned. Contact INTORQ if you are us- ing other materials. ❚... - Page 21 Bit for hexagon socket screws Measuring range [Nm] Wrench width [mm] BFK470-06 BFK470-08 1 - 12 BFK470-10 BFK470-12 BFK470-14 BFK470-16 20 - 100 BFK470-18 * For attaching flange inner bit with pin guide Multimeter Caliper gauge Feeler gauge INTORQ | BA 14.0199 | 08/2016...
-
Page 22: Assembly
NOTICE Check the tensile strength of the hub material: When operating with high torque, consult with INTORQ and use a steel hub with a higher tensile strength. Abb. 4 Installing the hub onto the shaft... - Page 23 The chamfer on the flange must point towards the brake! Align the through holes of the flange (6) with the fixing holes in the end shield (15). Abb. 6 Mounting the brake Brake Flange 15 End shield Rotor 10 Socket head cap screws INTORQ | BA 14.0199 | 08/2016...
- Page 24 The customer must seal the brake in this position himself if no shaft seal or cover is in use. NOTICE If it is necessary to loosen the screws with the seal again, the seals or the complete screw set must be replaced. INTORQ | BA 14.0199 | 08/2016...
-
Page 25: Electrical Installation
NOTICE ❚ It must be ensured that the supply voltage corresponds to the name plate data. Electrical connection Circuit suggestions NOTICE The terminal pin sequence shown here does not match the actual order. INTORQ | BA 14.0199 | 08/2016... - Page 26 3x 39V 47KΩ Abb. 8 Supply: Phase-phase Half-wave rectifiers Bridge rectifier BEG-2xx: U [VDC]=0.45 • U [VAC] BEG-1xx: U [VDC]=0.9 • U [VAC] Brake Inductive proximity sensor Not recommended for most regional/national high-voltage mains systems INTORQ | BA 14.0199 | 08/2016...
- Page 27 3x 39V 47KΩ Abb. 10 Supply: Phase-phase Half-wave rectifiers Bridge rectifier BEG-2xx: U [VDC]=0.45 • U [VAC] BEG-1xx: U [VDC]=0.9 • U [VAC] Brake Inductive proximity sensor Not recommended for most regional/national high-voltage mains systems INTORQ | BA 14.0199 | 08/2016...
- Page 28 3x 39V 47KΩ Abb. 12 Supply: Phase-phase Half-wave rectifiers Bridge rectifier BEG-2xx: U [VDC]=0.45 • U [VAC] BEG-1xx: U [VDC]=0.9 • U [VAC] Brake Inductive proximity sensor Not recommended for most regional/national high-voltage mains systems INTORQ | BA 14.0199 | 08/2016...
- Page 29 [VAC] BEG-14x: U [VDC]=0.9 • U [VAC] Brake Inductive proximity sensor Spark suppressor 14.198.00.xx (required once, select position) For most regional/national high-voltage mains systems, this only makes sense for supplies on L1 and N. INTORQ | BA 14.0199 | 08/2016...
-
Page 30: Technical Data For Inductive Proximity Sensors
Shock and vibration IEC 60947-5-2 / 7.4 EMC protection IEC 60947-5-2 (7.2.3.1) 1 kV IEC 61000-4-2 Level 2 IEC 61000-4-3 Level 3 IEC 61000-4-4 Level 2 Tab. 8: Technical data for inductive proximity sensors (release check) INTORQ | BA 14.0199 | 08/2016... -
Page 31: Minimum Bend Radius For The Brake Connection Line
The bridge-half-wave rectifiers are used to supply electromagnetic DC spring-applied brakes which are ap- proved for the use with such rectifiers. Other use is only permitted with the approval of INTORQ. Once a set over-excitation time has elapsed, the bridge-half-wave rectifiers switch over from bridge rectifi- cation to half-wave rectification. - Page 32 1 max [V ~] [V ~] [V ~] BEG-561-255-030 0.430 0.300 0.270 BEG-561-255-130 1,870 1,300 1,170 BEG-561-440-030-1 0.75 0.500 0.300 0.270 Tab. 10: Data for bridge/half-wave rectifier type BEG-561 input voltage (40 – 60 Hz) INTORQ | BA 14.0199 | 08/2016...
- Page 33 Delayed engagement Fast engagement Mains Bridge Coil 5.5.4 Permissible current load at ambient temperature 1 For screw assembly with metal surface (good heat dissipation) 2 For other assembly (e.g. adhesive) INTORQ | BA 14.0199 | 08/2016...
-
Page 34: Commissioning And Operation
NOTICE Operation without dynamic loads (functioning as a pure holding brake) ❚ If the brake is used as a pure holding brake without dynamic load, the friction lining must be reactivated regularly. INTORQ | BA 14.0199 | 08/2016... -
Page 35: Function Checks Before Commissioning
10. If necessary, remove the neutral conductor from the neutral point (step 2). The preparations for commissioning are completed. If faults occur, refer to the the error search table, 44. If the fault cannot be fixed or eliminated, please contact your customer service. INTORQ | BA 14.0199 | 08/2016... -
Page 36: Brake With Proximity Sensor
12. Screw the bridges onto the motor terminals. Remove additional PE conductor, if necessary. Contact type Connection Brake released Proximity sensor is closed N/O contact black / blue Tab. 11: Switching status of the proximity sensor INTORQ | BA 14.0199 | 08/2016... -
Page 37: Commissioning
Compare the DC voltage with the voltage indicated on the name plate. A deviation of 10 % is per- missible. ❚ If faults occur, refer to the the error search table, 44. If the fault cannot be fixed or eliminated, please contact your customer service. INTORQ | BA 14.0199 | 08/2016... -
Page 38: Maintenance And Repair
Axial load cycle and shear stress of Reduced spring force or Number of switching oper- springs through radial backlash on fatigue failure ations of brake reversal of armature plate Tab. 12: Causes for wear INTORQ | BA 14.0199 | 08/2016... -
Page 39: Inspections
❚ Check release function and control Inspections with as- sembled brake ❚ Check rotor Inspections after re- moving the brake ❚ Check hub ❚ Check armature plate and counter friction face INTORQ | BA 14.0199 | 08/2016... -
Page 40: Maintenance
Switch off the voltage. The brake must have no load torque on it when it is being dismantled. DANGER There is a risk of injury by electrical shock! Live connections must not be touched. WARNING Danger: rotating parts! The brake must be free of residual torque. The motor must not run! INTORQ | BA 14.0199 | 08/2016... - Page 41 Check the gear teeth of the hub. If the gear teeth are damaged, dismount and replace the hub. 6. Check armature plate: Thermal damage In the case of thermal damage (dark blue tarnishing), replace the stator. INTORQ | BA 14.0199 | 08/2016...
- Page 42 2. Measure the DC voltage at the brake. Compare the DC voltage with the voltage indicated on the name plate. A deviation of 10 % is per- missible. INTORQ | BA 14.0199 | 08/2016...
-
Page 43: Spare-Parts List
Maintenance and repair Spare-parts list Spring-applied brake INTORQ BFK470-06 to 18 Abb. 17 Spring-applied brake BFK470 _________________ material number of the brake (PLEASE INCLUDE: refer to the nameplate)! Only parts with item numbers are available. Item Designation Variant Shaft sealing ring... -
Page 44: Troubleshooting And Fault Elimination
❚ If the rectifier defect occurs again, replace the entire stator, even if you can- not find any fault between turns or short circuit to ground. The fault may oc- cur later during heating-up. Air gap too large Replace rotor Rotor thickness too Replace rotor small INTORQ | BA 14.0199 | 08/2016... - Page 45 Adjust rectifier and brake voltage to each match the rectifier other. Defective rectifier diode Replace defective rectifier by a suitable undamaged one. AC voltage is not mains Fuse is missing or defec- Install fuse. Exchange fuse. voltage tive INTORQ | BA 14.0199 | 08/2016...
- Page 46 Notes Notes INTORQ | BA 14.0199 | 08/2016...
- Page 47 Notes INTORQ | BA 14.0199 | 08/2016...
- Page 48 Notes INTORQ | BA 14.0199 | 08/2016...
- Page 49 Notes INTORQ | BA 14.0199 | 08/2016...
- Page 50 Notes INTORQ | BA 14.0199 | 08/2016...
- Page 52 INTORQ GmbH & Co KG Germany PO Box 1103 D-31849 Aerzen, Germany Wülmser Weg 5 D-31855 Aerzen, Germany +49 5154 70534-444 +49 5154 70534-200 info@intorq.com 应拓柯制动器 （上海）有限责任公司 INTORQ (Shanghai) Co., Ltd. 上海市浦东新区泥城镇新元南路 600 号 6 号楼一楼 B 座...
