Table of contents Symbols used in this manual ........................2 General safety ............................2 Product Unit label ..........................4 General requirements ..........................5 3.1 Product information..........................5 3.2 Product description ..........................5 3.3 Intended use ............................5 3.4 Intended operator ............................ 6 3.5 Essential Performance..........................
1. Symbols used in this manual Warning Symbol Indication of potentially hazardous situation. If not avoided, it can result in serious injury or death. Caution Symbol Indication of potentially hazardous situation which may result in minor or moderate injury. It may also be used to alert against unsafe practices. Notification Symbol This symbol is used to notify correct use and handling of the product.
Page 4
The information in this manual is based on correct installation in accordance with installation instructions for this product. Ropox cannot be held liable if the product is used in any way that differs from stated in this manual and/or installation instruction.
Product Unit label Ropox SlimLine Washbasin Complete Electric, 60cm support, 67cm unit This product is UKCA-marked in accordance with: UK SI 2002 No. 618 - The Medical Devices Regulations 2002, and its amendments UK SI 2008 No. 1597 - The Supply of Machinery (Safety) Regulations 2008, and its...
Consult manual before use 3. General requirements 3.1 Product information Manufacturer Ropox A/S Ringstedgade 221, DK-4700 Naestved +45 55 75 05 00 Email: Info@ropox.com Product models Part number Model Configuration 40-15601 SlimLine Complete Straight Support Washbasin Expected service life 5 years...
3.4 Intended operator Reading and understanding this manual will be sufficient training for an intended operator. Children under the age of 16 or patient are not considered intended operator. 3.5 Essential Performance The product does not have essential performance, as the patient and user do not experience any risk in case of loss of product function/performance.
4. Instructions for use 4.1 Operating the product Ropox SlimLine is adjusted in height by using either the fixed control, or the hand control with spiral cable (accessory). This ensures an optimal height for washing your hands, aiding users and carers alike.
4.2 Installation interfaces Construction The wall must be made of a material suited for screw mounting and approved for damp rooms. The hatched area is the minimum area for reinforcement of the wall. Tested in accordance with DS/EN 12182:2012 and DS/ISO 17966:2016 with the following max.
4.3 Connection adapters If the recommendations cannot be met, the components described below may be ordered. Ropox is not responsible for the optimal functionality of the below components under covers when adjusting the height of the unit. Water connection adapters...
4.4 Installation of product Warning! The product should always be able to travel the full range of actuation without colliding with objects. Failing to do so will compromise the product stability. Warning! The fitter should always consider the material, condition and strength of the wall and use screws and rawlplugs suitable for the specific wall type.
Page 13
97002674 Fixed control 97002672 Control box 97002679 Power supply 97002680 AC cable 2m 97001706 Oras Saga 3910F 40-15612-0 Plumbing kit SlimLine Incl. 97001601 Prevex siphon 97001162 Flexible drain hose Ø32/32 pipe 97001035 32x88,5° white PP Wafix elbow HT 97001126 Connection hose 700mm, Lindner 97001605 Prevex 100mm extension 95091070...
4.4.2 Installation of product The maximum tensile load of the screws is 68 kg. The wall must be able to resist such tensile load. Fix the mounting bracket as illustrated on the drawing with the right distance to water and drain. Make sure that the mounting bracket is level.
Page 15
Centerhole for mountingbraket Place the unit in accordance with the water connection and drain as shown on the drawing. Push 8 spacers in behind the frame so that it has the right distance to the wall. Mark the 8 holes for fastening. Take the lifting unit down again and drill the holes in the wall. TF 200.01.0028_eng...
Page 16
Use suitable rawlplugs and screws for the mounting. Remove the protective foil on the tape and fasten the power supply above the unit. Locate 1.5 m above the floor measured on the underside. Place it in the middle of the lifting unit. TF 200.01.0028_eng...
Page 17
Mount the control box on the mounting bracket. Make sure that the small aluminium leg interlocks and locks the box in a fixed position. TF 200.01.0028_eng...
Page 18
Connect the electrical system as illustrated. Fix the excess cable from the power supply on the mounting bracket with strips. Check that the unit freely moves at up/down. If needed, use cable clips etc. for the power cable. Fix the rods for the mirror bracket in the frame with M5 countersunk screws. TF 200.01.0028_eng...
Page 19
Install the siphon. Adjust the holder bracket to 20mm. Mount the flat cover and 3 (three) mirror brackets so it is kept in. TF 200.01.0028_eng...
Page 20
Now mount the washbasin with the enclosed mounting parts for bolt mounted washbasins. Caution! When mounting a porcelain washbasin, an insolation foam pad MUST be placed between the washbasin and the unit. It is recommended to grout around the washbasin. Remove the protective foil from the double-coated tape on the back of the brackets for the installation cover.
Page 21
Remove the installation cover and push the brackets very firmly against the wall to make sure that the glue has good contact with the wall. The power connection is positioned in a radius of up to 1500mm Install water connection and drain hoses as illustrated. Put the installation cover back on. Make sure that all hoses move freely and unhindered.
Page 22
Put the outermost cover on as illustrated. Install the rest of the drain and screw it in the washbasin. Now check that the washbasin and hoses below the caps move freely by moving the lifting unit up and down. Remove the protective foil on the double-coated tape on the back of the mirror and fix it as illustrated. Press it firmly and make sure that the mirror is properly fastened so that the final mirror bracket can be mounted.
Make sure the frame and washbasin doesn’t collide with anything during travel. Do a full travel of the frame to ensure proper function, and check for colliding objects. Afterwards, the Ropox SlimLine can be put into use. Before the first use, read section 6 Safety in Use. 4.5 Cable diagrams Standard product with fixed control.
➢ If the SlimLine washbasin has not been installed in accordance with these mounting instructions, the warranty may be void. ➢ Only use original Ropox spare parts as replacements parts. If other parts are used, the warranty may be void.
7. Cleaning Ropox SlimLine may be wiped with a wrung cloth with lukewarm water and a mild detergent. Do not use corrosive/grinding fluids or scouring sponges. Note! Do not use cleaning agents containing abrasive e.g. scouring powder, steel wool, scouring sponge.
8.2 Service schedule Service and maintenance Serial no. Service and maintenance Serial no. Date: Date: Signature: Signature: Remarks: Remarks: Service and maintenance Serial no. Service and maintenance Serial no. Date: Date: Signature: Signature: Remarks: Remarks: Service and maintenance Serial no. Service and maintenance Serial no.
9. Spare parts list Note! Ropox will make parts list available for extraordinary maintenance and repair beyond what is described in this manual. Repair beyond what is described in this manual may only be done by Ropox designated service personnel.
10. Environmental protection The product is not intended to be disposed as municipal waste. Proper disassembly, sorting and disposal of components must be done by waste disposal professionals. Part Disposal recommendation Wash basin Ceramic Main unit Steel Faucet Steel Cover Plastic Actuator Electronic...
