Compass quick guide
ChildFit
When working with very young children, it is not always possible to obtain all of the information
necessary for an accurate hearing aid fitting. To that end, Widex has developed the ChildFit procedure
which differs from our usual fitting procedure. ChildFit gives you a very precise estimated first fitting
based on only a few items of information about the child. And in addition to our new ChildFit procedure,
the Widex Baby hearing aid has been especially designed for infants and young children.
Widex Baby
Follow the procedure below to perform a binaural fitting of Widex Baby hearing aids. For details re:
choosing the correct earwire size and assembly, see Compass video.
Step 1: Removal of the Baby hearing aid battery doors is required in order to attach the programming
cables. Please see instructions and pictures 1a, 1b, 1c, and 1d below:
I.
Using tool open battery door (1a) and gently position the programming cable wire at the edge of
the door (1b)
II.
Proceed to close the door, holding the cable firmly in place as shown below (1c)
III.
The door should gently pop off. Please do not attempt to remove door in any other manner to
avoid breakage.
IV.
The programming adaptor is connected at the hinge area in the same manner as replacing a
battery door (1d).
1b
1d
1c
22/04/2010
1a
