Status Indicators

ControlLogix Network Device Status Indicators
Topic
Status Indicators
Single-Port Module Status Indicators
Dual-Port Module Status Indicators
The following graphics show the status indicators for these modules (extended-
temperature versions not shown).
Figure 2 - 1756-EN2F, 1756-EN2T (Single-port Modules)
EtherNet/IP
TM
10/100 BASE T
LINK NET OK
Link Status
Indicator (LINK)
Figure 3 - 1756-EN2TR, 1756-EN3TR (Dual-port Modules)
Link Status
Indicators (LINK)
Rockwell Automation Publication 1756-UM004A-EN-P - March 2019
Page
21
24
25
Module Status Display
OK Status Indicator
LINK NET OK
Network Status Indicator (NET)
Module Status Display
OK Status Indicator
Network Status Indicator (NET)
