No compromises are made in the product’s quality at any stage of the design or production process. We wish you many happy years of use from your Binatone product. Áëàãîäàðèì Âàñ çà ïîêóïêó òåëåôîíà òîðãîâîé ìàðêè Binatone. Âñÿ òåõíèêà Binatone èçãîòîâëåíà â ñîîòâåòñòâèè ñ åâðîïåéñêèìè...
Special Safety Measures ... 6 TELEPHONE DESCRIPTION ... 7 LCD icons ... 7 INSTALLING AND CONNECTING ... 9 Switching the telephone on and off ... 9 Setting Tone or Pulse dialing mode ... 10 Making a call ... 10 Language selection ... 10 New handset registration ...
Page 5
Conference call ... 23 Call information ... 23 Call duration ... 25 Resetting the timers ... 25 Making calls from the lists ... 25 Service menu ... 26 Keypad lock ... 28 Handset locator ... 28 Clock ... 29 Monitoring ... 29 Radio set mode ...
DECT Aquarel XDC1520 SAFETY MEASURES When using the phone you must comply with the following safety rules: Do not clean the phone with chemical solvents, abrasive materials, or spray cleaners – as they can penetrate inside the device making damage not covered by the warranty.
Talk or Flash button – used for answering or transfering a call. Off button – used for ending the call and for switching the telephone off. 8. Dialing buttons. 9. INT button – used for making internal calls.
Switching the telephone on and off To switch the telephone off: press and hold the button [7] in the standby mode for no less than 2 seconds. To switch the telephone on: press the button [7]. If the battery is discharged, the...
Setting Tone or Pulse dialing mode Your telephone can operate in the pulse or tone modes. Selection of the mode depends on the automatic exchange type. Usually digital automatic exchanges use the Tone mode, while analog automatic exchanges use the Pulse mode. If you set the Tone mode when operating with an analog automatic exchange, then your telephone will be able to receive calls, but unable to dial a number.
Page 11
On the handset: 1. With the telephone in the standby mode press the MENU button [3]. 2. By pressing the button [5] select the SYSTEM menu item, then press OK [3]. 3. By pressing the button [5] select the REGISTRATION menu item, then press OK [3].
MENU STRUCTURE MAIN MENU Display Detailed Clock Answering machine Time format. Pulse-Tone Handset Name Language Pause duration Screen Savers Prefix Color Call barring Sounds Handset melody System Base melody Registration Button beep Base selection Service Signals Remote Handset PIN-code change Additional To reset Functions...
1. Dial the required number by pressing the buttons [8]. 2. Press the Save button [3]. Note: If the telephone’s memory is full, then the LCD screen [2] will display an appropriate warning and the telephone will be transferred to the...
Note: The melody selection function can be used if your network supports the Caller ID function. 6. Press the Save button [3]. The telephone will return to the standby mode. Quick dial With the telephone in the standby mode, press and hold the button which corresponds to the required number.
3. Press the Talk button [6]. Ringer off 1. When the telephone rings, press the Mute button [4]. 2. With the telephone in the standby mode, press and hold the The LCD display [2] will show the sign Press and hold the [8] button once again to unlock it.
The length of each entry should not exceed 10 symbols and 20 digits. Storing a number into the phone book 1. With the telephone in the standby mode, press the Phone Book button [4]. 2. By pressing the button [5], select the required list. You may choose between the Protected or General list.
ID function. 10.Press the Save button [3]. Viewing the stored numbers 1. With the telephone in the standby mode, press the Tel Book button [4]. 2. By pressing the button [5], select the required list. You may choose from the Protected or General list.
You may copy stored telephone numbers from the protected list into the general list and vice versa. 1. With the telephone in the standby mode, press the Phone Book button [4]. 2. By pressing the button [5], select the required list. You may choose between the Protected and the General list.
You may use key buttons as quick dial buttons (1- 9) [8]. Functions of quick dialing buttons 1. With the telephone in the standby mode, press the Phone Book button [4]. 2. By pressing the button [5], select the PROTECTED LIST.
Deleting entries from the phone book 1. With the telephone in the standby mode, press the Phone Book button [4]. 2. By pressing the button [5], select the required list. You may choose between the protected and the general list.
Also you can look at the phone book list in the course of the conversation. Direct calls from the phone book 1. With the telephone in the standby mode, press the Phone Book button [4]. 2. By pressing the button [5], select the required list. You may choose between the protected and the general list.
To make an internal call you need to have, two registered handsets. Internal call 1. With the telephone in the standby mode, press the INT button [9]. 2. By pressing the button [5], select the number of the handset you intend to call.
Caller ID function) received and unanswered calls. Review of information about calls 1. With the telephone in the standby mode , press the CALLS button [11]. 2. By pressing the button [5], select the UNANSWERED, DIALED or RECEIVED menu item, then press OK [3].
Page 24
If in any list you find a number not recorded in the phone book, you may transfer that number into the phone book. 1. With the telephone in the standby mode, press the CALLS button [11]. 2. By pressing the button [5], select the UNANSWERED, DIALED or RECEIVED menu item, then press OK [3].
1. With the telephone in the standby mode, press the CALLS button [11]. 2. By pressing the button [5], select the DELETE menu item, then press OK [3]. 3. By pressing the button [5], select the VMWI menu item, then press OK [3].
The length of each entry shall not exceed 10 symbols and 20 figures. To enter a number into the service menu 1. With the telephone in the standby mode, press the SER button [10]. 2. By pressing the button [5], select the NEW ENTRY menu item, then press OK [3].
Page 27
[5], you may view the entries. To change entries in the service menu 1. With the telephone in the standby mode, press the SER button [10]. 2. By pressing the button [5], select the VIEW menu item, then press OK [3].
This function allows you to check on the amount of service menu memory in use. 1. With the telephone in the standby mode, press the SER button [10]. 2. By pressing the button [5], select the MEMORY STATUS menu item, then press OK [3].
Clock To set the time on the clock 1. With the telephone in the standby mode, press the MENU button [3]. 2. By pressing the button [5], select the ADDITIONAL FUNCTION menu item, after that press OK [3].
Leave the handset in the room you intend to monitor. Handset 2 1. With the telephone in the standby mode, press the INT button [10]. 2. By pressing the button [5], select the number of the handset with the monitoring mode switched on.
Calling other handsets under the radio set mode 1. With the telephone in the standby mode, press the RADIO SET button [3]. 2. By pressing the button [5], select the number of the handset you intend to call and wait for the answer.
LCD display [2] will indicate the incoming caller’s num- ber. If due to any reason the telephone failed to identify the number, then the LCD display [2] will indicate Undetermined. If the incoming caller sets the number with- held function, then the LCD display [2] will indicate Hidden.
8. Press OK [3] to confirm. Selecting clock format 1. With the telephone in the standby mode, press the MENU button [3]. 2. By pressing the button [5], select the DISPLAY menu item, then press OK [3]. 3. By pressing the button [5], select the CLOCK FORMAT menu item, then press OK [3].
Background color You may choose one of the three LCD screen colors. 1. With the telephone in the standby mode, press the MENU button [3]. 2. By pressing the button [5], select the DISPLAY menu item, then press OK [3].
Service signals 1. With the telephone in the standby mode, press the MENU button [3]. 2. By pressing the button [5], select the SOUNDS menu item, then press OK [3]. 3. By pressing the button [5], select the SERVICE SIGNALS menu item, then press OK [3].
[5]. By pressing the key buttons [8], enter the telephone number or part of the number. Note: If you enter the full telephone number, the prefix will be dialed only to precede that number. If you enter part of the number, for example, two figures, the prefix will be dialed to precede every number which starts with the figures entered by you.
Preliminary dialing for PBX This function is useful if your telephone is connected to a PBX. In this case, when placing a call to an automatic exchange, it will be necessary to dial a preliminary number. This function does that automatically.
10.Press OK [3] to confirm. Base unit selection Your telephone may be registered in four base units. If the handset is registered in more than one base unit, you may select the base unit you intend to use at a particular moment.
The factory setting is 0000. You may set any code of four figures at your discretion. 1. With the telephone in the standby mode, press the MENU button [3]. 2. By pressing the button [5], select the SYSTEM menu item, then press OK [3].
USEFUL INFORMATION Always check before usage whether the phone wire is connected to a phone network and the main unit; whether the rechargeable battery is inserted into the handset. I can not call – Check whether the power supply adapter is connected to power network –...
Features may be changed by Binatone without any notice. Warranty details are set out in the warranty card provided with the product. Exploitation period: 3 years after the day of purchase. Manufacture: Binatone Industries Ltd, Great Britain, Wembley, 1 Beresford Av- enue, Vitabiotics House...
