• Drop the head panel into place, with the slits fitting smoothly onto the
side panels to make it an even-sided grill.
Step 5:
• Slide the baffle plate into the
remaining two slots above the
center hole. It should look like a
rooftop over the pipe.
• Let the baffle plate rest a little on
the bottom plate.
Step 6:
• Slide the burner pipe through
the round hole on the head panel.
The curvature of the head panel
should be on the inside of the
grill, matching the curvature of
the other parts.
• Lift the head panel and slot the
tabs on the baffle plate onto the
corresponding slits of the head
plate.
20
Step 7:
Insert grill rack
Place Skotti in front of you with the burner pipe pointing to the right.
• Insert the grill rack with the Skotti logo into the corresponding
slots on the right side (head panel).
• Then, let the rack slide into the slots on the left side (foot panel).
• Carefully pull the rack back, towards the rigth. Once you hear it snap,
the grill is locked and stable.
3
2
1
3
1
3
21
2
