Summary of Contents for Inter-m NTU-100
- Page 1 (Program Installation) Operation anual etwork Tuner TU-100...
-
Page 2: Table Of Contents
NETWORK TUNER Contents Contents Ⅰ. Initial Web network setup......................1 Webpage Setting ..........................1 Ⅱ. Main Menu Screen ........................2 Ⅱ. 1 Network Setup .........................3 Ⅱ. 2 Operation Mode Setup ......................4 Ⅱ. 3 MP3 Time Signal Setup (MP3 Reserve Broadcast Settings)............5 Ⅱ. 3-1 MP3 scheduled table view - View table................6 Ⅱ. -
Page 3: Webpage Setting
NTU-100. ③ HOW TO SET UP a. Connect the NTU-100 to a network and browser enabled device using a straight or cross network cable. b. You can also connect via a network router or switch. c. Set the network configuration of the NTU-100 and the network device. -
Page 4: Ⅱ. Main Menu Screen
NETWORK TUNER d. From the network device browser (Internet Explorer, Chrome, etc) enter the IP address of the NTU-100 in address bar of the internet browser. Problems connecting? ① Make sure the cable is in good working order. ② Make sure that you are able to “ping” the NTU-100 from the network device. -
Page 5: Ⅱ. 1 Network Setup
③ Displays the IP information as applied to the device and the user can modify the IP information. ④ Click [ pply] button to apply the modified setting. Click [Reset] button to reset to the previous data setting. ⑤ Displays Help & Tips on Network setup. NTU-100... -
Page 6: Ⅱ. 2 Operation Mode Setup
Internet Radio related functions cannot be used. Internet Radio Internet Radio Play/Stop and dd/Delete, and pre-program are capable based on Internet Radio. MP3 file related features are not available. ① selects the mode of the current equipment. ② Displays Help&Tips on operation mode setup. NTU-100... -
Page 7: Ⅱ. 3 Mp3 Time Signal Setup (Mp3 Reserve Broadcast Settings)
④ Can add, delete or modify the information. ⑤ Set Holiday settings or delete the information. ⑥ Manage the MP3 source files for use in reserved broadcast. ⑦ Displays Help & Tips on MP3 Time signal setup (MP3 Reserved Broadcast Settings). NTU-100... -
Page 8: Ⅱ. 3-1 Mp3 Scheduled Table View - View Table
② File : Select a internet radio station play. ③ Time : Playing time. ④ Current Time : Current NTU-100 internal time is displayed. ⑤ Specified Time : The selected station will play for the interval set from ‘start time’ will repeat until the ’end time’. -
Page 9: Ⅱ. 3-3 Mp3 Reserved Setting - Delete
Press to delete a schedule and the following screen will appear ① Delete : Delete the selected schedule. ② Select all : Select or clear the entire list. Ⅱ. 3-4 MP3 reserved setting - Modify fter modify the schedule, press the pply button NTU-100... -
Page 10: Ⅱ. 3-5 Mp3 Source File Management - Setup
① The titles of the MP3 files that are stored in the device are shown. ② From the ① list, select to delete, preview and stop preview. ③ Show the available file upload space. ④ Select any file to upload to the device. NTU-100... -
Page 11: Ⅱ. 3-6 Mp3 Holiday - Setup
Press the save button to save the holiday setup. ⑤ holiday can be set up to 30 events. Ⅱ. 3-7 MP3 holiday - Delete ① Delete : Delete the selected holiday schedule. ② Select all : Select or clear the entire list. NTU-100... -
Page 12: Ⅱ. 4 I-Radio Tine Signal Setup(I-Radio Reserve Broadcast Setting)
③ Displays reserved broadcast settings in Table Format. ④ Can add, delete or modify the information. ⑤ Set Holiday settings or delete the information. ⑥ Displays Help & Tips on I-Radio Time signal setup (I-Radio Reserved Broadcast Settings). NTU-100... -
Page 13: Ⅱ. 4-1 I-Radio Schedule Table View - View
③ Hour : Displays the set start and end time. ④ Day of the Week : Displays the day of the week. Ⅱ. 4-2 I-Radio reserved setting - dd Press the ‘ dd’ button to add a internet radio station. The following screen will appear. NTU-100... -
Page 14: Ⅱ. 4-3 I-Radio Reserved Setting - Delete
② File : Select a internet radio station play. ③ Time : Playing time. ④ Current Time : Current NTU-100 internal time is displayed. ⑤ Specified Time : The selected station will play for the interval set from ‘start time’ will repeat until the ’end time’. -
Page 15: Ⅱ. 4-4 I-Radio Reserved Setting - Modify
NETWORK TUNER Ⅱ. 4-4 I-Radio reserved setting - Modify fter modify the schedule, press the pply button. NTU-100... -
Page 16: Ⅱ. 4-5 I-Radio Holiday - Setup
③ Start/End Date : Set the start date and the end date of the holiday setup. ④ Start/End Time : set the start time and the end time of the holiday setup. Press the save button to save the holiday setup. ⑤ holiday can be set up to 30 events. NTU-100... -
Page 17: Ⅱ. 4-6 I-Radio Holiday - Delete
NETWORK TUNER Ⅱ. 4-6 I-Radio holiday - Delete ① Delete : Delete the selected holiday schedule. ② Select all : Select or clear the entire list. NTU-100... -
Page 18: Ⅱ. 5 I-Radio Setup
① Radio channels that have been set on the device are listed and can be selected from the list. ② Click [Play] button to play the selectionfrom step ①. Click [Stop] button to stop the current selection from play. ③ Click [Edit] button to change the radio channels. ④ Displays Help & Tips on I-Radio setup. NTU-100... -
Page 19: Ⅱ. 5-1 I-Radio Setup - Edit
⑥ Displays the currently set radio channels. Click [Delete] button on the right to delete the internet radio channels that are currently set. fter entering the title/address of desired radio channel, click [ dd] button to add to the list. ⑦ NTU-100... -
Page 20: Ⅱ. 6 Time Setup
Displays the current date and time. ③ Time Setup a. Manual Setup NTU-100 uses internal clock to make time so that its time has some drift from the correct time. It is needed to adjust the time regularly. b. utomatic Time Synchronization It synchronizes the time from the time server so that NTU-100 can maintain the correct time. -
Page 21: Ⅱ. 7 View Log
NETWORK TUNER Ⅱ. 7 View Log This page displays the log information of the NTU-100 setting and history of modification with time. ① Refresh – the current log details will be renewed ② Clear Log – the current log details will be deleted. -
Page 22: Ⅱ. 8 Upgrade System
① Choose the firmware from your computer using the ‘· · · ’ Tab. ② Start the firmware upgrade by clicking the ‘ pply’ button. Network settings will be retained after the upgrade. ③ Displays Help&Tips on Upgrade system. NTU-100... -
Page 23: Ⅱ. 9 Restart System
NETWORK TUNER Ⅱ. 9 Restart system To restart the NTU-100, press the ' pply' button. ① Reboot process takes about 30 seconds. ② Displays Help&Tips on Restart system. NTU-100... -
Page 24: Ⅱ. 10 Factory Setting
NETWORK TUNER Ⅱ. 10 Factory Setting To reset the NTU-100 to factory default, press the ‘ pply’ button. ① Reset process takes about 30 seconds. The network and time setting will be reset to default setting. ② Displays Help&Tips on View log. -
Page 25: Ⅱ. 11 Password Setting
② New Password – Enter the new password. ③ Password Confirm – Confirm the new password. ④ Press the ‘ pply’ button. Default password is ‘1’. To keep security, the password have to be changed to new one before use. ⑤ Displays Help&Tips on View log. NTU-100... - Page 26 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
