Page 2 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 APPLICABILITY TABLE PRODUCT LE910-SKG SW Version 17.00.543 Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 2 of 273...
Page 3 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Notice While reasonable efforts have been made to assure the accuracy of this document, Telit assumes no liability resulting from any inaccuracies or omissions in this document, or from use of the information obtained herein.
Page 4 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 Usage and Disclosure Restrictions License Agreements The software described in this document is the property of Telit and its licensors. It is furnished by express license agreement only and may be used only in accordance with the terms of such an agreement.
Page 5: Table Of Contents
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 Contents Introduction............................ 10 1.1. Scope ..............................10 1.2. Audience ..............................10 1.3. Contact Information, Support ......................10 1.4. Document Organization ........................10 1.5. Text Conventions ..........................11 1.6. Related Documents ..........................11 Overview ............................12 2.1. About the document ..........................12 AT COMMANDS ..........................
Page 6 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 5.1.3.1.9. Model Identification - +GMM......................42 5.1.3.1.10. Revision Identification - +GMR ......................42 5.1.3.1.11. Capabilities List - +GCAP......................... 42 5.1.3.1.12. Serial Number - +GSN ........................42 5.1.3.1.13. Display Current Base Configuration And Profile - &V ..............42 5.1.3.1.14.
Page 7 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 5.1.4. 3GPP TS 27.007 AT Commands ........................60 General ..............................60 5.1.4.1.1. Request Manufacturer Identification - +CGMI ................... 60 5.1.4.1.2. Request Model Identification - +CGMM .................... 60 5.1.4.1.3. Request Revision Identification - +CGMR ..................60 5.1.4.1.4.
Page 8 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 Commands For EPS ..........................97 5.1.4.6.1. EPS Attach Or Detach - +CGATT ...................... 97 5.1.4.6.2. EPS Event Reporting - +CGEREP ...................... 98 5.1.4.6.3. EPS Network Registration Status - +CEREG ..................99 5.1.4.6.4.
Page 9 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 5.1.6.1.10. Extended Reset - #Z ........................143 5.1.6.1.11. Periodic Reset - #ENHRST ......................143 5.1.6.1.12. Wake From Alarm Mode - #WAKE ....................144 5.1.6.1.13. Temperature Monitor - #TEMPMON ..................... 145 5.1.6.1.14. General Purpose Input/Output Pin Control - #GPIO ............... 147 5.1.6.1.15.
Page 10: Introduction
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 This document is aimed in providing a detailed specification and a comprehensive listing as a reference for the whole set of AT command Readers of this document should be familiar with Telit modules and their ease of controlling by means of AT Commands.
Page 11: Overview
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 Chapter 2: “Overview” about the aim of this document and implementation suggestions. Chapter 3: “AT Commands” The core of this reference guide. Danger – This information MUST be followed or catastrophic equipment failure or bodily injury may occur.
Page 12: At Commands
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 This document is to describe all AT commands implemented on the Telit wireless module LE910-SKG. Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 12 of 273...
Page 13: Definitions
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 The Telit wireless module family can be controlled via the serial interface using the standard AT commands . The Telit wireless module family is compliant with: 1. Hayes standard AT command set, in order to maintain the compatibility with existing SW programs.
Page 14: String Type Parameters
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 The syntax rules followed by Telit implementation of either Hayes AT commands and GSM/WCDMA commands are very similar to those of standard basic and extended AT commands. There are two types of extended command: Parameter type commands.
Page 15: Command Lines
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 A command line is made up of three elements: the prefix, the body and the termination character. The command line prefix consists of the characters “AT” or “at”, or, to repeat the execution of the previous command line, the characters “A/”...
Page 16 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 command cannot be performed for some reason, result code 4<CR> and no subsequent commands in the command line are processed. In case of errors depending on ME operation, ERROR (or 4) response may be replaced by +CME ERROR: <err>...
Page 17 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 This is NOT a command, it is the error response to +Cxxx 3gpp TS 27.007 commands. Syntax: +CME ERROR: <err> Parameter: <err> - error code can be either numeric or verbose (see +CMEE).The possible values of <err>...
Page 18 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 Numeric Format Verbose Format Roaming not allowed in this tracking area (#13)* EPS related errors to a failure to Activate a Context and others: service option not supported (#32)* requested service option not subscribed (#33)*...
Page 19 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 This is NOT a command; it is the error response to +Cxxx 27.005 3gpp TS commands Syntax: +CMS ERROR: <err> Parameter: <err> - numeric error code. The <err> values are reported in the table:...
Page 20 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 The TA response, in case of verbose response format enabled, for the previous examples command line could be as shown below:  Information response to +CMD1? <CR><LF>+CMD1:2,1,10<CR><LF>  Information response to +CMD1=? <CR><LF>+CMD1(0-2),(0,1),(0-15)<CR><LF>...
Page 21 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 Every command issued to the Telit modules returns a result response if response codes are enabled (default). The time needed to process the given command and return the response varies, depending on the command type.
Page 22 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPUC +CSCA 5 (read and set commands) +CSAS +CRES 120 after CTRL-Z; 1 to get ‘>’ prompt +CMGS 120 after CTRL-Z; 1 to get ‘>’ prompt +CMSS 5 after CTRL-Z; 1 to get ‘>’ prompt...
Page 23 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #FTPCWD 500 (timeout set with AT#FTPTO, in case no response is receive d from server) #FTPLIST 500 (timeout set with AT#FTPTO, in case no response is receive d from server) + time to get listing...
Page 24 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 The Telit wireless modules stores the values set by several commands in the internal non volatile memory (NVM), allowing to remember this setting even after power off. In the NVM these values are set either as factory profile or as user profiles: there are two customizable user profiles and one factory profile in the NVM of the device: by default the device will start with user profile 0 equal to factory profile.
Page 25 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #QSS, #PSMRI , #SMOV, #MWI, #NITZ, #STIA, #CFLO, #SIMDET, #SIMPR, #NOPT, +CGEREP, #E2SMSRI, #E2SLRI, #TEMPMON (lt is partially stored in NVM, see command description) , +CTZU, +CTZR, +CAPD, +CSDF, +CSTF, +CSVM,...
Page 26: Storage
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 The values set by following commands are stored in NVM on demand, issuing specific commands and independently from the profile: +CSCA, +CSMP, +CSCB Stored by +CSAS command and restored by +CRES command.
Page 27: At Commands References
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 The following table lists the AT commands set and matches the availability of every single command versus the LE910KR family. COMMAND LE910-SKG LE910-STG LE910-SUG Function Command Line General Format – Command Line Prefixes ...
Page 28 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16    Single Line Connect Message    +GCI Country Of Installation    Line Signal Level    Line Quality    Speaker Loudness ...
Page 29 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16    Data Compression Reporting Hayes AT Commands – S Parameters    Number of Rings To Auto Answer  Ring Counter    Command Line Termination Character ...
Page 30 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16  +CIND Indicator Control    +CMER Mobile Equipment Event Reporting    +CPBS Select Phonebook Memory Storage    +CPBR Read Phonebook Entries    +CPBF Find Phonebook Entries ...
Page 31 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16    +CGDSCONT Define Secondary PDP Context    +CGTFT Traffic Flow Template    +CGEQOS Define EPS Quality of Service    +CGCONTRDP PDP Context Read Dynamic Parameters ...
Page 32 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16    +CMGW Write Message To Memory    +CMGD Delete Message    +CGSMS Select Service for MO SMS messages Custom AT Commands – General Configuration ...
Page 33 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16    #SMOV SMS Overflow    #MBN Mailbox Numbers    #MWI Message Waiting Indicator    #SIMPR SIM Presence Status    #NITZ Network Timezone ...
Page 34 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16    #SCFG Socket Configuration    #SCFGEXT Socket Configuration Extended    #SCFGEXT2 Socket Configuration Extended 2    Socket Dial    Socket Restore ...
Page 35 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16    #FTPREST Set restart position    #FTPRECV Receive Data in command mode    #FTPAPPEXT FTP Append Extended ® Custom AT Commands – Enhanced Easy GPRS Extension ...
Page 36 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16    #EMAILD E-mail Sending    #ESAV E-mail Parameters Save    #ERST E-mailParameters Reset    #EMAILMSG SMTP Read Message    #SMTPCL Send mail with attachment Custom AT Commands –...
Page 37 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16    #CMGS Send Message    #CMGW Write Message To Memory Custom AT Commands – SKT Specific    #GMMPSMSEN GMMP SMS Enable    #GMMPTCPOPEN GMMP TCP Connection ...
Page 38 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 AT - Starting A Command Line The prefix AT, or at, is a two-character abbreviation (ATtention), always used to start a command line to be sent from TE to TA Reference 3GPP TS 27.007...
Page 39: Repeat Last Command
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #/ - Repeat Last Command AT#/ Execute command is used to execute again the last received command. #SELINT - Select interface style AT#SELINT=<v> Set command sets the AT command interface style depending on parameter <v>.
Page 40 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 &F - Set To Factory-Defined Configuration Parameter: <value>: 0 - just the factory profile base section parameters are considered. 1 - either the factory profile base section and the extended section are considered (full factory profile).
Page 41 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 &P - Default Reset Full Profile Designation 0..1 – profile number: the wireless module is able to store 2 full configurations (see command &W). Note: differently from command Z<n>, which loads just once the desired profile, the one chosen through command &P will be loaded on every start up.
Page 42: Model Identification
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +GMI - Manufacturer Identification AT+GMI Execution command returns the manufacturer identification. Reference V.25ter +GMM - Model Identification AT+GMM Execution command returns the model identification. Reference V.25ter +GMR - Revision Identification AT+GMR Execution command returns the software revision identification.
Page 43 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 &V1 - S Registers Display AT&V1 Execution command returns the value of the S registers in decimal and hexadecimal value in the format: REG DEC <reg0> <dec> <hex> <reg1> <dec> <hex>...
Page 44: S Parameters
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 \V - Single Line Connect Message Execution command set single line connect message. AT\V<n> Parameter: <n> 0 - off 1 - on +GCI - Country Of Installation AT+GCI=<code> Set command selects the installation country code according to ITU-T.35 Annex A.
Page 45 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 E - Command Echo Set command enables/disables the command echo. ATE[<n>] Parameter: <n> 0 - disables command echo 1 - enables command echo (factory default) , hence command sent to the device are echoed back to the DTE before the response is given.
Page 46 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 V - Response Format 1 - full headers and trailers and verbose format of result codes (factory default) information responses <CR><LF> <text><CR><LF> result codes <CR><LF> <verbose code><CR><LF> Note: the <text> portion of information responses is not affected by this setting.
Page 47 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 I - Identification Information 2 - checksum check result 3 - manufacturer 4 - product name 5 - DOB version Note: if parameter is omitted, the command has the same behaviour of ATI0...
Page 48 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 &D - Data Terminal Ready (DTR) Control Note: if AT&D2 has been issued and the DTR has been tied Low, autoanswering is inhibited and it is possible to answer only issuing command ATA.
Page 49 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 \R - Ring (RI) Control Parameter: <n> 0 - RING on during ringing and further connection 1 - RING on during ringing (factory default) 2 - RING follows the ring signal Note: to check the ring option status use the &V command.
Page 50 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +IPR - Fixed DTE Interface Rate values) Reference V25ter +IFC - DTE-Modem Local Flow Control AT+IFC=<by_te>, Set command selects the flow control behaviour of the serial port in both directions: <by_ta>...
Page 51 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +ICF - DTE-Modem Character Framing AT+ICF=[<format> Set command defines the asynchronous character framing to be used when autobauding is disabled. ,[<parity>]] The LE910KR family supports only the 8 Data, 1 Stop setting.
Page 52 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 D – Dial Issues a call to phone number which corresponding alphanumeric field is <str>; ATD><str>[;] all available memories will be searched for the correct entry. If “;” is present a voice call is performed.
Page 53 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 D – Dial <nr> - internal phonebook position to be called (See commands &N and &Z) Note: LE910KR doesn’t support voice call. Issues a call overwriting the CLIR supplementary service subscription default ATD<number>I[;]...
Page 54 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 T - Tone Dial landline modems. Reference V25ter. P - Pulse Dial Set command has no effect is included only for backward compatibility with landline modems. Reference V25ter. A - Answer Execution command is used to answer to an incoming call if automatic answer is disabled.
Page 55 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 &G – Guard Tone landline modems. &Q – Sync/Async Mode AT&Q Set command has no effect is included only for backward compatibility with landline modems. %E - Line Quality Monitor And Auto Retrain Or Fallback/Fallforward AT%E<n>...
Page 56 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +DR - Data Compression Reporting Reference V25ter Basic commands that begin with the letter “S” are known as “S-Parameters”. The number following the “S” indicates the “parameter number” being referenced. If the number is not recognized as a valid parameter number, an ERROR result code is issued.
Page 57 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 S1 - Ring Counter S1 is incremented each time the device detects the ring signal of an incoming call. ATS1 S1 is cleared as soon as no ring occur. Note: the form ATS1 has no effect.
Page 58 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 S5 - Command Line Editing Character Set command sets the value of the character recognized by the device as a request ATS5=<char> to delete from the command line the immediately preceding character.
Page 59 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 S38 – Delay Before Forced Hang Up ATS38=<delay> Set command has no effect and it included only for backward compatibility Parameter: <delay> - expressed in seconds 0..255 - factory default value is 0.
Page 60 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGMI - Request Manufacturer Identification Execution command returns the device manufacturer identification code without AT+CGMI command echo. Test command returns OK result code. AT+CGMI=? Reference 3GPP TS 27.007 +CGMM - Request Model Identification...
Page 61 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CSCS - Select TE Character Set Read command returns the current value of the active character set. AT+CSCS? AT+CSCS=? Test command returns the supported values for parameter <chset>. Reference 3GPP TS 27.007...
Page 62 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CR - Service Reporting Control Set command controls whether or not intermediate result code +CR is returned AT+CR=[<mode>] from TA to TE. Parameter: <mode> 0 - disables +CR reporting (factory default)
Page 63: Network Registration Report
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CNUM - Subscriber Number where: <alpha> - alphanumeric string associated to <number>; used character set should be the one selected with +CSCS. <number> - string containing the phone number in the format <type>...
Page 64 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CREG - Network Registration Report where <stat> 0 - not registered, ME is not currently searching a new operator to register to 1 - registered, home network 2 - not registered, but ME is currently searching a new operator to register to...
Page 65 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CREG - Network Registration Report at+creg? +CREG: 0,1 (the MODULE is registered) at+creg? +CREG: 0,1 Reference 3GPP TS 27.007 +COPS - Operator Selection Set command forces an attempt to select and register the network operator.
Page 66: Facility Lock/Unlock
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +COPS - Operator Selection Note : LE910KR doesn’t support <mode>=1 and 4 because LTE only doesn’t support manual. <AcT> access technology selected: 7 E-UTRAN AT+COPS? Read command returns current value of <mode>,<format>,<oper> and <AcT> in format <format>;...
Page 67 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CLCK - Facility Lock/Unlock Parameters: [,<passwd> <fac> - facility [,<class>]] "SC" - SIM (PIN request) (device asks SIM password at power-up and when this lock command issued) "FD" - SIM fixed dialling memory feature (if PIN2 authentication has not been done during the current session, PIN2 is required as <passwd>)
Page 68 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CLCK - Facility Lock/Unlock AT+CLCK =”AO”,2 +CLCK: <status>,1 +CLCK: <status>,2 +CLCK: <status>,4 +CPWD - Change Facility Password AT+CPWD=<fac>, Execution command changes the password for the facility lock function defined by <oldpwd>, command Facility Lock +CLCK.
Page 69 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPWD - Change Facility Password Reference 3GPP TS 27.007 +CAOC - Advice Of Charge AT+CAOC= Set command refers to the Advice of Charge supplementary services that enable <mode> subscriber to get information about the cost of calls; the command also includes the possibility to enable an unsolicited event reporting of the Current Call Meter (CCM) information.
Page 70 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPOL - Preferred Operator List 0 – access technology not selected 1 – access technology selected <GSM_Compact_AcT> - GSM compact access technology 0 – access technology not selected 1 – access technology selected <UTRAN_AcT>...
Page 71 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CFUN - Set Phone Functionality Set command selects the level of functionality in the ME. AT+CFUN= [<fun>[,<rst>]] Parameters: <fun> - is the power saving function mode 0 - minimum functionality, NON-CYCLIC SLEEP mode: in this mode, the AT interface is not accessible.
Page 72 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPIN - Enter PIN AT+CPIN=<pin> Set command sends to the device a password which is necessary before it can be [,<newpin>] operated (SIM PIN, SIM PUK, PH-SIM PIN, etc.). If the PIN required is SIM PUK or SIM PUK2, the <newpin> is required. This second pin, <newpin>...
Page 73 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPIN - Enter PIN PH-CORP PUK - ME is waiting corporate personalization unblocking password to be given Note: Pin pending status at startup depends on PIN facility setting, to change or query the default power up setting use the command AT+CLCK=SC,<mode>,<pin>...
Page 74 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CIND - Indicator Control where: <descr> - indicator names as follows (along with their <ind> ranges) “battchg” - battery charge level <ind> - battery charge level indicator range 0..5 99 - not measurable “signal”...
Page 75 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CIND - Indicator Control CIND: 4,0,1,0,0,0,0,0,2 Note See command +CMER Reference 3GPP TS 27.007 +CMER - Mobile Equipment Event Reporting Set command enables/disables sending of unsolicited result codes from TA to TE AT+CMER= in the case of indicator state changes (n.b.: sending of URCs in the case of key...
Page 76 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPBS - Select Phonebook Memory Storage Set command selects phonebook memory storage <storage>, which will be used by AT+CPBS= other phonebook commands. <storage> Parameter: <storage> "SM" - SIM phonebook "FD" - SIM fixed dialling-phonebook (only phase 2/2+ SIM) "LD"...
Page 77 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPBR - Read Phonebook Entries AT+CPBR= Execution command returns phonebook entries in location number range <index1> <index1>..<index2> from the current phonebook memory storage selected with +CPBS. If <index2> is omitted, only location <index1> is returned.
Page 78 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPBR - Read Phonebook Entries Note: if “MC” is the currently selected phonebook memory storage, a sequence of missed calls coming from the same number will be saved as one missed call and +CPBR will show just one line of information.
Page 79 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPBR - Read Phonebook Entries Reference 3GPP TS 27.007 +CPBF - Find Phonebook Entries AT+CPBF= Execution command returns phonebook entries (from the current phonebook <findtext> memory storage selected with +CPBS) which alphanumeric field start with string <findtext>.
Page 80 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPBF - Find Phonebook Entries 0: phonebook entry not hidden 1: phonebook entry hidden Note: +CPBF is not applicable if the current selected storage (see +CPBS) is either “MC”, either “RC” or “LD”.
Page 81 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPBF - Find Phonebook Entries +CPBF: 2,"0169998888",129,"Jane" +CPBF: 7,"0115556666",129,"Juliet" +CPBF: 5,"0181111234",129,"Kevin" Reference 3GPP TS 27.007 +CPBW - Write Phonebook Entry AT+CPBW= Execution command writes phonebook entry in location number <index> in the [<index>]...
Page 82 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPBW - Write Phonebook Entry Note: if <index> is omitted or <index>=0, the number <number> is stored in the first free phonebook location. (example at+cpbw=0,"+390404192701",129,"Text" and at+cpbw=,"+390404192701",129,"Text") Note: if either “LD”, “MC” or “RC” memory storage has been selected (see +CPBS) it is possible just to delete the phonebook entry in location <index>,...
Page 83 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPBW - Write Phonebook Entry AT+CPBW=? +CPBW: (1-500),40,(129,145),20,1,20,40 AT+CPBW=1,"01048771234",129,"John",1,"18651896699",129,"sec_name","john @email.com" AT+CPBS="SM" AT+CPBW=? +CPBW: (1-250),40,(129,145),17,16,17,25 AT+CPBW=1,"01048771234",129,"John","Group1","18651896699",129,"sec_nam e","john@email.com" Note Remember to select the PB storage with +CPBS command before issuing PB commands. #CPBGR- Read Group Entries...
Page 84 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #CPBGR- Read Group Entries <tlength> - maximum <text> field length, integer type #CPBGW - Write Group Entry AT#CPBGW= Execution command writes Grouping information Alpha String (GAS) USIM file entry in location number <index>.
Page 85 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CCLK - Clock Management Note: the three last characters of <time>, i.e. the time zone information, are returned by +CCLK? only if the #NITZ URC ‘extended’ format has been enabled (see #NITZ).
Page 86 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CALA - Alarm Management otherwise it remains fully operative. In both cases the MODULE starts playing the alarm tone on the selected path for the ringer (see command #SRP) The device keeps on playing the alarm tone until a #WAKE or #SHDN command is received or a 90 s time-out occurs.
Page 87 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CALA - Alarm Management [+CALA: <time>,<n>,<type>,[<text>],<recurr>,<silent>] Test command returns the list of supported index values (currently just 0), alarm AT+CALA=? types, maximum length of the text to be displayed, maximum length of <recurr>...
Page 88 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CSDF – setting date format 2 DD-MM-YY 3 MM/DD/YY 4 DD/MM/YY 5 DD.MM.YY 6 YYMMDD 7 YY-MM-DD <auxmode>: 1 yy/MM/dd (default) 2 yyyy/MM/dd Note: The <time> format of +CCLK and +CALA is "yy/MM/dd,hh:mm:ss+zz"...
Page 89 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CTZR – Time Zone reporting <onoff>: 0 Disable time zone change event reporting (default) 1 Enable time zone change event reporting Read command reports the currently selected <onoff> in the format: AT+CTZR? +CTZR: <onoff>...
Page 90 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CRSM - Restricted SIM Access AT+CRSM= Execution command transmits to the ME the SIM <command> and its required parameters. ME handles internally all SIM-ME interface locking and file selection <command> [,<fileid>...
Page 91 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CRSM - Restricted SIM Access Test command returns the OK result code AT+CRSM=? Example Read binary, ICCID(2FE2) AT+CRSM=176,12258,0,0,10 +CRSM: 144,0,982850702001107686F4 Read record, ADN(6F3A) AT+CRSM=178,28474,1,4,40 +CRSM: 144,0,42434A554EFFFFFFFFFFFFFFFFFFFFFF0681105678 9282FFFFFFFFFFFFFF Update Binary, KcGPRS(6F52) AT+CRSM=214,28539,0,0,8,C69018C7958C87...
Page 92 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CSIM – Generic SIM Access <command> Set command transmits to the MT the <command> it then shall send as it is to the SIM The <response> is Returned in the same manner to the TE Parameters: <length>...
Page 93 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CSVM – Set Voice Mail Number 129 - unknown type of number and ISDN/Telephony numbering plan 145 - international type of number and ISDN/Telephony numbering plan (contains the character "+") AT+CSVM? Read command returns the currently selected voice mail number and the status (i.e.
Page 94 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CAMM - Accumulated Call Meter Maximum Note: <acmmax> = 0 value disables the feature. Read command reports the ACMmax value stored in SIM in the format: AT+CAMM? +CAMM : <acmm> where: <acmm>...
Page 95 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CCHO – Open Logical Channel Execution of the command causes the MT to return <sessionid> to allow the TE to AT+CCHO=<dfname identify a channel that is being allocated by the UICC, which is attached to ME.
Page 96 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGLA – Generic UICC Logical Channel Access +CGLA: <length>,<response> Where: <length> integer type; length of the characters that are sent to TE in <response> <response> response to the command passed on by the UICC to the MT AT+CGLA=? Test command returns the OK result code.
Page 97: Mobile Equipment Errors
LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMEE - Report Mobile Equipment Error AT+CMEE=[<n>] Set command enables/disables the report of result code: +CME ERROR: <err> as an indication of an error relating to the +Cxxx commands issued. When enabled, device related errors cause the +CME ERROR: <err> final result code instead of the default ERROR final result code.
Page 98 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGATT - EPS Attach Or Detach +CGATT: (0,1) AT+CGATT=1 Reference 3GPP TS 27.007 +CGEREP - EPS Event Reporting AT+CGEREP= Set command enables or disables sending of unsolicited result codes [<mode>[,<bfr>]] +CGEV: XXX (see below) from TA to TE in the case of certain events occurring in the TA or the network.
Page 99 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGEREP - EPS Event Reporting +CGEV: ME DEACT <PDP_type>, <PDP_addr>, [<cid>] The mobile equipment has forced a context deactivation. The <cid> that was used to activate the context is provided if known to TA +CGEV: NW DETACH The network has forced a EPS detach.
Page 100 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CEREG - EPS Network Registration Status 4 - unknown 5 - registered, roaming 2 - enable network registration and location information unsolicited result code; if there is a change of the network cell, it is issued the unsolicited result code: +CEREG: <stat>[,<tac>,<ci>[,<AcT>]]...
Page 101 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGDCONT - Define PDP Context applicable to the PDP. The allocated address may be read using the +CGPADDR command. <d_comp> - numeric parameter that controls PDP data compression 0 - off (default if value is omitted) 1 –...
Page 102 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGDSCONT - Define Secondary PDP Context given by the range returned by the test command. In EPS the command is used to define traffic flows. A special form of the set command, +CGDSCONT= <cid> causes the values for context number <cid>...
Page 103 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGTFT – Traffic Flow Template identifier>, This command allows the TE to specify a Packet Filter (PF) for a Traffic Flow <evaluation precedence Template (TFT) that is used in the GGSN in UMTS/GPRS and Packet GW in EPS index>[,<source...
Page 104 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGTFT – Traffic Flow Template <destination port range>: string type. The string is given as dot-separated numeric (0-65535) parameters in the form "f.t". <source port range>:string type. The string is given as dot-separated numeric (0- 65535) parameters in the form "f.t".
Page 105 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGTFT – Traffic Flow Template AT+CGTFT: <PDP_type>, (list of supported <packet filter identifier>s), (list of supported <evaluation precedence index>s), (list of supported <source address and subnet mask>s), (list of supported <protocol number (ipv4) / next header (ipv6)>s), (list of supported <destination port range>s), (list of supported <source port...
Page 106 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGEQOS – Define EPS Quality of Service 24.301 [83]) <DL_MBR> a numeric parameter, indicates DL MBR in case of GBR QCI. The value is in kbit/s. This parameter omitted for a non-GBR QCI. (see 3GPP TS 24.301 [83])
Page 107 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGCONTRDP – PDP Context Read Dynamic Parameters <p_cid> - a numeric parameter specifies a particular non secondary PDP context definition. The parameter is local to the TE-MT interface and used in other PDP context-related commands.
Page 108 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGSCONTRDP – Secondary PDP Context Read Dynamic Parameters +CGSCONTRDP:<cid>,<p_cid>,<bearer_id>[<CR><LF> +CGSCONTRDP: <cid>, <p_cid>,<bearer_id>[…]] [<cid>] The execution command returns <p_cid> and <bearer_id> for a given <cid>. If the context cannot be found an ERROR response returned.If the parameter <cid> is omitted, the <cid>, <p_cid>...
Page 109 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGTFTRDP- Traffic Flow Template Read Dynamic Parameters <cid>: a numeric parameter which specifies a particular PDP context definition or Traffic Flows definition (see +CGDCONT and +CGDSCONT commands). The following parameters are defined in 3GPP TS 23.060 [47].
Page 110 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGEQOSRDP – EPS Quality of Service Read Dynamic Parameters +CGEQOSRDP:<cid>,<QCI>,[<DL_GBR>,<UL_GBR>],[<DL_MBR>,<UL_M BR>][…]] Description: The execution command returns the Quality of Service parameters <QCI>, [<DL_GBR> and <UL_GBR>] and [<DL_MBR> and <UL_MBR>] of the established PDP Context associated to the provided context identifier <cid>.
Page 111 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGPIAF – Printing IP Address Format 1 - Use IPv6-like colon-notation. IP address, and subnetwork mask if applicable [,<IPv6_compressZer and when given explicitly, are separated by a space. os>]]]] <IPv6_SubnetNotation> - decides the subnet-notation for <remote address and subnet mask>...
Page 112 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGACT - PDP Context Activate Or Deactivate Note: if no <cid>s are specified, the activation/deactivation form of the command activates/deactivates all defined contexts. Default PDP context(cid 1) is automatically activated by piggybacking on LTE attach procedure for Always-on IP connectivity.
Page 113 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGPADDR - Show PDP Address AT+CGPADDR=1 +CGPADDR: 1,”xxx.yyy.zzz.www” AT+CGPADDR=? +CGPADDR: (1) Reference 3GPP TS 27.007 +CGCMOD – 3G Quality Of Service Profile (Negotiated) AT+CGCMOD=[<cid1> The execution command is used to modify the specified PDP context(s) with [,<cid2>[,…,<cidN>]]]...
Page 114 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 + CBC - Battery Charge Note: without battery/power connected on VBATT pins or during a power fault the unit is not working, therefore values <bcs>=2 and <bcs>=3 will never appear. Test command returns parameter values supported as a compound value.
Page 115 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CSMS - Select Message Service 0 - type not supported 1 - type supported Read command reports current service setting along with supported message types AT+CSMS? in the format: +CSMS: <service>,<mt>,<mo>,<bm>...
Page 116 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CPMS - Preferred Message Storage +CPMS: <usedr>,<totalr>,<usedw>,<totalw>,<useds>,<totals> where: <usedr> - number of SMs stored into <memr> <totalr> - max number of SMs that <memr> can contain <usedw> - number of SMs stored into <memw>...
Page 117 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMGF - Message Format Example AT+CMGF=1 Reference 3GPP TS 27.005 +CSCA -Service Center Address Set command sets the Service Center Address to be used for mobile originated SMS AT+CSCA= <number> transmissions.
Page 118 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CSMP - Set Text Mode Parameters <fo> - first octet of 3GPP TS 23.040 SMS-SUBMIT or SMS-DELIVER, in integer [,<dcs>]]]] format (default 17, i.e. SMS-SUBMIT with validity period in relative format).
Page 119 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CSMP - Set Text Mode Parameters bit[6]: Single Shot SM; [0] - the SC is not required to make up to one delivery attempt [1] - the SC is required to make up to one delivery attempt...
Page 120 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CSMP - Set Text Mode Parameters Set the parameters for an outgoing message with validity period in enhanced format: the <vp> string actually codes 60 seconds of validity period. AT+CSMP=9,“023C0000000000“ Set the parameters for an outgoing message with validity period in enhanced format: the <vp>...
Page 121 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CSCB -Select Cell Broadcast Message Types <dcss> - Data Coding Schemes, string type: all different possible combinations of CBM data coding schemes; default is empty string (“”). Note: the current settings are stored through +CSAS AT+CSCB? Read command reports the current value of parameters <mode>, <mids>...
Page 122 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CRES - Restore Settings Note: If parameter is omitted the command restores message service settings from NVM. Test command returns the possible range of values for the parameter <profile>. AT+CRES=? Reference 3GPP TS 27.005...
Page 123 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CNMI - New Message Indications To Terminal Equipment <mt> - result code indication reporting for SMS-DELIVER 0 - No SMS-DELIVER indications are routed to the TE and message is stored. 1 - If SMS-DELIVER is stored into ME/TA, indication of the memory location is routed to the TE using the following unsolicited result code: +CMTI: <memr>,<index>...
Page 124 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CNMI - New Message Indications To Terminal Equipment  If <dcs> indicates that 8-bit or UCS2 data coding scheme is used or <fo> indicates that GSM03.40/23.040 TP-User-Data-Header-Indication is set (bit 6 of <fo> is 1), each 8-bit octet will be converted into two IRA character long hexadecimal number (e.g.
Page 125 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CNMI - New Message Indications To Terminal Equipment (TEXT Mode) +CDS: <fo>,<mr>,<ra>,<tora>,<scts>,<dt>,<st> where: <fo> - first octet of the message PDU <mr> - message reference number <ra> - recipient address, string type, represented in the currently selected character set (see +CSCS) <tora>...
Page 126 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CNMA – New Message Acknowledgement (PDU Mode) Execution command confirms correct reception of a new message (SMS-DELIVER AT+CNMA [=<n> or SMS-STATUS-REPORT) which is routed directly to the TE. [,<length> [<CR> Acknowledge with +CNMA is possible only if the +CSMS parameter is set to PUD is given<ctrl-...
Page 127 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CNMA – New Message Acknowledgement Send positive acknowledgement to the network. AT+CNMA=0 Message is received from network. +CMT: "",70 06816000585426000480980600F170110370537284… Send negative acknowledgement(Unspecified error) to the network. AT+CNMA=2,3<CR> > 00FF00 <Ctrl-Z>...
Page 128 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMGL - List Messages (PDU Mode) Parameter: <stat> 0 - new message 1 - read message 2 - stored message not yet sent 3 - stored message already sent 4 - all messages.
Page 129 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMGL - List Messages <tooa/toda> - type of number <oa/da> 129 - number in national format 145 - number in international format (contains the "+") <length> - text length <data> - TP-User-Data ...
Page 130 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMGL - List Messages 079128019291903011640A8110567892820000A70CF4F29C0E6A97E7F3F0B90 +CMGL: 1,2,,21 079128019291903011640A8110516529700000A709027A794E77B95C2E +CMGL: 26,2,,17 08812801009901025911640A8110567892820014A704C7D1B1DB Reference 3GPP TS 27.005 +CMGR - Read Message Execution command reports the message with location value <index> from AT+CMGR= <memr> message storage (<memr> is the message storage for read and delete SMs <index>...
Page 131 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMGR - Read Message Output format for sent messages: +CMGR: <stat>,<da>,<alpha>[,<toda>,<fo>,<pid>,<dcs>,[<vp>], <sca>,<tosca>,<length>]<CR><LF><data> Output format for message delivery confirm: +CMGR: <stat>,<fo>,<mr>,,,<scts>,<dt>,<st> where: <stat> - status of the message "REC UNREAD" - new received message unread "REC READ"...
Page 132 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMGR - Read Message (e.g. octet 0x2A will be converted as two characters 0x32 0x41) Note: in both cases if status of the message is 'received unread', status in the storage changes to 'received read'.
Page 133 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMGS - Send Message Note: the PDU shall be hexadecimal format (each octet of the PDU is given as two IRA character long hexadecimal number) and given in one line. Note: when the length octet of the SMSC address (given in the PDU) equals zero, the SMSC address set with command +CSCA is used;...
Page 134 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMGS - Send Message backspace can be used to delete last character and carriage returns can be used. - if current <dcs> (see +CSMP) indicates that 8-bit or UCS2 data coding scheme is used or current <fo>...
Page 135 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMGS - Send Message AT+CMGF=1 AT+CSMP=17,167,0,0 AT+CMGS=”01090255219”,129 >TEST MESSAGE +CMGS:125 Reference 3GPP TS 27.005 +CMSS - Send Message From Storage Execution command sends to the network a message which is already stored in the AT+CMSS= <memw>...
Page 136 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMSS - Send Message From Storage +CMGW: 28 AT+CMSS=28 +CMSS: 136 Reference 3GPP TS 27.005 +CMGW - Write Message To Memory (PDU Mode) (PDU Mode) AT+CMGW= Execution command writes in the <memw> memory storage a new message.
Page 137 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMGW - Write Message To Memory 129 - number in national format 145 - number in international format (contains the "+") <stat> - message status. "REC UNREAD" - new received message unread "REC READ"...
Page 138 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMGW - Write Message To Memory SIM interacting commands are issued. Note: it is possible to save a concatenation of at most 10 SMs; the maximum number of chars depends on the <dcs>: 1530 chars if 3GPP TS 03.38/23.038...
Page 139 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CMGD - Delete Message Note: if <delflag> is present and not set to 0 then <index> is ignored and ME shall follow the rules for <delflag> shown above. Note: if the location to be deleted is empty, an error message is reported.
Page 140 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 +CGSMS – Select service for MO SMS messages AT+CGSMS= The set command is used to specify the service or service preference that the MT wi [<service>] ll use to send MO SMS messages.
Page 141 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #CGMM - Model Identification Execution command returns the device model identification code with command AT#CGMM echo. Test command returns the OK result code. AT#CGMM=? Example AT#CGMM #CGMM: LE910-SKG #CGMR - Revision Identification AT#CGMR Execution command returns device software revision number with command echo.
Page 142 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #CCID - Read ICCID #PCT - Display PIN Counter AT#PCT Execution command reports the PIN/PUK or PIN2/PUK2 input remaining attempts, depending on +CPIN requested password in the format: #PCT: <n> where: <n>...
Page 143 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #REBOOT - Reboot AT#REBOOT=? Example AT#REBOOT #Z - Extended reset Set command loads both base section and extended section of the AT#Z=<profile> specified user profile stored with AT&P. Parameter <profile> 0 – user profile 0 1 –...
Page 144 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #ENHRST – Periodic ReseT <delay>. AT#ENHRST=1,60 Examples …. Module reboots after 60 minutes … AT#ENHRST=1,0 #WAKE - Wake From Alarm Mode AT#WAKE= Execution command stops any eventually present alarm activity and, if the module [<opmode>]...
Page 145 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #TEMPMON - Temperature Monitor Set command sets the behavior of the module internal temperature monitor. AT#TEMPMON= <mod> [,<urcmode> Parameters: [,<action> [,<hyst_time> <mod> [,<GPIO>]]]] 0 - sets the command parameters. 1 - triggers the measurement of the module internal temperature, reporting the result in the format: #TEMPMEAS: <level>,<value>...
Page 146 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 levels (default is 0). If <action> is not zero, it is mandatory to set the <hyst_time> parameter too. 0 - no action (00) 1 - automatic shut-down when the temperature is beyond the extreme...
Page 147 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 Operating Temperature Lower Bound -20°C Operating Temperature Operating Temperature Upper Bound +78°C Extreme Temperature Upper Bound +90°C WCDMA Limits Extreme Temperature Lower Bound -30°C Operating Temperature Lower Bound -20°C Operating Temperature Operating Temperature Upper Bound +90°C...
Page 148 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #GPIO - General Purpose Input/Output Pin Control respectively (see Note). <save> - GPIO pin save configuration 0 – pin configuration is not saved 1 – pin configuration is saved Note: when <save> is omitted the configuration is stored only if user set or reset ALTx function on <dir>...
Page 149 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #GPIO - General Purpose Input/Output Pin Control AT#GPIO=4,1,1 AT#GPIO=5,0,0 AT#GPIO=6,2 #GPIO: 0,1 #ALARMPIN – Alarm Pin Set command sets the GPIO pin for the ALARM pin AT#ALARMPIN= Parameters: <pin> <pin> defines which GPIO shall be used as ALARM pin.
Page 150 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SLED - STAT_LED GPIO Setting  registered in idle: blinking 300ms on and 2,7s off  registered in idle with powersaving : blinking time depends on network condition in order to minimize power consumption <on_duration>...
Page 151 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #E2SMSRI - SMS Ring Indicator AT#E2SMSRI? Read command reports the duration in ms of the pulse generated on receipt of an incoming SM, in the format: #E2SMSRI: <n> Note: as seen before, the value <n>=0 means that the RI pin response to an incoming SM is disabled.
Page 152 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #VAUX- Auxiliary Voltage Output Control <stat> 0 - output off 1 - output on 2 - query current value of VAUX pin Note: when <stat>=2 and command is successful, it returns: #VAUX: <value>...
Page 153 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #V24CFG - V24 Output Pins Configuration driver. (default) 1 - GPIO mode: output pins are directly controlled by #V24 command only. Read command returns actual mode for all the pins in the format: AT#V24CFG? #V24CFG: <pin1>,<mode1>[<CR><LF><CR><LF>...
Page 154 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #CBC- Battery And Charger Status where: <ChargerState> - battery charger state 0 - charger not connected 1 - charger connected and charging 2 - charger connected and charge completed <BatteryVoltage> - battery voltage in millivolt: it is the real battery voltage only if charger is not connected;...
Page 155 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #MONI - Cell Monitor PWR:<dBm> where: <netname> - name of network operator <cc> - country code <nc> - network operator code <n> - progressive number of adjacent cell <rsrp> - Reference Signal Received Power <rsrq>...
Page 156 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SERVINFO - Serving Cell Information <RSRP> - Reference Signal Received Power AT#SERVINFO=? Test command returns the OK result code. #RFSTS – Read Current Network Status in E-UTRAN AT#RFSTS Read current status in the format...
Page 157 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #RFSTS – Read Current Network Status in E-UTRAN 13 - WAIT_FOR_RR_CONNECTION_LU 14 - WAIT_FOR_RR_CONNECTION_MM 15 - WAIT_FOR_RR_CONNECTION_IMSI_DETACH 17 - REESTABLISHMENT_INITIATED 18 - WAIT_FOR_RR_ACTIVE 19 - IDLE 20 - WAIT_FOR_ADDITIONAL_OUTGOING_MM_CONNECTION 21 - WAIT_FOR_RR_CONNECTION_REESTABLISHMENT...
Page 158 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #RFSTS – Read Current Network Status in E-UTRAN 38 - RR_STATE_MAX AT#RFSTS=? Test command returns the OK result code. #QSS - Query SIM Status Set command enables/disables the Query SIM Status unsolicited indication in the AT#QSS= [<mode>]...
Page 159 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #QSS - Query SIM Status #CPBD - Delete All Phonebook Entries AT#CPBD Execution command deletes all phonebook entries in the current phonebook memor y storage selected with +CPBS. Note: in case of SM or ME, it takes some time to delete all its entries.
Page 160 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #MBN - Mailbox Numbers <type> - type of mailbox number octet in integer format 129 - national numbering scheme 145 - international numbering scheme (contains the character "+") <text> - the alphanumeric text associated to the number; used character set should be the one selected with command +CSCS <mboxtype>...
Page 161 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #MWI - Message Waiting Indication AT#MWI=<enable> Set command enables/disables the presentation of the message waiting indicator URC. Parameter: <enable> 0 - disable the presentation of the #MWI URC 1 - enable the presentation of the #MWI URC each time a new message waiting...
Page 162 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #MWI - Message Waiting Indication 4 - E-mail 5 - Other <count> - message counter: number of pending messages related to the message waiting indicator <indicator> as it is stored on SIM.
Page 163 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #NITZ - Network Timezone Set command enables/disables (a) automatic date/time updating, (b) Full AT#NITZ= Network Name applying and (c) #NITZ URC; moreover it permits to change [<val> [,<mode>]] the #NITZ URC format.
Page 164 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #NITZ - Network Timezone Network Name applying, (c) #NITZ URC (as well as its format) are currently enabled or not, in the format: #NITZ: <val>,<mode> AT#NITZ=? Test command returns supported values of parameters <val> and <mode>.
Page 165 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #BND - Select Band AT#BND= Set command selects the E-UTRAN current band. [<E-UTRAN band>] Parameter <E-UTRAN band> For SKT model all combinations of next bands can be used: - 4 : E-UTRAN BAND 3...
Page 166 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #GAUTH - PPP-GPRS Connection Authentication Type 2 – CHAP authentication Note : if the settings on the server side(the host application) of the PPP are not compatible with the AT#GAUTH setting, then the PDP Context Activation will use no authentication.
Page 167 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 where: <mode> - SIM Detection mode, as before <simin> - SIMIN pin real status 0 - SIM not inserted 1 - SIM inserted AT#SIMDET=? Test command reports the supported range of values for parameter <mode>...
Page 168 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #I2CWR – Write to I2C <sdaPin>: GPIO number for SDA . Valid range is “any input/output pin” (see <registerId>, <len> “Hardware User’s Guide”.) <sclPin>: GPIO number to be used for SCL. Valid range is “any output pin” (see “Hardware User’s Guide”).
Page 169 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #I2CRD – Read from I2C GPIOs <sdaPin>, <sclPin>, <deviceId>, <sdaPin>: GPIO number for SDA . Valid range is “any input/output pin” (see <registerId>, <len> “Hardware User’s Guide”.) <sclPin>: GPIO number to be used for SCL. Valid range is “any output pin” (see “Hardware User’s Guide”).
Page 170 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #PSMRI – Power Saving Mode Ring Indicator Note: the behavior for #PSMRI is invoked only when modem is in sleep mode (AT+CFUN=5 and DTR Off on Main UART) AT#PSMRI? Read command reports the duration in ms of the pulse generated, in the format: #PSMRI: <n>...
Page 171 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #CMGLCONCINDEX – Report concatenated SMS indexes #LANG – select language AT#LANG=<lan> Set command selects the currently used language for displaying different messages Parameter: <lan> - selected language “en” – English (factory default) “it”...
Page 172 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #NWSCANTMR - Network Scan Timer AT#NWSCANTMR Execution command reports time, in seconds, when the next scan activity will be executed. The format is: #NWSCANTMREXP: <time> Note: if <time> is zero it means that the timer is not running...
Page 173 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #CDORM – Dormant Control Command #CDORM:<unsolicited_status>[,<call_id>, <dormant_status>][<CR><LF> #CDORM:<unsolicited_status>,<call_id>, <dormant_status>[…]] Where: <unsolicited_status> 0 - Disabled unsolicited indication (default) 1 Enabled unsolicited indication AT#CDORM=? The test command returns the possible ranges of <action> and <call_id>...
Page 174 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #LTEDS – Read current network status in E-UTRAN Channel Number BAND Band Class 20 MHz Band Width PLMN 450 05 Public Land Mobile Network 12544 Tracking Area Code CELL(Physical 16333 (77)
Page 175 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #LTEDS – Read current network status in E-UTRAN 4 : "TAU_INIT" 5 : "SVC_REQ_INIT" 6 : "DEREGINIT" 7 : "INVALID" Note : Sub Status -This parameter depend on the EMM Status is “DEREGISTERD”.
Page 176 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #LTEDS – Read current network status in E-UTRAN 1 : "WAIT4ESM_REP" //EMM_WAITING_FOR_ESM_RESPONSE Note : RRC 0 : IDLE_STATE 1 : WAITING_FOR_RRC_CONFIRMATION_STATE 2 : CONNECTED_STATE 3 : RELEASING_RRC_CONNECTION_STATE Note : SVC 0 : NO_SVC...
Page 177 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #LTEBW: <BAND>,<BW> Test command reports the supported range of parameters values. AT#LTEBW=? #LTEBW: (3, 1-63) #LTEBW: (5, 1-15) #DOMAIN – Set preferred service domain AT#DOMAIN= Execution command sets service_domain_pref value. <service_domain>...
Page 178 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SS - Socket Status command. <locIP> - IP address associated by the context activation to the socket. <locPort> - two meanings: the listening port if we put the socket in listen mode.
Page 179 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SI - Socket Info <CR><LF> … #SI: <connId6>,<sent6>,<received6>,<buff_in6>,<ack_waiting6> AT#SI=? Test command reports the range for parameter <connId>. AT#SI Example #SI: 1,123,400,10,50 #SI: 2,0,100,0,0 #SI: 3,589,100,10,100 #SI: 4,0,0,0,0 #SI: 5,0,0,0,0 #SI: 6,0,98,60,0 Sockets 1,2,3,6 are opened with some data traffic.
Page 180 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #ST – Socket Type the response format is: #ST: <connId1>,<type1>,<direction1> <CR><LF> … #ST: <connId6>,<type6>,<direction6> Test command reports the range for parameter <connId>. AT#ST=? Example Single socket: AT#ST=3 #ST:3,2,1 Socket 3 is an UDP dialer.
Page 181 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SGACT - Context Activation <userId> - string type, used only if the context requires it <pwd> - string type, used only if the context requires it Note: context activation/deactivation returns ERROR if there is not any socket associated to it (see AT#SCFG).
Page 182 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SCFG - Socket Configuration 1..5 - numeric parameter which specifies a particular PDP context definition. (see +CGDCONT command) <pktSz> - packet size to be used by the TCP/UDP/IP stack for data sending.
Page 183 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SCFG - Socket Configuration #SCFGEXT - Socket Configuration Extended AT#SCFGEXT= Set command sets the socket configuration extended parameters. <connId>, Parameters: <connId> - socket connection identifier <srMode>, <dataMode>, 1..6 <keepalive> <srMode> - SRing URC mode [,<ListenAutoRsp>...
Page 184 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SCFGEXT - Socket Configuration Extended 1 - data represented as sequence of hexadecimal numbers (from 00 to FF) Each octet of the data is given as two IRA character long hexadecimal number Note: <keepalive>...
Page 185 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SCFGEXT2 - Socket Configuration Extended (#SCFG command 6th parameter old behaviour, start only first time if new data are received from the serial port) 1 – new behaviour for transmission timer : Restart when new data received from serial port Note : is necessary to avoid overlapping of the two methods.
Page 186 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SCFGEXT2 - Socket Configuration Extended available data(#SRECV or SRING mode 2), it is indicated cause 1 for both possible FIN and RST from remote. Read command returns the current socket extended configuration...
Page 187 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SCFGEXT2 - Socket Configuration Extended #SD - Socket Dial AT#SD=<connId>, Execution command opens a remote connection via socket. <txProt>,<rPort>, Parameters: <connId> - socket connection identifier <IPaddr> [,<closureType> 1..6 [,<lPort> <txProt> - transmission protocol [,<connMode>...
Page 188 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SD - Socket Dial Note: if we set <connMode> to command mode connection and the command is successful, the socket is opened and we remain in command mode and we see the result code OK.
Page 189 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SL - Socket Listen <listenState> - 0 - closes socket listening 1 - starts socket listening <listenPort> - local listening port 1..65535 <closure type> - socket closure behavior for TCP when remote host has closed 0 –...
Page 190 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SLUDP – UDP Socket Listen <listenState> - 0 - closes socket listening 1 - starts socket listening <listenPort> - local listening port 1..65535 Note: if successful, commands returns a final result code OK . Then, when there’s...
Page 191 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SA - Socket Accept Test command reports the range of values for all the parameters. AT#SA=? #SLASTCLOSURE – Detect the cause of a socket disconnection Execution command reports socket disconnection cause AT#SLASTCLOSUR E[=<connId>]...
Page 192 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SLASTCLOSURE – Detect the cause of a socket disconnection Note: if more consecutive closure causes are received, the original disconnection cause is saved. (For instance: if a TCP FIN is received from remote...
Page 193 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SRECV – Received Data in Command Mode Test command returns the range of supported values for parameters AT#SRECV=? <connId> <maxByte> and <UDPInfo> Example SRING URC (<srMode> be 0, <dataMode> be 0) telling data have just come through connected socket identified by <connId>=1 and are now buffered...
Page 194 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SSEND – Send Data in Command Mode Execution command permits, while the module is in command mode, to AT#SSEND= send data through a connected socket. <connId> Parameters: <connId> - socket connection identifier 1..6...
Page 195 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SSENDEXT – Send Data in Command Mode extended BS, i.e. previous character is not deleted) Test command returns the range of supported values for parameters <connId> and AT#SSENDEXT=? <bytestosend> Example Open the socket in command mode: AT#SD=1,0,<port>,”IP address”,0,0,1...
Page 196 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SSENDUDP – send UDP data to a specific remote host Starts listening on <LocPort>(previous setting of firewall through #FRWL has to be done) Example AT#SLUDP=1,1,<LocPort> SRING: 1 // UDP data from a remote host available...
Page 197 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SSENDUDP – send UDP data to a specific remote host a reponse: AT#SSENDUDP=1,<RemIP2>,<RemPort2> >response to second host #SSENDUDPEXT – send UDP data to a specific remote host extended AT#SSENDUDPEXT This command permits, while the module is in command mode, to send data over =<connId>,<bytestose...
Page 198 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SGACTAUTH – Easy GPRS Authentication Type Note: the parameter is not saved in NVM Read command reports the current EPS authentication type, in the format: AT#SGACTAUTH? #SGACTAUTH: <type> AT#SGACTAUTH=? Test command returns the range of supported values for parameter <type>.
Page 199 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SGACTCFG – Context Activation and Configuration Note: if the automatic activation is enabled on a context, then it is not allowed to modify by the command AT#SCFG the association between the context itself and the socket connection identifier all the other parameters of command AT#SCFG are modifiable while the socket is not connected.
Page 200 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SGACTCFGEXT – Context Activation and Configuration Note: values are automatically saved in NVM. Read command reports the state of all the six contexts, in the format: AT#SGACTCFGEX #SGACTCFGEXT: <cid1>,<abortAttemptEnable1>,,0,0,0<CR><LF> … #SGACTCFGEXT: <cid6>,<abortAttemptEnable6>,,0,0,0 where: <cidn>...
Page 201 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #FTPOPEN - FTP Open 1200 (120 seconds). The FTPTO value that exceed 1200 is considered as 1200. Note: Before opening FTP connection the EPS must been activated with AT#GPRS=1 or AT# SGACT AT#FTPOPEN=? Test command returns the OK result code.
Page 202 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #FTPPUT - FTP Put Note: if we set <connMode> to 1, the data connection is opened and we remain in command mode and we see the result code OK (instead of CONNECT) Parameter: <filename>...
Page 203 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #FTPGETPKT - FTP Get in command mode It’s possible to read data afterwards issuing #FTPRECV command. Parameter: <filename> - file name, string type. (maximum length: 200 characters). <viewMode> - permit to choose view mode (text format or Hexadecimal) 0 –...
Page 204 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #FTPDELE - FTP Delete Execution command, issued during an FTP connection, deletes a file from the AT#FTPDELE= remote working directory. [<filename>] Parameter: <filename> - string type, it’s the name of the file to delete.
Page 205 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #FTPLIST - FTP List Test command returns the OK result code. AT#FTPLIST=? #FTPFSIZE – Get file size from FTP server AT#FTPFSIZE= Execution command, issued during an FTP connection, permits to get file size of <filename>...
Page 206 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #FTPREST – Set restart position for FTP GET It permits to restart a previously interrupted FTP download from the selected position in byte. Parameters: <restartposition> – position in byte of restarting for successive #FTPGET (or #FTPGETPKT) Note: It’s necessary to issue #FTPTYPE=0 before successive #FTPGET (or...
Page 207 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #FTPRECV – Receive Data In Command Mode #FTPRECV:<available> AT#FTPRECV? Example #FTPRECV: 3000 Read required part of the buffered data: AT#FTPRECV=400 #FTPRECV:400 Text row number 1 * 11111111111111111111111111 * Text row number 2 * 22222222222222222222222222 *...
Page 208 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #FTPAPPEXT - FTP Append Extended <connMode> parameter set to command mode connection. Parameters: <bytestosend> - number of bytes to be sent 1..1500 <eof> - data port closure 0 – normal sending of data chunk 1 –...
Page 209 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #FTPAPPEXT - FTP Append Extended is returned #FTPAPPEXT:<SentBytes> If the user has to reopen the data port to send another (or append to the same) file, he can restart with the FTPPUT (or FTPAPP).
Page 210 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #PASSW - Authentication Password empty string “”). Test command returns the maximum allowed length of the string parameter <pwd>. AT#PASSW=? The allowed maximum length is 127. Example AT#PASSW="myPassword" #PKTSZ - Packet Size...
Page 211 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #DSTO -Data Sending Time-Out Note: this time-out applies to data whose size is less than packet size and whose sending would have been delayed for an undefined time until new data to be sent had been received and full packet size reached.
Page 212 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SKTSET - Socket Definition either: any valid IP address in the format: xxx.xxx.xxx.xxx - any host name to be solved with a DNS query in the format: <host name> (factory default is the empty string “”) <closure type>...
Page 213 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #QDNS - Query DNS Note: <IP address> is in the format: xxx.xxx.xxx.xxx Test command returns the OK result code. AT#QDNS=? Note This command requires that the authentication parameters are correctly set and that the EPS network is present.
Page 214 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #DNS – Manual DNS Selection this value instead of the secondary DNS server come from the network (default is “0.0.0.0”). Note: if <primary> is ”0.0.0.0.0” and <secondary> is not “0.0.0.0”, then issuing AT#DNS=…...
Page 215 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SKTSAV - Socket Parameters Save Execution command saves the actual socket parameters in the NVM of the device. AT#SKTSAV The socket parameters to store are: - User ID - Password - Packet Size...
Page 216 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SKTRST - Socket Parameters Reset AT#SKTRST Execution command resets the actual socket parameters in the NVM of the device to the default ones. The socket parameters to reset are: - User ID...
Page 217 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #GPRS - GPRS Context Activation 1 - EPS context activated 2 - EPS context activation pending. Test command returns the allowed values for parameter <mode>. AT#GPRS=? Example AT#GPRS=1 +IP: 129.137.1.1 Now EPS Context has been activated and our IP is 129.137.1.1 AT#GPRS=0 Now EPS context has been deactivated, IP is lost.
Page 218 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SKTD - Socket Dial the EPS has been activated with AT#GPRS=1 Note: If all parameters are omitted then the behaviour of Set command is the same as Read command. AT#SKTD? Read command reports the socket dial parameters values, in the format: AT#SKTD: <socket type>,<remote port>,<remote addr>,...
Page 219 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SKTL - Socket Listen +CONN FROM: <remote addr> Where: <remote addr> - host address of the remote machine that contacted the device. When the connection is established the CONNECT indication is given and the modem goes into data transfer mode.
Page 220 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SKTL - Socket Listen send escape sequence NO CARRIER Now listen is not anymore active to stop listening AT#SKTL=0,0,1024, 255 Note The main difference between this command and #SKTD is that #SKTL does not...
Page 221 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #FRWL - Firewall Setup Note: the firewall applies for incoming (listening) connections only. Firewall general policy is DROP, therefore all packets that are not included into an ACCEPT chain rule will be silently discarded.
Page 222 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #GDATAVOL - GPRS Data Volume format: #GDATAVOL: <cidn>,<totn>,<sentn>,<receivedn>[<CR><LF> #GDATAVOL: <cidm>,<totm>,<sentm>,<receivedm>[…]] where: <cidn> - PDP context identifier 1..5 - numeric parameter which specifies a particular PDP context definition. (see +CGDCONT command) <totn> - number of bytes either received or transmitted in the last EPS session for <cidn>...
Page 223 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #ICMP – ICMP Ping Support ECHO_REPLY only to a subset of IP Addresses pinging it; this subset of IP Addresses has been previously specified through #FRWL (see) 2 - enable free ICMP Ping support; the module is sending a proper ECHO_REPLY to every IP Address pinging it.
Page 224 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #PING – Ping Request #PING: 02,”81.201.117.177”,5,50 #PING: 03,”81.201.117.177”,6,50 #PING: 04,”81.201.117.177”,5,50 Note When the Echo Request timeout expires (no reply received on time) the response will contain <replyTime> set to 600 and <ttl> set to 255.
Page 225 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #NWDNS – DNS from Network AT#NWDNS=? Test command returns a list of defined <cid>s. #SMSMOVE – Move Short Message To Other Memory AT#SMSMOVE= Execution command moves selected Short Message from current memory to destination memory.
Page 226 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SMSMOVE – Move Short Message To Other Memory //list the SMs to discover the memory index AT#SMSMOVE=1 //move the SM in the first position of ME to SIM AT#SMSMOVE? #SMSMOVE: "ME",2,100,"SM",1,50 //now we have 2 SMs in ME and 1 in SIM #SMSMODE –...
Page 227 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #ESMTP - E-mail SMTP Server Note The SMTP server used shall be inside the APN space (the smtp server provided by the network operator) or it must allow the Relay, otherwise it will refuse to send the e-mail.
Page 228 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #EUSER - E-mail Authentication User Name Note It is a different user field than the one used for EPS authentication (see #USERID). Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved...
Page 229 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #EPASSW - E-mail Authentication Password AT#EPASSW= Set command sets the password string to be used during the authentication step of the SMTP. [<e-pwd>] Parameter: <e-pwd> - e-mail authentication password, string type.
Page 230 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #EMAILD - E-mail Sending ..wait.. Message has been sent. #ESAV - E-mail Parameters Save AT#ESAV Execution command saves the actual e-mail parameters in the NVM of the device. The values stored are:...
Page 231 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SMTPCL – Send Mail with Attachment The escape sequence has to be sent to close the SMTP connection. Encoding of data received on the serial port is performed if required (binary data), before transmission on the SMTP socket.
Page 232 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SMTPCL – Send Mail with Attachment …data received on the serial port are sent as attachment…. Send escape sequence to close the SMTP connection NO CARRIER at#smtpcl="me@myaddress.com","test2",2,"image.jpg",1 >message body...this is the text of the mail message…...
Page 233 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #HTTPCFG – configure HTTP parameters <ssl_enabled> - Numeric parameter indicating if the SSL encryption is enabled. 0 – SSL encryption disabled (default) 1 – SSL encryption enabled (not yet implemented and not available for setting) <timeout>: Numeric parameter indicating the time interval in seconds to wait for...
Page 234 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #HTTPQRY – send HTTP GET, HEAD or DELETE request AT#HTTPQRY=<pr Execution command performs a GET, HEAD or DELETE request to HTTP server. of_id>,<command>,< resource>[,<extra_he Parameters: <prof_id> - Numeric parameter indicating the profile identifier.
Page 235 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #HTTPQRY – send HTTP GET, HEAD or DELETE request <command>s),<r_length>,<m_length> where: <r_length> - integer type value indicating the maximum length of parameter <resource>. <m_length> - integer type value indicating the maximum length of parameter <extra_header_line>.
Page 236 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #HTTPSND – send HTTP POST or PUT request Note: the HTTP request header sent with #HTTPSND always contains the “Connection: close” line, and it can not be removed. When the HTTP server answer is received, then the following URC is put on the serial port: #HTTPRING: <prof_id>,<http_status_code>,<content_type>,<data_size>...
Page 237 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #HTTPRCV – receive HTTP server data Execution command permits the user to read data from HTTP server in response to a AT#HTTPRCV=<pr previous HTTP module request. The module is notified of these data by the of_id>,[<maxByte>]...
Page 238 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #STIA - SIM Tookit Interface Activation 18 - enable SAT and extended unsolicited indication #STN (see #STGI) . only GSM default alphaber is supported 19 - enable SAT and reduced unsolicited indication #STN (see #STGI). only GSM...
Page 239 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #STIA - SIM Tookit Interface Activation 2 - SIM Initialization and File Change Notification; 3 - SIM Initialization; 4 - SIM Reset In this case neither #STGI nor #STSR commands are required: ...
Page 240 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #STIA - SIM Tookit Interface Activation 0 - clear message after a delay 1 - wait for user to clear message <text> - (optional) text to be displayed to user In this case: if <cmdDetails>/bit8 is 0 neither #STGI nor #STSR commands are...
Page 241 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #STIA - SIM Tookit Interface Activation 150 - SMS control response 160 - call/SS/USSD response <Result> 0 - Call/SMS not allowed 1 - Call/SMS allowed 2 - Call/SMS allowed with modification <Number>...
Page 242 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #STIA - SIM Tookit Interface Activation Test command returns the range of available values for the parameters <mode> and AT#STIA=? <timeout>. Note Just one instance at a time, the one which first issued AT#STIA=n (with n different from zero), is allowed to issue SAT commands, and this is valid till the same instance issues AT#STIA=0.
Page 243 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #STGI - SIM Tookit Get Information #STGI: <cmdType>,<refresh type> where: <refresh type> 0 - SIM Initialization and Full File Change Notification; 1 - File Change Notification; 2 - SIM Initialization and File Change Notification;...
Page 244 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #STGI - SIM Tookit Get Information if <cmdType>=17 (SEND SS) if <cmdType>=18 (SEND USSD) if <cmdType>=19 (SEND SHORT MESSAGE) if <cmdType>=20 (SEND DTMF) if <cmdType>=32 (PLAY TONE) (not supported) if <cmdType>=40 (SET UP IDLE MODE TEXT) #STGI: <cmdType>[,<text>]...
Page 245 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #STGI - SIM Tookit Get Information bits 4 to 7: bit 8: 0 - No help information available 1 - Help information available <text> - String as prompt for text. if <cmdType>=35 (GET INPUT) #STGI: <cmdType>,<commandDetails>,<text>,<responseMin>,...
Page 246 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #STGI - SIM Tookit Get Information #STGI: <cmdType>,<commandDetails>,<numOfItems>[,<titleText>] <CR><LF> One line follows for every item, repeated for <numOfItems>: #STGI: <cmdType>,<itemId>,<itemText>[,<nextActionId>] where: <commandDetails> - unsigned Integer used as a bitfield 0..255 - used as a bit field:...
Page 247 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #STGI - SIM Tookit Get Information 0..255 - used as a bit field: bit 1: 0 - no selection preference 1 - selection using soft key preferred bit 2 to 7:...
Page 248 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #STGI - SIM Tookit Get Information The unsolicited notification sent to the user: #STN:237 is an indication that the main menu of the SIM Application has been removed from the TA, and it is no longer available. In this case AT#STGI=37 command response will be always ERROR.
Page 249 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #STSR - SIM Tookit Send Response Note: Use of icons is not supported. All icon related actions will respond with no icon available. AT#STSR? The read command can be used to request the currently ongoing proactive command and the SAT state in the format #STSR: <state>,<cmdType>...
Page 250 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SMSATRUNCFG – Set SMS AT Run Parameters Set command configures the SMS AT RUN service. AT#SMSATRUNCFG= <instance> [,<urcmod> Parameter: [,<timeout>]] <instance>: AT instance that will be used by the service to run the AT Command. Range 1- 3, default 3.
Page 251 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #SMSATWL – SMS AT Run White List AT#SMSATWL= Set command to handle the white list. <action> ,<index> <action >: 0 – Add an element to the WhiteList [,<entryType> 1 – Delete an element from the WhiteList [,<string>]]...
Page 252 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #TCPATRUNCFG – Set TCP AT Run Service Parameters Range 1..6. This parameter is mandatory. ,<tcpHost> [,<urcmod> [,<timeout> <instance > [,<authMode> AT instance that will be used by the service to run the AT Command. Default 2.
Page 253 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #TCPATRUNCFG – Set TCP AT Run Service Parameters Determines the authentication procedure in server mode: 0 – when connection is up, username and password (in this order and each of them followed by a Carriage Return) have to be sent to the module before the first AT command.
Page 254 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #TCPATRUNL – Enables TCP AT Run Service in listen (server) mode Note: the current settings are stored in NVM. Note: to start automatically the service when the module is powered-on, the automatic PDP context activation has to be set (see AT#SGACTCFG command).
Page 255 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #TCPATRUNFRWL – TCP AT Run Firewall List If criteria is matched, then the packet is accepted and the rule scan is finished; if criteria is not matched for any chain the packet is silently dropped.
Page 256 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #TCPATRUNAUTH – TCP AT Run Authentication Parameters List #TCPATRUNAUTH: <userid>,<passw> … Test command returns the allowed values for parameter <action>. AT#TCPATRUNAUTH= #TCPATRUND – Enable TCP AT Run Service in dial (client) mode Set command enables/disables the TCP AT RUN service in client mode.
Page 257 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #TCPATRUNCLOSE – Closes TCP Run AT Socket AT#TCPATRUNCLOSE=? Test command returns OK #TCPATCMDSEQ – For TCP Run AT Service, allows the user to give AT commands in sequence AT#TCPATCMDSEQ= Set command enable/dsable, for TCP Run AT service, a feature that allows <mod>...
Page 258 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #TCPATCONSER – Connects the TCP Run AT service to a serial port Note: To exit from online mode and close the connection, the escape sequence (+++) has to be sent on the TCP ATRUN instance. The escape sequence needs to be sent in one single packet.
Page 259 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #ENAEVMONI – Enable EvMoni Service Note: The current settings are stored in NVM. Read command returns the current settings of <mode> and the value of <stat> AT#ENAEVMONI? in the format: #ENAEVMONI: <mod>,<stat>...
Page 260 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #ENAEVMONICFG – Set EvMoni Service Parameters Note: EvMoni service and SMS Run AT service share the same channel. For the unified policy, when the #ENAEVMONICFG sets the <instance> parameter, the change is reflected also in the <instance> parameter of the #SMSATRUNCFG command, and viceversa.
Page 261 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #EVMONI – Set the single Event Monitoring <param> It can be a numeric or string value depending on the value of <paramType> and on the type of event. If <paramType> is 0, then <param> is a string containing the AT command: •...
Page 262 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #EVMONI – Set the single Event Monitoring seconds after that the selected GPIO pin in the status specified with <paramType> = 1 causes the event. The range is 0 – 255.
Page 263 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #CMGS - Send Message octets). 7..164 <pdu> - PDU in hexadecimal format (each octet of the PDU is given as two IRA character long hexadecimal number) and given in one line.
Page 264 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #CMGS - Send Message where <mr> - message reference number; 3GPP TS 23.040 TP-Message-Reference in integer format. Note: if message sending fails for some reason, an error code is reported. Test command resturns the OK result code.
Page 265 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #CMGW - Write Message To Memory User-Data-Header-Indication is not set, then ME/TA converts the entered text into GSM alphabet, according to GSM 27.005, Annex A. - if current <dcs> (see +CSMP) indicates that 8-bit or UCS2 data coding scheme is used or current <fo>...
Page 266 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #GMMPSMSEN – GMMP SMS Enable Example AT#GMMPSMSEN=? #GMMPSMSEN: (0,1) AT#GMMPSMSEN? #GMMPSMSEN: 1 // Receive GMMP Control message with 8bit data coding scheme from server #GMMPSMSIND: 1,HmdFTwEAAAAAAAAAAAAAAAAAAAAAAA== // Receive GMMP Control message with UCS2 data coding scheme from server...
Page 267 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #GMMPTCPOPEN – GMMP TCP Connection send data issuing #GMMPSEND Test command reports the range of values for all the parameters. AT#GMMPTCPOPE Open TCP connection for GMMP Example AT#GMMPTCPOPEN=1,”111.111.111.111”,5001 #GMMPTCPCLOSE – GMMP TCP Disconnection AT#GMMPTCPCLO Execution command close GMMP TCP socket.
Page 268 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #GMMPRECV – Receive GMMP Data AT#GMMPRECV= Execution command permits the user to read data arrived through a <connId> connected socket. the module is notified of arriving data by a SRING URC Parameters: <connId>...
Page 269 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 #CPBU - Read Phonebook Information for USIM Read command reports phonebook USIM info in the form: AT#CPBU? #CPBU: <index0>,(<temail>,<uemail>),(<tanr>,<uanr>),(<tsne>,<usne>),(<tgrp>,<ug rp>) #CPBU: <indexn>,(<temail>,<uemail>),(<tanr>,<uanr>),(<tsne>,<usne>),(<tgrp>,<ug rp>) where: <indexn> - the index of adnn, integer type <temail>- total record number of emailn, integer type...
Page 270 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 The following AT Command list can be aborted, while executing the AT Command +CLCK +COPN +CPOL +COPS(Accept only test command) NOTE: If DTE transmit any character before receiving the response to the issued AT Command, this make current AT Command to be aborted.
Page 271 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 List of acronyms ARFCN Absolute Radio Frequency Channel Number Attention command BCCH Allocation BCCH Broadcast Control Channel Cell Allocation Cell Broadcast Message Cell Broadcast Service Current Call Meter CLIR Calling Line Identification Restriction...
Page 272 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 SMSC Short Message Service Center Simple Mail Transport Protocol SMTP Terminal Adapter Transmission Control Protocol Terminal Equipment User Datagram Protocol USSD Unstructured Supplementary Service Data Coordinated Universal Time VDOP Vertical dilution of precision Course over ground and ground speed Reproduction forbidden without Telit Communications S.p.A.
Page 273 LE910-SKG AT commands reference guide 80437ST10619A Rev.1 – 2014-09-16 Document History Revision Date Changes 2014-09-16 Initial release Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 273 of 273...
