xDEEP Stealth 2.0 User Manual

Tec side mount system
Hide thumbs
Table of Contents

Advertisement

Quick Links

STEALTH 2.0 TEC Side Mount System
User manual
English
Rev.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stealth 2.0 and is the answer not in the manual?

Questions and answers

Related Manuals for xDEEP Stealth 2.0

Summary of Contents for xDEEP Stealth 2.0

  • Page 1 STEALTH 2.0 TEC Side Mount System User manual English Rev.2...
  • Page 2 If any of the information contained in this manual or if any information label placed on the Buoyancy Compensation Device is not clear, contact the manufacturer for explanation: XDEEP Spółka z ograniczoną odpowiedzialnością Sp. K. Ul.Ogrodników 3, 43-227 Góra Polska Tel: +48 12 44 66 998 e-mail: biuro@xdeep.pl...
  • Page 3 80-416 Gdańsk Poland STEALTH 2.0 TEC buoyancy compensator has been certified as compatible with 89/686/EWG directive, as far as it contains air compatible with EN 12021 norm. Regarding the lack of EN norms for safety requirements while the use of it takes place with mixtures of higher oxygen content, the above mentioned buoyancy compensator cannot be regarded as one which has been a subject of CE certification with gas mixtures with oxygen level higher than 21% (+/- 2%) as stated in 89/686/EWG directive.

  • Page 4: Safety Rules

    3 Safety rules Danger! STEALTH 2.0 TEC BC is designed to provide the user with safety and comfort. Improper use may result in an accident, therefore it is necessary to comply with ALL of the following rules. 1. Before every dive, carefully inspect all elements of the equipment, including the BC. For further information on the subject, read: “Pre-dive inspection”.
  • Page 5 4 Elements of the STEALTH 2.0 system The Stealth 2.0 system consists of a few independent elements, which may be configured depending on individual preferences and on the specification of the type of diving you are engaged in.  The Stealth 2.0 Harness...
  • Page 6 The STEALTH harness has been designed for side-mount diving and can be used with or without the integrated weight system. The picture below shows the harness in its basic configuration, with the weight system installed: Fig. 2. Harness STEALTH 2.0 1. Upper node (partly under the weight pocket) 2. Lower node (under the weight pocket);...
  • Page 7 The STEALTH 2.0 harness is offered in one universal size. The adjustment system makes it simple to fit either a very small or very large person by the adjustment of shoulder straps, a waist strap, and a crotch strap, as well as by the adjustment of the distance between the lower and the upper node to accommodate the height of the diver.
  • Page 8 7 The harness adjustment 2/2 The STEALTH 2.0 provides great comfort and full freedom of movement, providing the lower and upper nodes are placed in the right spot on the back. The lower node should be in such a place so that the waist strap is exactly on the waistline, and the upper node of the harness should be in such a place so that the metal element is between the shoulder blades.
  • Page 9 8 Mounting of the bungee cord 1/2 The characteristic feature of the side mount configuration are the bungee cords which route around the cylinders valve and draw the cylinder tight into the divers body, creating a very clean and streamlined profile. There are several different methods of mounting the bungee cord: 1.
  • Page 10 9 Mounting of the bungee cord 1/2 The STEALTH 2.0 buoyancy compensator is equipped with additional adjustment points used for mounting the bungee to the compensator which are located in its upper underside. The adjustment points ensure an easy movement of the bungees at the same time stabilizing the BC and preventing the upper part of the compensator from getting loose and baggy.
  • Page 11 9 Central Weight Pocket 1/3 The STEALTH 2.0 weight system in the basic configuration consists of the central weight pocket placed on the back, and in the optional trim pockets which allow for an increase in the total weight capacity of the system as well as improved trim adjustment.
  • Page 12 10 Central Weight Pocket 2/3 In order to change the position of the central weight pocket follow the steps below: 1. Unscrew the nut placed inside the weight pocket in its upper part; Fig.11. Adjustment of the central weight pocket – step 1 2.
  • Page 13 11 Central Weight Pocket 3/3 5. Adjust the metal adaptor plate to the desired height for the central weight pocket, remember to attach the backing screw. The backing screw should be on the same side as the logo on the upper harness node.
  • Page 14 12 Trim Pockets The STEALTH 2.0 harness enables you to mount additional weight pockets practically anywhere, allowing for optimal placement of the weight, regardless of the type of exposure suit used. The pockets are mounted on the straps using two attached tri-glides.
  • Page 15 13 Optional droppable weight pockets The STEALTH 2.0 harness enables the installation of the xDEEP two weight pocket with capacity of 2x3kg or 2x6kg of weight on your waist strap, which were originally designed to be used with back-mount systems.

  • Page 16: Other Components

    14 Other components Mounting of the light canister Together with the STEALTH 2.0 harness you will receive an accessory plate enabling you to attach the light canister to your crotch, waist or shoulder strap. The canister can be attached with bungee cords which hold it securely, and at the same time enable its easy and quick removal during movement through narrow spaces and then its re-attachment.
  • Page 17 15 Stealth 2.0 TEC BC 1/2 Independent STEALTH 2.0 buoyancy compensator is designed to be used with most of the SM harnesses in configuration with one, two, or more cylinders. The basic elements of the compensator Fig.20. STEALTH TEC BCD (from the top side).
  • Page 18 17 Stealth 2.0 TEC BC 2/2 STEALTH 2.0 Tec BC is mounted to the harness and while in use it remains fixed to it. The compensator is mounted to the harness in six points. Fig. 23. Mounting points of STEALTH 2.0 BC 1.
  • Page 19 16 BC configuration and adjustment 1/3 Self-assembly harness and compensator In the event of a separate order of the compensator without the harness it needs to be mounted by the user following the given order: 1. Dismantle the shoulder strap by passing it through the lower adjustment point and taking off all the mounted elements such as D-rings, tri-gliders or bungees.
  • Page 20 16 BC configuration and adjustment 2/3 5. Install the flat D-rings that serve as double ender clipping points on the waist strap and follow the instruction. Fig. 26. Way of attaching flat d-ring on the waist strap How to make side loops from the bungee . The loops that mount the compensator are made from a 5mm bungee cord whose one end is mounted to the outer layer of the compensator while the other end has a fixed bolt-snap which, when in use, is clipped off to the flat D-ring on the waist strap.
  • Page 21 16 BC configuration and adjustment 3/3 Fig. 27. Bungee loop Alternative ways of mounting bungee loops Depending on the needs and preferences you can apply two other ways of mounting the compensator to the harness which are very similar to the method used when mounting the STEATH 2.0 Classic compensator: 1.
  • Page 22 21 ACCESS TO THE WEIGHT SYSTEM STEALTH 2.0 TEC Setup provides easy access to the weight system including the central weight pocket fixed to the harness. In order to reach the central pocket compartments put the harness down on a flat surface in such a way that the compensator lies down beneath and unclip the bolt-snap fixing the compensator on the waist strap on the left side.
  • Page 23 18 Connecting the LP hose To allow for proper operation of the inflator it must be connected to the LP port of the 1st stage of the regulator using the LP hose supplied with the BC. Danger! LP hose connection using the 1 stage of the regulator must be made to the low pressure (LP) port only.
  • Page 24 19 Wearing the compensator STEALTH compensator should be put on after the harness with the weight system have been put on and before donning the cylinders. Mounting the compensator is carried out by putting it on the lumbar region and then tying up the loops with double-enders in front.
  • Page 25 If trimmed properly, STEALTH 2.0 allows you to enjoy the ideal position, regardless of the gas volume in the cylinders, and without the need to manage trim with the use of a dry-suit.

  • Page 26: Pre-Dive Inspection

    7. Inflate the BC using the inflator button and leave it fully inflated for 15 minutes. After the 15 minutes the BC should remain full. If it is not, do not use it until the defect is removed by an authorized XDEEP service center.

  • Page 27: Operation

    22 Operation Buoyancy on the surface In order to ensure maximum buoyancy on the surface, before getting into the water (or directly after ascending) inflate the BC using inflator button. Stop inflating the BC when the automatic dump valve activates. Danger! Before jumping into deep water from a boat or a bank inflate the BC using the inflator button.

  • Page 28: Post-Dive Maintenance

    23 Post-dive maintenance Disconnecting After diving, take out the weight from the weight pockets (if applicable), disconnect the LP hose from the inflator, and then disconnect the tank. Draining Inflate the BC orally using the purge button of the inflator. Next turn the BC to keep the automatic dump valve at the lowest point of the BC.

  • Page 29: Repair And Maintenance

    24 Repair and maintenance STEALTH 2.0 TEC BC does not contain any elements which can be repaired by the user, and so all repairs (including lubrication or replacement of worn-out elements) should be performed only by trained technicians holding certificates issued by the producer (authorized service center).

  • Page 30: Troubleshooting

    25 Troubleshooting The STEALTH 2.0 System gives huge possibilities for configuration adjustment to your own needs. Sometimes it happens that divers make “rookie” mistakes as far as the harness or compensator configuration are concerned. Here are some basic problems and solutions to them: The harness sticks out from your back when you arch your body It is a typical situation, since the harness is improperly adjusted to your height.
  • Page 31 26 Technical specification of the BC Basic parameters Type Side mount buoyancy compensator, mounted to the STEALTH 2.0 harness. Buoyancy 19 kg Outer shell fabric Cordura 1100 dTEX Inner bladder fabric Nylon 440 dTEX Weight of the dry compensator 1.4 kg (without harness).
  • Page 32 XDEEP Spółka z ograniczoną odpowiedzialnością Sp. K. Ul.Ogrodników 3 43-227 Góra Polska Tel: +48 12 44 66 998 e-mail: biuro@xdeep.pl...
