Summary of Contents for SpeakerCraft Tantra Triple LCR
-
Page 2: Speaker Placement
DIAGRAM 4: Speaker Terminal The Tantra Triple LCR provides a left, center and right channel in one cabinet. Be sure to connect the left, Placement on Wall or Stand center and right channels to the left, center and right channel inputs of your Home Theater receiver. -
Page 3: Mounting The Wall Bracket
DIAGRAM 6: MOUNTING THE WALL BRACKET Vertical Wall Mounting The Tantra On-Walls utilizes a unique mounting sys- tem. The Wall Bracket is mounted onto a stud in the wall. Then, the Tantra Series Speaker simply slips onto the Wall Bracket, securing the cabinet to the wall. Refer to Diagram 6 and follow steps 1–3. -
Page 4: Speaker Adjustments
SPEAKER ADJUSTMENTS Grille Removal he Tantra grille is pre-installed at the factory. To remove it, start on one corner and simply pull the grille out with your fingers (Diagram 11) Then do the same on the opposite side (Diagram 12) and continue to gently work your way down. -
Page 5: Specifications
SPECIFICATIONS Tantra Triple LCR Tantra Four Tantra Three Speaker Type: 2-Way Ported LCR 3-Way Ported On-Wall 3-Way Ported On-Wall Tweeter: ⁄ " Aluminum Dome (1) 1" Aluminum Dome (1) 1" Aluminum Dome Mid: (2) 5 ⁄ " Aluminum Cone (1) 2" Aluminum Dome... -
Page 6: Limited Lifetime Warranty
LIMITED LIFETIME WARRANTY Tantra Audio warrants to the original retail purchaser only purchaser, within a reasonable time, freight prepaid. that this Tantra Audio product will be free from defects This Warranty does not include service or parts to repair in materials and workmanship, provided the speaker damage caused by accident, disaster, misuse, abuse, was purchased from a Tantra Audio Authorized Dealer.
