This manual describes how you can use ControlLogix® EtherNet/IP™
communication modules with a Logix 5000™ controller and communicate with
various devices on the Ethernet/IP network.
Use this manual if you program applications that use EtherNet/IP networks
with these Logix 5000 controllers:
• CompactLogix™ controller
• ControlLogix controller
Be sure to understand these concepts and tools:
• FactoryTalk® Linx
• Logix Designer
• ControlFLASH Plus™
• HMIs
• SNMP tools
These documents contain additional information concerning related products
from Rockwell Automation.
Resource
1756 ControlLogix Communication Modules Specifications,
publication 1756-TD003
Ethernet Design Considerations Reference Manual,
publication ENET-RM002
EtherNet/IP Network Devices User Manual,
publication ENET-UM006
EtherNet/IP Modules Installation Instructions,
publication ENET-IN002
EtherNet/IP Media Planning and Installation Manual
This manual is available from the Open DeviceNet® Vendor
Association (ODVA) at: http://www.odva.org.
EtherNet/IP Embedded Switch Technology Application
Guide, publication ENET-AP005
EtherNet/IP Device Level Ring Application Technique,
publication ENET-AT007
Rockwell Automation Publication 1756-UM004A-EN-P - March 2019
Description
Specifications for ControlLogix communication
modules.
Provides details about how to use EtherNet/IP
communication modules with Logix 5000 controllers
and communicate with other devices on the
EtherNet/IP network.
Describes how to install, configure, and operate the
Compact 5000™ I/O EtherNet/IP adapters.
Provides information about how to complete these
tasks with EtherNet/IP communication modules in a
Logix 5000 control system:
• Install the module
• Configure initial application setup
• Troubleshoot application anomalies that are
related to EtherNet/IP communication module use
Provides details about how to install, configure, and
maintain linear and Device Level Ring (DLR) networks
by using Rockwell Automation EtherNet/IP devices
that are equipped with embedded switch technology.
Provides details about how to install, configure, and
maintain linear and Device Level Ring (DLR) networks
by using Rockwell Automation EtherNet/IP devices
that are equipped with embedded switch technology.
Describes DLR network operation, topologies,
configuration considerations, and diagnostic
methods.
