Axis : You will set the placement of the mic towards the cone of the cabinet's speaker. At 0%
the mic is placed at the center of the speaker, at 100% the mic is placed either at the edge of
the speaker (when the mic is at the grill cloth), or up to 1 meter (3 feet) away from the center
(when the mic is at the furthest distance of the cabinet).
Dist : You will set the distance of the mic towards the cabinet. At 0% the microphone is placed
at the grid cloth of the cabinet. At 100% the mic is placed at 3 meters (10 feet) from the
cabinet.
Side : You will place the mic at the Front or at the Back of the cabinet.
4.3.2.3 EQ
The EQ section has 3 mode of operations : guitar, bass and custom.
4.3.2.4 Reverb
To enhance you experience with the Torpedo C.A.B. M, especially when playing with headphones,
your unit features different reverbs.
https://wiki.two-notes.com/
Guitar mode: 120Hz, 360Hz, 800Hz,
2000Hz, 6000Hz (centre frequency of each
band from the lower to the highest). You can
adjust the gain for each band with a range of -20
dB to +20dB
Bass mode: 50Hz, 120Hz, 360Hz, 800Hz,
4000Hz (centre frequency of each band, from
the lowest to the highest). You can adjust the
gain for each band with a range of -20 dB to
+20dB
Custom Mode : Instead of having fixed
frequencies to work with, you have a 5 band
semi parametric eq with a low cut filter.
Room: The room type determines the type of
reverb you will apply to your guitar or bass tone.
You have access to 8 different rooms: Studio A &
B, Hall A & B, Cathedral, Crypt, Basement and
Loft.
Dry/Wet: Determines the amount of reverb to
be applied to you tone.
