Ver 3, Jan 2008(CANADA)
USER GUIDE
iDECT X3i System
Colour Display Telephone with
200 Name and Number Phonebook
and Answering Machine
THIS EQUIPMENT IS NOT DESIGNED FOR MAKING
EMERGENCY TELEPHONE CALLS WHEN THE POWER
FAILS. ALTERNATIVE ARRANGEMENTS SHOULD BE
MADE FOR ACCESS TO DIAL EMERGENCY SERVICES.
Before operating this set,
please read these instructions carefully.
Advertisement
Table of Contents
Related Manuals for Binatone iDECT X3i
Summary of Contents for Binatone iDECT X3i
- Page 1 USER GUIDE iDECT X3i System Colour Display Telephone with 200 Name and Number Phonebook and Answering Machine THIS EQUIPMENT IS NOT DESIGNED FOR MAKING EMERGENCY TELEPHONE CALLS WHEN THE POWER FAILS. ALTERNATIVE ARRANGEMENTS SHOULD BE MADE FOR ACCESS TO DIAL EMERGENCY SERVICES.
- Page 2 IMPORTANTES MESURES DE SÉCURITÉ Certaines mesures de sécurité doivent être prises pendant l’utilisation de matérial téléphonique afin de réduire les risques d’incendie, de choc électrique et de blessures. En voici quelquesunes: Ne pas utiliser l’appareil près de l’eau, p.ex., près d’une baignoire, d’un lavabo, d’un évier de cuisine, d’un bac à...
- Page 3 IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
- Page 4 Equipment Approval Information This equipment is approved for connection to the Public Switched Telephone Network and complies with Part 15 and 68 of the FCC rules and the requirements adopted by the ACTA. Notification to Local Telephone Company On the bottom of this equipment is a label that contains, among other information, BINW409BIDECTX3I and Ringer Equivalence Number (REN) for the equipment.
- Page 5 • Connection to a party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information. • AC electrical surges, typically resulting from lightning strikes, are very destructive to the telephone equipment connected to AC power sources.
- Page 6 Privacy of communications may not be ensured when using this phone. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...
- Page 7 Industry Canada Approval information This product meets the applicable Industry Canada technical specifications. The Ringer Equivalence Number is an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed five.
- Page 8 Important note - emergency calls This telephone is not designed for making Emergency calls when the mains power fails. For Emergency calls you should have a basic phone that does not need mains power, connected to your line so that you can make calls during a power failure. Charging batteries for the first time Before you start to use your telephone make sure that all batteries are fully charged for 24 hours.
- Page 9 Where to find it Colour Display with backlight EARPIECE Left Soft/ Menu Right Soft/ Access button Phonebook button Press to access menu. Press to access phonebook menu. Press for OK. Press for BACK / CLEAR. HANG UP/ C button Navigation buttons and power ON/OFF : access dialled calls.
- Page 10 This shows the handset name. BINATONE 1 Display in standby mode. If activated the following icons and text are shown - Alarm active Current time...
-
Page 11: What The Symbols Mean
To navigate within the menu options in the iDECT X3i, simply press UP/ or DOWN/ key until you reach your selected option; then press the left soft key confirm the selected option. -
Page 12: Table Of Contents
Contents What the symbols mean To store a last number redial entry in phonebook Contents Dialling from phonebook Caller ID log Read First before Use Handset ringer volume, melody Choosing a site for the base unit Using a multi-handset system and charger pod Paging handset Radio signals between handset... -
Page 13: Read First Before Use
Troubleshooting Guarantee and Service Cleaning and Care Technical Details Declaration of Conformity Read First Before Use Choosing a site The base unit and charger pod(s) should be placed on a level surface, in a position where: for the base unit and charger pod the mains adapter plug will reach an easily accessible 120-VAC switched mains supply socket - never try to lengthen the... -
Page 14: Connection And Conditions For Use
Connection You can connect your iDECT X3i to a direct exchange line (DEL) — a line connected to a local exchange, with its own phone and conditions number; to an extension socket connected to a DEL; or to an for use extension on an approved compatible PBX. -
Page 15: Installation And Set-Up
Use the telephone line cord RJ11C supplied with your iDECT X3i - other line cords may not work with this phone. Plug the mains adaptor into your wall socket. If you have one or more charger pods, plug in the mains adaptors accordingly. -
Page 16: Fit The Rechargeable Batteries In Each Handset
Fit the rechargeable batteries in each handset. A. Push down on the top of the battery B. Lift the battery pack and connect compartment cover (located on the its plug to the socket inside the back of the handset) and slide the compartment, as shown. - Page 17 Use Sanik 2SN-3/5 F60H-H-JP2 NiMH 600mAh 2.4v rechargeable battery and charge them only on the original base station or charger pod(s). Insert the batteries properly as previously described. Do not dispose of the batteries in fire: this may cause an explosion. Remove the batteries from its compartment if the phone is not used for a long period of time.
-
Page 18: Your Telephone Operations
Your Telephone Operations Switching on/off Press the HANG UP/ C button to turn the phone 'ON'. Press the HANG UP/C button and hold for two seconds to turn the phone 'OFF'. ** You can switch the handset off and save battery. ** When the handset is in "off"... -
Page 19: Set The Alarm
Press the OK button. à The display shows Time (24 Hr):. Use the digit keys to enter the time 0 to 9 - format HH:MM (It's a 24 hour clock). Press the button to confirm. à The display shows Time & Date Saved. Press the HANG UP/C button to return to idle mode. -
Page 20: Your Handset's Name (Change The Name)
Set Alarm tone Press the menu button. à The display shows Calls lists. à Use the UP/ or DOWN/ to select Time setting. Press the button. à à The display shows Time setting >Alarm. Press the button to select Alarm. Use the UP/ or DOWN/ to select Set Alarm Tone. -
Page 21: Select Your Handset Display Language
Select your handset display language Press the menu button. à The display shows Calls lists. Use the UP/ or DOWN/ to select Handset. Press the button. à The display shows Handset >Ringtone. Use the UP/ or DOWN/ to select Language. Press the button, then press the UP/ or DOWN/... -
Page 22: Select Your Handset Wallpaper
Select your handset Wallpaper Press the menu button. à The display shows Calls lists. Use the UP/ or DOWN/ to select Handset. Press the button. à The display shows Handset >Ringtone. Use the UP/ or DOWN/ to select Wallpaper. Press the button, then press the UP/ or DOWN/ button to go through...
