- Page 1 Southbay Hex Easy Up Gazebo Instruction Manual Item #: L-GZ793PST-A SKU #: 810213584...
- Page 2 IMPORTANT: Please read and follow all safety statements, warnings, assembly instructions, use & care directions before attempting to assemble. WARNING: 1. When installing and assembling your gazebo, it is recommended that 2 or more adults are involved. 2. This product is intended for outdoor use only and should be placed on flat, horizontal ground.
- Page 3 Parts List Post Horizontal screen Arch beam Middle beam Big top frame Small top arch beam Small top connector Hook Knob Small canopy Big canopy Mosquito netting Netting tube...
- Page 4 Fig.1: Attach horizontal Fig.1-1: Attach netting screen (B) to post (A) by tube (M) to horizontal knob (I) screen (B) by knob (I).
- Page 5 Fig.4: Insert upper side of Fig.3: Insert connector of Fig.2: Insert connecting piece arch beam into arch beam (C) into post (A). of big top frame (E) into connector of big top frame pentagon tube, then locked (E). wirth knob (I). Fig.7: Insert hook (H) into Fig.5: Insert upper side of Fig.6: Insert connector of...
- Page 6 Hardware Pack Stake 18 PCS Ring 48 PCS Fig.9: Put on small Fig.10: Spread out big Fig.10-1: Stick Fig.11: Attach mosquito canopy (J), attach canopy (K), attach corners netting small netting (L) to netting tube corners to small top to arch beam and middle canopy (J) to big (M) by ring (BB).
- Page 7 3. Warranty does not cover damage due to extreme weather conditions. CUSTOMER SERVICE Sunjoy Industries warrants to the original purchaser that this item is free from defects in workmanship and materials of your item provided the item was factory-sealed at the time of purchase and is maintained with care and used only for personal, residential purposes.
