Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfil your needs for many years to
come. Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the reason
they are greatly appreciated throughout the world.
To get the most out of your new dishwasher, we recommend that you read the
operating instructions before using the dishwasher. The operating instructions
also include information on how you can help protect the environment.

Operating Instructions

Dishwasher
ASKO D5896XXLFI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D5896XXLFI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asko D5896XXLFI

Summary of Contents for Asko D5896XXLFI

  • Page 1: Operating Instructions

    Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfil your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.

  • Page 2: Table Of Contents

    Contents Front panel Troubleshooting Safety instructions Information for test institute Before washing for the first time Technical information Loading the dishwasher Installation Using the dishwasher Service Settings Programme chart Care and cleaning Your notes Front panel To start the machine, press and hold the main power switch until the display lights up. 0:25 Navigation button <...

  • Page 3: Safety Instructions

    Safety instructions General Winter storage/Transport Read the operating instructions and keep them in a safe place! Store the dishwasher where the temperature remains above freezing. Never use the dishwasher for any purpose other than that specified in these operating instructions. Avoid long transport distances in very cold weather.

  • Page 4: Before Washing For The First Time

    Before washing for the first time 5 Run a programme to ensure that any salt in the dishwasher The water softener is rinsed away. In order to achieve good dishwashing results, the dishwasher needs soft water (water with low mineral content). Hard water leaves a white coating on dishes and the dishwasher.

  • Page 5: Loading The Dishwasher

    Loading the dishwasher Setting the rinse aid dosage Economic dishwashing The section Settings describes how to set the rinse aid dosage. Run programmes only with a full load Rinse aid dispensing can be set from (Off) to (High Wait to run a programme until the dishwasher is full, this way you save energy.

  • Page 6: Upper Basket

    Your machine is equipped with a turbo drying function (Turbo Upper basket Drying Express+™), which improves the drying of plastic objects Place glasses, cups, bowls, side plates and saucers in the upper and other items. basket. All dirty surfaces should face inwards and downwards! NOTE! Wine glasses are placed on the wine glass shelf and knives are placed in the knife stand on the right (if fitted).

  • Page 7: Cutlery Basket

    Foldable tines Lower the foldable tines (plate supports) when washing pots. Release the foldable tines by pressing the catch inwards before adjusting their position. In the rear right part of the lower basket, half of the foldable tines can be folded when washing, for example, stoneware or a deep pan.

  • Page 8: Using The Dishwasher

    Using the dishwasher Cutlery basket with lid Add detergent Positioning of cutlery basket lid (in upper basket) The cutlery basket lid can be removed and used, for example, as an extra cutlery basket in the upper basket (see below). 1 Prewash detergent compartment 2 Main wash detergent compartment Detergent is added according to water hardness.

  • Page 9: Programme Selection

    Hygiene wash Main power switch This programme is ideal to use where demands on hygiene are extra high, e.g. for baby bottles and cutting boards. The Press and hold the main power switch until the display lights up. temperature is high both in the main wash and in the final rinse. Programme selection Crockery warming Used to warm plates.

  • Page 10: Selecting Options

    Selecting Options Status light™ Press Option/Set and then navigation button < or > to select an The status light at the bottom on the dishwasher provides option. Confirm your selection by pressing Option/Set. information by means of 3 different colours. Adjust the status light so that it is seen clearly by pulling out or pushing in the The available options depend on the selected programme.

  • Page 11: Settings

    Settings 1. Function Menu Open the Function Menu: Button press Description Turn off the machine. Open the door. Press and hold the main power switch until the display lights up. Within 20 seconds; - press navigation button > (right), 5 times. - press the button Option/Set, 5 times.
  • Page 12 You can change the following settings in the Function Menu: Settings Options 1. Language English/Svenska/Dansk/Norsk/ You can choose the language used for the display. Suomi/Français/Deutsch/Italiano/ Español/Nederlands/Русский 2. Child lock On/Off You can activate the child lock (button lock) to prevent children from starting the dishwasher.
  • Page 13 Settings Options 11. Select programs Auto wash / Time program / Heavy wash Programmes can be shown or hidden in the menu. Choose / Daily wash / Eco wash / Quick wash / between On and Off. Plastic wash / Delicate wash / Lower half If all programmes are set at Off, the programme Eco wash wash / Upper half wash / Hygiene wash will be shown on the display.

  • Page 14: Care And Cleaning

    Care and cleaning Coarse filter NOTE! The coarse filter traps larger food particles, which cannot get The dishwasher must not be used without the filters in place! past the drainage pump. Empty the coarse filter as necessary. Dishwashing results may be affected if the coarse filter is 1 Lift the coarse filter by the handle.
  • Page 15 Door When cleaning the edge around the door, use only a slightly damp cloth (with a little cleaner if necessary). WARNING! Do not use a spray bottle or the like around the door lock. This is to ensure that water does not penetrate the door catch and come into contact with the electrical components.

  • Page 16: Troubleshooting

    Troubleshooting Front display Type of fault on the Action display Overfilling 1 Clear the drainage pump. See the section Care and cleaning. If the problem persists, call the service department. Water outlet fault See “Water remains in the dishwasher” in the table “Problem” below. If the problem persists, call the service department.
  • Page 17 Problem Possible causes Action Spots or films on the dishes. The water softener is leaking salt. Check that the salt compartment lid is properly tightened. Otherwise call the service department. Incorrect water softener setting. See the section Settings. Incorrect rinse aid dosage setting. See the sections Before washing for the first time and Settings.
  • Page 18 Problem Possible causes Action Water remains in the dishwasher. Blocked drainage hose. Loosen the drainage hose where it connects to the sink unit's water trap. Check that no debris has fastened. Is the cone-shaped part of the pipe cut to an inner diameter of at least 14 mm? Kink in drainage hose.

  • Page 19: Information For Test Institute

    Information for test institute Energy labelling European test standard: EN 60436 Number of standard place settings: Dishwashing programmes: Eco wash, Drying: Short Connection: Cold water 15 °C Dosages during testing Detergent: In accordance with EN 60436 Rinse aid: In accordance with EN 60436 Prewash: 7.5 gram Rinse aid dosage:...
  • Page 20 Loading the dishwasher See section Energy labelling.

  • Page 21: Technical Information

    Technical information Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 1059/2010 ASKO Model designation: D5896XXLFI Number of standard place settings: Energy efficiency class: A+++ Annual energy consumption(AE 236 kWh per year Energy consumption of the standard cleaning cycle(E 0.83 kWh...

  • Page 22: Installation

    Installation 1238 [mm] 30-94 *Remove locking nuts for an installed height of 860-861 mm. **Door length. It is important that you read through and follow the instructions are correct before starting the installation. Note that the height and directions below. Conduct installation and connection in of the cover door can be adjusted to match other fittings.

  • Page 23: Service

    Service Once the installation is complete, the stopcock should be opened Read chapter Troubleshooting before contacting the service to allow the pressure to settle for a while and to check that all department. Note down the details on the serial number plate connections are tight.

  • Page 24: Programme Chart

    Programme chart...

  • Page 25: Your Notes

    Your notes...
  • Page 26 Your notes...
  • Page 27 Your notes...

  • Page 28: Quick Guide

    Fill up salt and rinse aid to achieve good washing and drying results. (See page 4.) Refill salt indicator. Refill rinse aid indicator. Select a programme and any options (See page 9.) Press Start/Stop, close the door en (08-16) ASKO APPLIANCES AB SOCKERBRUKSGATAN 3, SE-531 40 LIDKÖPING, SWEDEN WWW.ASKO.COM...
