Specifications; Minimum System Requirements; Package Contents - ActionTec R1524SU Specifications

Wireless-Ready DSL Gateway

Minimum System Requirements

• PC or Macintosh with Ethernet network adapter or
USB (PC only)
• Microsoft Windows:98SE / ME / NT / 2000 / XP,
MacOS 8.01 or higher
(USB: Windows 98SE, ME, 2000, XP)
• TCP/IP installed
• Internet Explorer 4.0+ or Netscape 4.0+

Package Contents

• Wireless-Ready DSL Gateway
• Power Supply
TM
• Installation Buddy CD-ROM
• User's Manual on CD-ROM
• Quick Start Guide
• Ethernet Network Cable (RJ-45)
• USB Cable
• RJ-11 Phone Cable
• Phone Filters are Optional
Broadband Technology Made Easy

Specifications

Interface Ports
ADSL Features
ATM and AAL Support
Standards Compliance
VPN Support
Setup and Management
Optional Router Features
Protocols Supported
Visual Indicators
Maximum Computer Users Supported
Compliance Certification
Limited Warranty
*** VPN Support contingent upon operating system configuration.
VPN Pass Through Supports a maximum of 4 sessions.
* PC Cards must be from Actiontec or Actiontec certified for use with the Actiontec Wireless-
Ready DSL Gateway.
** Actual speeds achieved are a factor of line conditions, distance between the gateway and
Central Office, and the configuration of the DSL Network, among other things .
© 2003 Actiontec Electronics, Inc. Actiontec, and the Actiontec logo are trademarks of Actiontec
Electronics, Inc. All other names are properties of their respective owners.
Product photo may differ from actual product, however functionality remains as stated above.
Internet (WAN): (1)ADSL RJ-11, (1) Phone Port with filter
Network (LAN): 4-Port 10/100 Mbps Auto-sensing
Ethernet switch, USB
PC Card: Two PCMCIA expansion slots
Top slot for wireless 802.11b PC Card*
Bottom slot for PC Expansion cards
exclusively from Actiontec*
Embedded full-rate ADSL Modem
Compliant with T1.413, G.dmt and G.lite
G.dmt full-rate connectivity at up to 8 Mbps
downstream, 1 Mbps upstream
Up to 18,000 feet loop reach (over standard
loops)**
AAL5
ATM Transmission Convergence (TC) layer
Support for full range of PVC settings
Hardware SAR
ADSL G.dmt (ITU G.992.1, ANSI TI.413)
ADSL G.lite (ITU G.992.2)
Bridge/Routed RFC 1483 (2684), RFC 2364, RFC 2516
IEEE 802.3 10 Base-T Ethernet
IEEE 802.3u 100 Base-Tx Fast Ethernet
PPTP, L2TP, IPSec (all pass-through)***
Web-based
RFC 2516 (PPPoE), 2364 (PPPoA) clients
TCP
IP, UDP
NAT, PAT
DHCP (client, server)
DNS (client)
TFTP (client, server)
SMTP, POP3
WAN Link, LAN Link/Traffic, PC Card, Power
253
FCC Part 15, FCC Part 68, UL
One year
WRDG/1202
