Xc-eu50ce - Sony XC-EU50 Technical Manual

Sony corporation ccd black-and-white video camera module xc-eu50/eu50ce.
Hide thumbs

Advertisement

XC-EU50CE

Horizontal Output Waveform Timing Chart
HD
98
(6.91 µs)
40
CCD
output
signal
70.5 ns
Camera video
output signal
(Typical value)
21
(1.48 µs)
91
22
3
Dummy
Optical black
bits
portion
Horizontal transfer stop period
Optical black portion
Horizontal blanking period (12.1 µs)
81 (5.71 µs)
HSYNC
70
(4.93 µs)
One horizontal scanning period (1 H) 908 (64.0 µs)
15
Effective total pixels 752
Output video period
736 (51.9 µs)
* Values without units indicate the clock counts.
Appendix
736
25
