3.2 Using the Torpedo C.A.B. M with an amp
Insert the C.A.B. M between your amp and your cabinet. To do so, connect your amp to the
AMP/INST/LINE IN (item N°4 in the
connect the SPEAKER OUT (item N°5) of the C.A.B. M to your cabinet, again with a speaker cable.
If you are using a combo, unplug the speaker cable connected to the amp section of the combo, plug
this embedded combo speaker in the SPEAKER OUT of the C.A.B M, and connect the AMP IN of the
pedal to the output section of the amp with an additional speaker cable.
The C.A.B. is NOT a loadbox. Always keep a cabinet connected to the
SPEAKER OUT when an amp is connected to the AMP IN of the pedal.
https://wiki.two-notes.com/
overview diagram above) of the C.A.B. M with a speaker cable and
