TCL
L1 Service Manual
Communication Ltd.
Pixi4-7 3G&VF
9003A/9003X/VF1100
Note: this manual is non-contractual and TCL Communication Ltd. can modify it without prior
notice on the characteristics of described equipments.
Rev.
Page
1.1
1/30
9003A/9003X/VF1100 Level 1 Service Manual
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Alcatel Pixi4-7 3G&VF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TCL Alcatel Pixi4-7 3G&VF

Summary of Contents for TCL Alcatel Pixi4-7 3G&VF

  • Page 1 L1 Service Manual Communication Ltd. Pixi4-7 3G&VF 9003A/9003X/VF1100 Note: this manual is non-contractual and TCL Communication Ltd. can modify it without prior notice on the characteristics of described equipments. Rev. Page 1/30 9003A/9003X/VF1100 Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 2 L1 Service Manual Communication Ltd. 7-Mar-2016 Preliminary Draft Jane Chen Keira Xie Rev. Date Modification description Prepared By Checked By Approved By Rev. Page 2/30 9003A/9003X/VF1100 Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 3: Table Of Contents

    L1 Service Manual Communication Ltd. Content 1. General ............................. 4 2. Portable Label ..........................6 2.1. Label zones ............................6 2.2. Commercial Label Samples......................8 2.3. CU label ............................9 2.4. L1 Spare Part List .......................... 10 2.5. Accessory ............................10 2.5.1.

  • Page 4: General

    L1 Service Manual Communication Ltd. 1. General Pixi4-7 3G&VF(9003A/9003X/VF1100) is a MT8321 Platform tablet with Quad core 1.3 GHz, and BT/WLAN/MP3, social network service etc functions. It originally installed Android 6.0 system. It can work with the GSM 850 / 900 / 1800 / 1900MHz, 900/2100MHz (EMEA), 850/900/1900/2100MHz(LATAM). Detail features Pixi4-7 3G&VF Project Name...
  • Page 5 L1 Service Manual Communication Ltd. RAM Capacity 1GB (512MB/2GB Compatible) Micro SD, 9003A/9003X: up to 32GB External storage Capability VF1100: up to 64GB Internal, End user memory size Glonass Bluetooth supported version V4.1 Wi-Fi / WLAN 802.11 b/g/n WIFI direct Touch Icon position in LCD VA Connectivity...

  • Page 6: Portable Label

    L1 Service Manual Communication Ltd. G-sensor Proximity Light sensor E-Compass Sensors Gyroscope Pressure sensor Sensor Hub Hall IC Battery capacity (mAh) 2580mAh Standby time 430hours 5Hours-3G Battery Talking time (Hours) 10Hours-2G Charging time [Hours] within 4hours Battery type (RF standby mode) Soft pack 2.
  • Page 7 L1 Service Manual Communication Ltd. Printing zone definition (CPE000381AC0----For General 27*22+11*1.5+16*1.5mm) Rev. Page 7/30 9003A/9003X/VF1100 Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 8: Commercial Label Samples

    L1 Service Manual Communication Ltd. 2.2. Commercial Label Samples Rev. Page 8/30 9003A/9003X/VF1100 Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 9: Cu Label

    L1 Service Manual Communication Ltd. 2.3. CU label Rev. Page 9/30 9003A/9003X/VF1100 Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 10: L1 Spare Part List

    L1 Service Manual Communication Ltd. 2.4. L1 Spare Part List Please get the latest SPL in Forlog system. 2.5. Accessory 2.5.1. Charger Rev. Page 10/30 9003A/9003X/VF1100 Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 11: Headset

    L1 Service Manual Communication Ltd. 2.5.2. Headset Rev. Page 11/30 9003A/9003X/VF1100 Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 12: End User Usb Cable

    L1 Service Manual Communication Ltd. 2.5.3. End user USB cable 2.6. Maintenance policy This chapter describes the maintenance of the 9003A/9003X/VF1100 series device authorized at L1 repair centre. The maintenance operations can only be performed in approved repair centres. General Main L1 maintenance operations are as following: 2.6.1.

  • Page 13: If Input The Following Codes On Tablet, You Can

    L1 Service Manual Communication Ltd. Replacement of defective accessories 2.6.3. If input the following codes on tablet, you can: Code Description “Settings” -> “About tablet” -> Check IMEI number “Status” -> “IMEI/IMEI SV” Open “Calculator” application, and Enter MMI Test mode (refer to 2.13) input “0x0-0+=”...
  • Page 14 L1 Service Manual Communication Ltd. 2. Press “volume” key to select “wipe data / factory reset”, press “power” key to confirm; 3. Press “volume” key to select “Yes—delete all user data” and the press “power” key to double confirm the factory reset; Rev.
  • Page 15 L1 Service Manual Communication Ltd. 4. Factory reset complete, press “volume” key to select “reboot system now” and press “power” key to confirm. Rev. Page 15/30 9003A/9003X/VF1100 Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 16: Tablet Maintenance

    L1 Service Manual Communication Ltd. 2.7. Tablet maintenance Equipments for handset test.  Battery with full power.  One SIM card. It is recommended the following tools:  One PC with Windows 2000/NT/XP/Windows 7.  One ampere meter for charger current test. 2.8.

  • Page 17: Imei Check

    L1 Service Manual Communication Ltd. mouth year 2.9. IMEI Check Power on the handset, enter ”Settings” -> “About tablet” -> “Status” -> “IMEI information”. Input 0X0-0+= on calculator screen. There are three IMEI sticker positions on the device: Position 1: in the back casing Position 2: in the PCBA Position 3: in the SD slot cover Rev.

  • Page 18: Humidity Sensitive Sticker Check

    L1 Service Manual Communication Ltd. If the IMEI sticker in the back casing is not lost: We should make sure that the IMEI number MUST be the same with the one on the IMEI sticker; if not, it‟s out of warranty policy. 2.10.

  • Page 19: Visual Mechanical Inspection

    L1 Service Manual Communication Ltd. 2.11. Visual Mechanical inspection Mechanical warranties check items: Corrosion  Corrosion on the USB connectors, SIM connectors, and other metal surfaces Hole  Holes (Diameter > 1mm) on any surface, including front casing, decorate frame, battery cover, LCD Lens, keypad.

  • Page 20: Tablet Maintenance Procedure

    L1 Service Manual Communication Ltd. Any use in abnormal temperature, other than the one specified in the user manual. Any evidence of plastic/casing melted. Any mark of food or liquid around the accessory or in the USB socket. Any evidence of mechanical shocked which damage the enclosure of the charger or headset. Any mark of tentative of disassembly the accessory Any abnormal use which induce wire damage, wire broken or USB socket deformed.
  • Page 21 L1 Service Manual Communication Ltd. “Please draw in the yellow area” according to instructions  RAW Data I. You can see Raw data test is running; II. Press “pass” key to continue;  I. You will see the LCD display three colors - RED, GREEN and BLUE - if it functions well; II.
  • Page 22 L1 Service Manual Communication Ltd. II. Press “Pass” to continue.  Main Camera I. You will see the LCD displays the picture that back camera catch if it functions well; II. Press “Pass” to continue;  Front Camera I. You will see the LCD displays the picture that front camera catch if it functions well; II.
  • Page 23 L1 Service Manual Communication Ltd. The “Volume Down “and “Volume Up” will display grey when you adjust the volume if it functions well. IV. Press ”pass” to continue; V. Press “start “to record sound, and then press” Play”, you will hear the record sound if it functions well VI.
  • Page 24 L1 Service Manual Communication Ltd. “Please shadow the touch senor“ according to the instruction and it will display “near: OK far: OK” if it functions well. II. Press “Pass” to continue;  Insert SIM card and the phone will detect it if functions well; Press “Pass”...

  • Page 25: Software Download

    L1 Service Manual Communication Ltd. II. Press”Pass” to continue;  NETWORK Insert SIM card and follow the instruction if it functions well. Press”Pass” to continue;  Calling I. It will automatically call the emergency call if it functions well. II. Press “Pass” to continue; ...

  • Page 26: Handset Driver Installation

    L1 Service Manual Communication Ltd. 3.2 Handset driver installation Double click to install the Sugar MTK_SP V3.3.5, then select the “Install driver” check box for the driver installation. 3.3 SW download process Login the Sugar MTK_SP, then select the 9003A/9003X/VF1100 model: Rev.
  • Page 27 L1 Service Manual Communication Ltd. II. Click the „Get Status‟ button, it will display the SW version , IMEI, Cu ref etc of the handset, press “Yes “ to continue. Rev. Page 27/30 9003A/9003X/VF1100 Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 28 L1 Service Manual Communication Ltd. III. Click the “Upgrade” button. Online upgrade process starting: Rev. Page 28/30 9003A/9003X/VF1100 Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 29 L1 Service Manual Communication Ltd. IV. Upgrade finished: Rev. Page 29/30 9003A/9003X/VF1100 Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 30 L1 Service Manual Communication Ltd. If you have any question or problem, please feel free to contact us. Thanks for your cooperation. TCL Communication Ltd. Global Customer Service TS Dept. Mar,3 , 2015 Rev. Page 30/30 9003A/9003X/VF1100 Level 1 Service Manual...
