- Page 1 INTORQ BFK466−80 Electromagnetically released spring−applied brake Operating Instructions setting the standard www.intorq.com...
-
Page 2: J | Ba 14.0204
| BA 14.0204 | 02/2012 This documentation applies to ... BFK466−80 BFK46680−003.iso/dms Product key Product key INTORQ − Legend for the INTORQ BFK466 product key Product group Brakes Product family Spring−applied brake Type Size Not coded: supply voltage, hub bore, options... -
Page 3: J | Ba 14.0204
j | BA 14.0204 | 02/2012 Identification Package label Example Manufacturer Bar code Name Type No. Type (see product key) Quantity per box Rated voltage Rated power Rated torque Packing date Model identification Desired customer no. Additional information CE designation BFK46680_001.iso/dms Nameplate Example... -
Page 4: Table Of Contents
j | BA 14.0204 | 02/2012 Contents Preface and general information ........About these Operating Instructions . - Page 5 j | BA 14.0204 | 02/2012 Contents Troubleshooting and fault elimination ........
-
Page 6: Preface And General Information
j | BA 14.0204 | 02/2012 Preface and general information Preface and general information About these Operating Instructions These Operating Instructions will help you to work safely on and with the multi−pole spring−applied brake. They contain safety instructions that must be followed. All persons working on or with the multi−pole spring−applied brake must have these Operating Instructions available and observe the information and notes relevant for their work. -
Page 7: Abbreviations Used
INTORQ does not accept any liability for deficiencies claimed subsequently. Claim – visible transport damage immediately to the forwarder. – visible deficiencies / incompleteness immediately to INTORQ GmbH & Co. KG. Disposal The spring−applied brake consists of different types of material. -
Page 8: Drive Systems
– operating faults – disregarding these Operating Instructions Warranty Terms of warranty: see terms of sale and delivery of INTORQ GmbH & Co. KG. Warranty claims must be made to INTORQ immediately after detecting defects or faults. The warranty is void in all cases where liability claims cannot be made. -
Page 9: Safety Instructions
– This is the prerequisite for safe and trouble−free operation and for achieving the specified product features. Only qualified, skilled personnel are permitted to work on and with INTORQ components. In accordance with IEC 60364 or CENELEC HD 384, qualified, skilled personnel are persons ... -
Page 10: Application As Directed
– must only be operated under the ambient conditions prescribed in these Operating Instructions. – must not be operated beyond their corresponding power limits. Any other use shall be deemed inappropriate! Possible applications of the INTORQ spring−applied brake Humidity: no restrictions Ambient temperature: – −5°C to +40°C (standard) At high humidity and low temperature: –... -
Page 11: Notes Used
j | BA 14.0204 | 02/2012 Safety instructions Notes used The following pictographs and signal words are used in this documentation to indicate dangers and important information: Safety instructions Structure of safety instructions: Danger! Characterises the type and severity of danger Note Describes the danger Possible consequences:... -
Page 12: Technical Data
j | BA 14.0204 | 02/2012 Technical data Technical data Product description 3.1.1 Structure and function BFK46685−004.iso Fig. 1 Design of a BFK466−80 spring−applied brake Stator Cheese head screw Friction lining Brake disk Guide sleeve Support of friction lining Flange Cheese head screw Manual release lever (detachable) - Page 13 After approx. 1...2 seconds, the supply voltage is decreased to 50%. 3.1.5 Release monitoring The INTORQ BFK466 spring−applied brake is equipped with a microswitch (changeover contact) which monitors the switching status. During brake release, the microswitch (9) changes over. This must exclude drive operation against the applied brake.
- Page 14 j | BA 14.0204 | 02/2012 Technical data 3.1.8 Project planning notes The brakes are dimensioned in such a way that the given characteristic torques are reached safely after a short run−in process. Due to the fluctuating properties of the organic friction linings used and the alternating environmental conditions, deviations of the given braking torques may occur.
-
Page 15: Rated Data
j | BA 14.0204 | 02/2012 Technical data Rated data Type Friction Brake disk Max. sliding Voltage Power Coil Max. Overexcit force radius speed resistance current ation time [mm] [m/s] U ±10% R20±5% sec. max. max. [V] DC min. / max. 90/45 522/130.5 15.52... -
Page 16: Operating Frequency / Friction Work
j | BA 14.0204 | 02/2012 Technical data Disengagement time The disengagement time is not affected by DC or AC switching. The indicated disengagement time applies to an air gap of 0.4 mm. When the air gap is larger (as a result of wear), the disengagement time increases. -
Page 17: Emission
j | BA 14.0204 | 02/2012 Technical data Emission Heat Since the brake converts kinetic energy as well as mechanical and electrical energy into heat, the surface temperature varies considerably, depending on the operating conditions and possible heat dissipation. Under unfavourable conditions, the surface temperature can reach 130_C. -
Page 18: Mechanical Installation
j | BA 14.0204 | 02/2012 Mechanical installation Mechanical installation Important notes Stop! | Do not lubricate the screws with oil or grease. Necessary tools Type Torque key Insert for hexagon Transport screw Crosstip screwdriver socket screws Measuring range [Nm] Wrench size [mm] Wrench size [mm] Crosstip size... -
Page 19: Mounting
j | BA 14.0204 | 02/2012 Mechanical installation Mounting 4.3.1 Preparation 1. Unpack spring−applied brake. 2. Check for completeness. 3. Check nameplate data, especially rated voltage. Installation The brake is delivered preassembled with two transport safety bolts (17). 1. Fit the guide sleeve (19) on the drive and tighten it lightly with the fixing screw (21). 2. -
Page 20: Electrical Installation
j | BA 14.0204 | 02/2012 Electrical installation Electrical installation Important notes Danger! | Electrical connection must only be carried out by skilled personnel! | Connections must only be made when the equipment is de−energised! Danger through unintended starts or electric shocks. Stop! | It must be ensured that the supply voltage corresponds to the nameplate data. -
Page 21: Microswitch
j | BA 14.0204 | 02/2012 Electrical installation Microswitch Note! Application range recommended for the microswitch | DC current: 10 mA to 100 mA at 12 V | AC current: 10 mA to 5 A at 12 V / max. 250 V 5.3.1 Microswitch as NC contact (series connection) Danger! - Page 22 j | BA 14.0204 | 02/2012 Electrical installation When current is fed to the spring−applied brake, the armature plate is released. The microswitch (NC contact) is actuated and gives the signal Spring−applied brake released". When the maximum working air gap is exceeded, the release monitoring circuit is opened by the wear monitoring microswitch connected in series.
- Page 23 j | BA 14.0204 | 02/2012 Electrical installation 5.3.2 Microswitch as NO contact (parallel connection) Danger! | Perform electrical connection only when no voltage is applied. | If an "emergency stop" is carried out without the protective circuit provided, the control device may be destroyed. Observe the correct polarity of the protective circuit! BFK466XX−018.iso Fig.
- Page 24 j | BA 14.0204 | 02/2012 Electrical installation Microswitch (NO contact, parallel connection) Brake released Brake worn−out Circuit open closed closed closed...
-
Page 25: Commissioning And Operation
j | BA 14.0204 | 02/2012 Commissioning and operation Commissioning and operation Important notes Danger! The brake must be free of residual torque. The motor must not rotate. Danger! Live connections must not be touched. The brakes are dimensioned in such a way that the given characteristic torques are reached safely after a short run−in process. -
Page 26: Function Checks Before Commissioning
j | BA 14.0204 | 02/2012 Commissioning and operation Function checks before commissioning 6.2.1 Release / voltage check Danger! Disconnect the drive from the load to prevent accidents. During the next inspection steps of the spring−applied brake, the motor must not run! 1. - Page 27 j | BA 14.0204 | 02/2012 Commissioning and operation BFK466XX−003.iso Hexagon head cap screw Microswitch tappet Check the setting of the microswitch for release monitoring using a feeler gauge with thickness "Y and Y " between hexagon head cap screw (1) and microswitch tappet (2). max.
- Page 28 j | BA 14.0204 | 02/2012 Commissioning and operation 6.2.3 Checking the manual release function Stop! This operational test is to be carried out additionally! Danger! The drive system must be load−free. The motor must not rotate. Stop! If the brake is operated above the maximally permissible working air gap "s Lü...
-
Page 29: Commissioning
j | BA 14.0204 | 02/2012 Commissioning and operation Manual release with bowden cable (optional) Note! The manual release is designed for operation using a bowden cable. BFK46680−004.iso Motor and brake deenergised. 1. Suspend bowden cable (not included in the scope of supply) and pull with approx. 800 N. -
Page 30: During Operation
j | BA 14.0204 | 02/2012 Commissioning and operation During operation Danger! Live connections must not be touched. Check the brake regularly during operation. Take special care of: – unusual noises or temperatures – loose fixing elements – the condition of the electrical cables. The armature plate must be attracted and the drive must move without residual torque. -
Page 31: Maintenance/Repair
If several of the causes of wear indicated for the friction lining occur in an application at the same time, the influencing factors must be added for calculating the wear. The INTORQ Select dimensioning program can be used to calculate the maintenance intervals. -
Page 32: Inspections
j | BA 14.0204 | 02/2012 Maintenance/repair Inspections 7.2.1 Important notes To ensure safe and trouble−free operation, spring−applied brakes must be checked and maintained at regular intervals. Servicing can be made easier if good accessibility of the brakes is provided in the plant. This must be considered when installing the drives in the plant. Primarily, the necessary maintenance intervals for industrial brakes result from the load during operation. - Page 33 j | BA 14.0204 | 02/2012 Maintenance/repair 7.2.3 Air gap check Danger! Disconnect the drive from the load to prevent accidents. During the next inspection steps of the spring−applied brake, the motor must not run! 1. Switch on the current for the brake(¶ 26). 2.
-
Page 34: Maintenance Operations
3. Loosen a fixing screw (4) and remove the guide sleeve (2) from the through−hole. 4. Turn the brake around the second guide sleeve (2) away from the brake disc (3). 5. Remove the brake from the guide sleeve (2). Spare parts order INTORQ BFK466spring−applied brake Order quantity _________ Pc. \ 80... - Page 35 j | BA 14.0204 | 02/2012 Troubleshooting and fault elimination Troubleshooting and fault elimination If any malfunctions should occur during operation of the drive system, please check the possible causes using the following table. If the fault cannot be eliminated by one of the listed measures, please contact the aftersales service.
- Page 36 j | BA 14.0204 | 02/2012 Troubleshooting and fault elimination Fault Cause Remedy Voltage too high Supply voltage too high Adapt the coil voltage to the supply voltage Rectifier defective Replace rectifier Bridge rectifier used instead of Replace the bridge rectifier by a bridge/half−wave bridge/half−wave rectifier rectifier.
- Page 37 j | BA 14.0204 | 02/2012 Notes...
- Page 38 j | BA 14.0204 | 02/2012 Notes...
- Page 39 j | BA 14.0204 | 02/2012 Notes...
- Page 40 F INTORQ GmbH & Co KG Wülmser Weg 5 D−31855 Aerzen Germany ( +49 (0) 51 54 70 53 4−0 Ê +49 (0) 51 54 70 53 4−100 š info@intorq.com ü www.intorq.com Service ( 00 80 00 24 4 68 77 (24 h helpline) Ê...
