- Page 1 Operation Manual PAM-MPM4A CD/USB/TUNER MODULE * 본 제품을 사용하기 전에 반드시 방송방식 및 전원 전압을 확인하여 사용하시기 바랍니다.
- Page 2 Warning CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING To prevent fire or shock hazard, do not expose the unit to rain or moisture. This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage”...
-
Page 3: Table Of Contents
Contents Welcome ................4 Unpacking ................4 Installation Environment.................5 Important Safety Instructions ..........5 Additional Explanation ............7 Method to treat Compact Disc (CD)........8 Features ................9 Contents and Accessories ..........9 Part Names and Function ..........10 Method to Use CD/USB............ 12 Method to Use FM Tuner ..........15 Block Diagram..............16 Specification..............17 Service... -
Page 4: Welcome
Welcome A personal welcome to you from the management and employees of Inter-M All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products. -
Page 5: Installation
11. Only use attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the ap- paratus. When a cart is used, use caution when moving the cart/ap- S3125A PAM-MPM4A (CD/USB/Tuner Module) - Page 6 - DO NOT OPEN THE CASE OR ATTEMPT REPAIRS OR MODIFICATIONS YOURSELF This product contains no user-serviceable parts. Refer all maintenance to qualified Inter-M service personnel. Opening the case and/or tampering with internal cir- cuitry voids the warranty. - ALWAYS POWER OFF BEFORE MAKING CONNECTIONS Always turn the AC mains OFF before connecting or disconnecting cables.
-
Page 7: Additional Explanation
The device of the party which re- ceived optical signals converts optical signals to electrical signals for various treatments. Direct transmission of digital data has advantage that there is less data error as it is not affected by electrical noise than electrical signals. PAM-MPM4A (CD/USB/Tuner Module) -
Page 8: Method To Treat Compact Disc (Cd)
■ ■ ■ Leaving it for a place where temperature is high may cause deformation, etc. Do not paste papers, etc to the character surface or write let- ters on it. ■ ■ ■ PAM-MPM4A (CD/USB/Tuner Module) -
Page 9: Features
This device responds to both CD-DA and MP3/WMA/WAV. ■ ■ ■ Contents and Accessories 1. PAM-MPM4A x 1EA 2. FM TUNER Antenna x 1EA 3. Screws for PAM-Series x 4EA 4. Power and Audio Cable x 1EA 5. Operation Manual x 1EA... -
Page 10: Part Names And Function
1. Insert the CD with the label side facing up. 2. Never insert a 8cm CD into the slot. 5. GROUP/MEMORY BUTTON 1) Use this button to move between folders when files exist under various folders for MP3/WMA/WAV from CD/USB operation. PAM-MPM4A (CD/USB/Tuner Module) - Page 11 This is a terminal to connect with FM antenna. 12. VOLUME BUTTON This button is function to tune volume. 13. TUNING BUTTON This function is used to decrease channel frequency from TUNER. 14. EJECT BUTTON This button is used when taking out a CD. PAM-MPM4A (CD/USB/Tuner Module)
-
Page 12: Method To Use Cd/Usb
2. When you insert a CD of a different format, NO FILES ap- pears in the OLED DISPLAY. 3. When the CD is inserted upside down, CD READ ERR is displayed on the OLED DISPLAY. 2) Method to use USB (1) Insert USB memory. PAM-MPM4A (CD/USB/Tuner Module) - Page 13 (CD / USB). 3) REPEAT ALL: Repetitively play the whole sector of CD/USB. 3. EJECT 1) This function is used to take out CD. 2) CD comes out if pressing this button irrespective of operation status of operation. PAM-MPM4A (CD/USB/Tuner Module)
- Page 14 1) Never insert an 8cm CD into the CD slot. 2) If CD READ ERR or USB ERR is continuously displayed on the OLED DISPLAY, please contact our A/S center. 3) USB memory is supported up to 32GB. PAM-MPM4A (CD/USB/Tuner Module)
-
Page 15: Method To Use Fm Tuner
4) No. 1 through No. 40 frequencies can be saved. 5) Memorized broadcasting frequency can select the desired broadcasting frequency using the PRESET button. PAM-MPM4A (CD/USB/Tuner Module) -
Page 16: Block Diagram
Block Diagram PAM-MPM4A (CD/USB/Tuner Module) -
Page 17: Specification
-10˚C ~ +40˚C Power Source DC 24V Weight(Set) 0.88kg/1.94lb 184(W) x 55(H) x 182(D)mm/ Dimensions(Set) 7.24(W) x 2.16(H) x 7.16(D)in * Design and specification are subject to be changed for the improvement of product quality without pre notice. PAM-MPM4A (CD/USB/Tuner Module) -
Page 18: Service
To obtain specific warranty information and available serv- ice locations contact Inter-M directly or the authorized Inter- M Distributor for your specific country or region. PAM-MPM4A (CD/USB/Tuner Module) - Page 19 NOTE...
- Page 20 NOTE...
- Page 21 NOTE...
- Page 22 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
